HIGH PRESSURE PORTABLE FORCED AIR HEATER OWNER’S MANUAL 350 SIDE PFA/PV 008 Model B350EAI IMPORTANT Read and understand this manual before assembling, starting, or servicing heater. Improper use of heater can cause serious injury. Keep this manual for future reference.
SAFETY INFORMATION 099565 WARNINGS WARNING ICON G 001 IMPORTANT: Read this Owner’s Manual carefully and completely before trying to assemble, operate, or service this heater. Improper use of this heater can cause serious injury or death from burns, fire, explosion, electrical shock, electrocution, and carbon monoxide poisoning.
Lower Shell Fuel Cap Thermostat Figure 1 - B350EAI BTU/Hr Model 1. Remove all protective packing applied to heater for shipment. 2. Remove heater from shipping container. 3. Check heater for any shipping damage. If heater is damaged, promptly inform dealer where you bought heater.
Page 5
ASSEMBLY Continued 099565 Front Handle Screw Hot Air Outlet Fuel Tank Flange Wheel Support Frame Wheel Cotter Flat Washer Figure 2 - Wheel and Handle Assembly Air Inlet Extended Axle Wheel Spacer Flat Washer Rear Handle...
THEORY OF OPERATION Clean Heated Air Out The Fuel System: The motor turns the fuel pump. The fuel pump pulls fuel from the fuel tank. The fuel pump pushes fuel through a filter and a solenoid valve and out the burner head nozzle. A fine mist of fuel is sprayed into the combustion chamber. The Air System: The motor turns the fan.
FUELS VENTILATION 099565 WARNING ICON G 001 Use only kerosene or No. 1 fuel oil to avoid risk of fire or explosion. Never use gasoline, naphtha, paint thinners, alcohol, or other highly flammable fuels. Do not use heavy fuels such as No. 2 fuel oil or No. 2 diesel. Using heavy fuels will result in: •...
OPERATION WARNING ICON G 001 Review and understand the warnings in the Safety Information Section. They are needed to safely operate this heater. To Start Heater 1. Follow all ventilation and safety information. 2. Fill fuel tank with kerosene or No. 1 fuel oil. 3.
OPERATION Continued STORAGE 099565 To Stop Heater WARNING ICON Never unplug heater while heater is running. Heater must go through purge cycle. The purge cycle cools the combustion chamber. Damage to heater can occur if combustion chamber is not cooled. Do not restart heater until purge cycle is complete. 1.
PREVENTATIVE MAINTENANCE SCHEDULE WARNING ICON Never service heater while it is plugged in, operating, or hot. Severe burns and electrical shock can occur. Item How Often Fuel tank Flush every 150-200 hours of operation or as needed. Filler neck screen Check for trash when filling fuel tank.
TROUBLE- SHOOTING 099565 WARNING ICON G 001 Never service heater while it is plugged in, operating, or hot. Severe burns and electrical shock can occur. Only a qualified service person should service and repair heater. OBSERVED POSSIