Operation

This section is intended to assist the operator with the initial
start-up of the walk-behind trowel. It is extremely important
that this section be read carefully before attempting to use
the trowel in the field. DO NOT use your trowel until this
section is thoroughly understood.
Lifting the Trowel Onto a Slab
Extra care should be taken when lifting the trowel off the
ground. Serious damage to the machine or personal injury
could be caused by dropping a trowel.
WARNING
NEVER attempt to lift this machine alone. NEVER lift
the trowel by the guard ring as it may rotate and cause
injury.
ALWAYS make certain the handle is secure and use
only the manufacturer's approved lifting point. The
trowel may be lifted at the center lifting bale by crane
or other lifting device of adequate capacity.
NOTICE
DO NOT attempt to operate the trowel until the Safety,
General Information and Inspection sections of this
manual have been read and thoroughly understood.
NOTICE
The trowel is heavy and awkward to move around. Use
proper heavy lifting procedures and DO NOT lift the
trowel by the guard rings.
BS90C WALK-BEHIND TROWEL • OPERATION AND PARTS MANUAL — REV. #0 (9/4/15)— PAGE 25
Lifting Bale
The lift bale provides an optimal lift point for lifting the trowel.
When lifting the trowel onto a concrete slab, attach a chain
or rope to the lifting bale. Make sure the lifting device has
adequate lifting capacity to lift the trowel.
Using a crane or forklift (Figure 25) to lift the trowel is highly
recommended, and is perfectly safe for the trowel. ALWAYS
use extra care when lifting the trowel off the ground.
Figure 25. Lifting the Trowel
NEVER lift the trowel to unnecessary heights. DO NOT
stand underneath the trowel while it is being lifted. Serious
damage to the machine or personal injury could be caused
by dropping a trowel.
