PARTS AND OPERATION MANUAL
B-Series Power
Trowel
(CHINA)
Revision #0 (12/03/01)
P/N 20966

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the B Series and is the answer not in the manual?

Questions and answers

Related Manuals for MULTIQUIP B Series

Summary of Contents for MULTIQUIP B Series

  • Page 1 PARTS AND OPERATION MANUAL B-Series Power Trowel (CHINA) Revision #0 (12/03/01) P/N 20966...
  • Page 2 We sell worldwide for the brands: Genie, Terex, JLG, MultiQuip, Mikasa, Essick, Whiteman, Mayco, Toro Stone, Diamond Products, Generac Magnum, Airman, Haulotte, Barreto,...

  • Page 3: Table Of Contents

    TABLE OF CONTENTS CONGRATULATIONS ON YOUR PURCHASE OF YOUR POWER TROWEL! Each and every walk-behind trowel is designed-without compromise-to produce the finest possible finishes. B-Series Trowel Table Of Contents ........... 3 General Safety Guidelines ........4 Explanation Of Codes In Remarks Column .... 5 Safety Information ...........

  • Page 4: General Safety Guidelines

    GENERAL SAFETY GUIDELINES Failure to follow instructions in this manual may lead to serious injury or even death! This equipment is to be used by qualified and trained personnel only. This equipment should not be operated by persons under 18 years of age.

  • Page 5: Explanation Of Codes In Remarks Column

    EXPLANATION OF CODE IN REMARK COLUMN How to read the marks and remarks used in this parts book. Section 1: Items Found In the “Remarks” Column Serial Numbers-Where indicated, this indicates a serial number range (inclusive) where a particular part is used. Model Number-Where indicated, this shows that the corresponding part is utilized only with this specific model number or model number variant.

  • Page 6: Safety Information

    SAFETY INFORMATION RECOGNIZE SAFETY INFORMATION, FOLLOW ALL SAFETY INSTRUCTIONS SYMBOLS AND TERMINOLOGY Note: If there are ANY questions regarding this manual (i.e. something is unclear) contact Discount-equipment. Read ALL safety instructions carefully. Safety instructions will be This is the caution symbol. Wherever you see found throughout this manual and on the machine.

  • Page 7: Fuel

    FUEL Dispose of potentially hazardous waste properly. Examples of FUEL potentially hazardous waste are: motor oil, fuel and filters. Use Handle fuel safely. Motor fuels are highly flammable and can be rigid containers for trapping these items. Do not use old food or dangerous if mishandled.

  • Page 8: Instructions

    B-SERIES TROWEL — INSTRUCTIONS Putting Into Service Before packing and shipping, this Power Trowel was run and tested at the factory. If there are any problems, please let us know. Fill out and send the warranty-registration card supplied with the machine.
  • Page 9 B-SERIES TROWEL — INSTRUCTIONS STEP 5 STEP 5 STEP 5 STEP 5 STEP 5 Preload adjustment for QUICK PITCH Remove one brass nut from the cable end. Thread the second After the handle is installed on the machine, spring preload brass nut towards the cable as far as possible.
  • Page 10 B-SERIES TROWEL — INSTRUCTIONS General Instructions Set the throttle lever to the idle position by pushing it away from the operator’s position towards the engine (counter clockwise from the top- Step 1). Loosen the screw that crimps the throttle cable to allow free movement of throttle cable (Step 2). STEP 4 STEP 4 STEP 4...
  • Page 11 B-SERIES TROWEL — INSTRUCTIONS Handling Machine Operations Machine is heavy and awkward to move around. CONTROLS Use proper heavy lifting procedures and DO Safety Kill Switches NOT LIFT THE MACHINE BY GUARD RINGS. Your finisher has been equipped with a safety kill switch or a hand operated clutch.
  • Page 12 B-SERIES TROWEL — INSTRUCTIONS Engine Operation Blade Pitch — Standard Handle Check the oil level before starting the engine. The pitch control on machines equipped with the standard handle is a big star-wheel knob located at the operator end of the main Because of the number of engine options, please handle tube.
  • Page 13 B-SERIES TROWEL — INSTRUCTIONS NEVER start the engine with the throttle Maintenance (Service, Adjustment and Repair) above the idle position. Note: See the engine manual supplied with your machine 5. Grasp the control handle with left hand. Pull for appropriate engine maintenance schedule. slowly on starter rope until resistance is felt, then There is a “Daily Preoperation Check List”...
  • Page 14 B-SERIES TROWEL — INSTRUCTIONS The easiest way to make this adjustment is to use the Trowel Arm 2. Remove the bolts and lock washers on the trowel arm, then Adjustment Fixture, Part Number 1817 (pictured below). This remove the blade. fixture will allow consistent adjustment of the trowel arm fingers.

  • Page 15: Troubleshooting

    B-SERIES TROWEL — TROUBLESHOOTING TROUBLESHOOTING SYMPTOM POSSIBLE PROBLEM SOLUTION Engine running rough or not at all. Kill switch off or malfunctioning? Make sure that the kill switch is on or replace switch if necessary. Other problems? Consult engine manufacture’s manual. Safety kill switch not functioning.

  • Page 16: Operator Training

    B-SERIES TROWEL — OPERATOR TRAINING Operator Training SUGGESTED TRAINING Note: ONLY QUALIFIED AND EXPERIENCED PERSONNEL SHOULD OPERATE THIS EQUIPMENT Before taking your new equipment to the job site for it’s first use, there are a few things that should be considered before operation.

  • Page 17: Optional Equipment

    Note: BLADES SHOULD BE CHANGED WHEN THEY FAIL TO Multiquip makes a special tool that will adjust all of the trowel arms FINISH CONCRETE IN A SATISFACTORY MANNER. consistently, Part Number 1817-Trowel Arm Fixture.

  • Page 18: Technical Specifications

    B-SERIES TROWEL — TECHNICAL SPECIFICATIONS TECHNICAL SPECIFICATIONS MODEL J A 36.7 in. 931.6mm 34.5 in. 876.2mm B 41.4 in. 1044.2mm 41.1 in. 1044.2mm C 36.5 in. 927.1mm 46 1168.4mm D 70.5 in. 1789.4mm 75.2 in. 1910.1mm Weight 150 lb. 330 Kg 240 lb. 528 Kg Sound Pressure* 94 dB 94 dB 97 dB 97 dB Vibration** 2.0g 19.6m/s2 2.5g 24.5 m/s2 Blade Speed (max.) 129 rpm @ 4000 129 rpm @ 4000 129 rpm...
  • Page 19 B-SERIES TROWEL — HANDLE PAGE 20 — B-SERIES TROWEL — PARTS & OPERATION MANUAL — REV. #1 (12/03/01)

  • Page 20: Handle

    B-SERIES TROWEL — HANDLE B-SERIES POWER TROWEL HANDLE PART NO. PART NAME QTY. REMARKS 0189 HANDLE GRIP 4634 HANDLE GRIP (ELECTRIC MODEL) 1102 PLUG 0304 RHMS 10-24X 1/4" 1103 SAFETY SWITCH ASSY 1101 HANDLE ONLY 1907 HANDLE ONLY (ELECT. MODEL) HANDLE ASSY ..........

  • Page 21: Quick Pitch Handle

    B-SERIES TROWEL — QUICK PITCH HANDLE™ PAGE 22 — B-SERIES TROWEL — PARTS & OPERATION MANUAL — REV. #1 (12/03/01)
  • Page 22 B-SERIES TROWEL — QUICK PITCH HANDLE™ B-SERIES POWER TROWEL QUICK PITCH HANDLE PART NO. PART NAME QTY. REMARKS 1746 QUICK PITCH TRIGGER 1724 CONTROL HANDLE GRIP 1707 CONTROL HANDLE ........1 ....INCLS. P/N 1739 BUSHING 1739 BUSHING 1734 WARNING DECAL 1729 ROLL PIN 3/16X1.1/4"...

  • Page 23: Spider And Blades

    B-SERIES TROWEL — SPIDER AND BLADES B-SERIES POWER TROWEL SPIDER & BLADES PAGE 24 — B-SERIES TROWEL — PARTS & OPERATION MANUAL — REV. #1 (12/03/01)
  • Page 24 B-SERIES TROWEL — SPIDER AND BLADES B-SERIES POWER TROWEL SPIDER & BLADES PART NO. PART NAME QTY. REMARKS 12208 WEAR RING 12778 FLANGE BEARING 10793 THRUST COLLAR 1154A WEAR PLATE ............1 ..INCLUDES ITEMS W/$ 1157A BEARING INSERT 0164B FULL THREAD, RADIUS HEAD 3/8-16X1.1/4"...

  • Page 25: Gear Box And Engine Mounts

    B-SERIES TROWEL — GEARBOX AND ENGINE MOUNTS PAGE 26 — B-SERIES TROWEL — PARTS & OPERATION MANUAL — REV. #1 (12/03/01)
  • Page 26 B-SERIES TROWEL — GEARBOX AND ENGINE MOUNTS B-SERIES POWER TROWEL GEARBOX & ENGINE MOUNTS PART NO. PART NAME QTY. REMARKS 1131 GEAR CASE 0131A HHCS 1/4-20X3/4" 1136 END CAP 2614 GASKET KIT ..........1 ....INCLS. ITEMS W/ 0735A BEARING CUP 1132 AIR VENT 0735...

  • Page 27: Engine

    B-SERIES TROWEL — ENGINES, 5 HP B&S, 6.0 HP ROBIN, 5.5 HP HONDA ENGINES, 5 H.P. B&S, 6.0 H.P. ROBIN, 5.5 H.P. HONDA ASSY. PAGE 28 — B-SERIES TROWEL — PARTS & OPERATION MANUAL — REV. #1 (12/03/01)
  • Page 28 B-SERIES TROWEL — ENGINES, 5 HP B&S, 6.0 HP ROBIN, 5.5 HP HONDA ENGINES, 5 H.P. B&S, 6.0 H.P. ROBIN, 5.5 H.P. HONDA ASSY. PART NO. PART NAME QTY. REMARKS 1256 ENGINE 6.0 HP ROBIN GX240K1QA2 ENGINE 5.5 HP HONDA 1242 ENGINE 5 HP BRIGS &...

  • Page 29: Hand Clutch (S/N Lj41888 And Below)

    B-SERIES TROWEL — HAND CLUTCH — S.N. LJ41888 AND BELOW PAGE 30 — B-SERIES TROWEL — PARTS & OPERATION MANUAL — REV. #1 (12/03/01)
  • Page 30 B-SERIES TROWEL — HAND CLUTCH — S.N. LJ41888 AND BELOW B-SERIES POWER TROWEL HAND CLUTCH - S/N LJ41888 AND BELOW PART NO. PART NAME QTY. REMARKS GX24OK1QA2 ENGINE 8HP HONDA 1256 ENGINE 7.5HP ROBIN 2834 SPACER (ROBIN) 1512 HAND CLUTCH HAND LEVER 10075 HAND CLUTCH CABLE ASSY LIFTING BALE ASSY ........

  • Page 31: Hand Clutch (S/N Lj41889 And Above)

    B-SERIES TROWEL — HAND CLUTCH — S.N. LJ41889 AND ABOVE PAGE 32 — B-SERIES TROWEL — PARTS & OPERATION MANUAL — REV. #1 (12/03/01)
  • Page 32 B-SERIES TROWEL — HAND CLUTCH — S.N. LJ41889 AND ABOVE B-SERIES POWER TROWEL HAND CLUTCH — S.N. LJ41889 AND ABOVE PART NO. PART NAME QTY. REMARKS GX24OK1QA2 ENGINE 8HP HONDA 1256 ENGINE 7.5HP ROBIN 10036 CLUTCH ASSIST HANDLE ASSY 6014C HEX FINISH NUT 5/16-24 0300B FLAT WASHER 5/16”...
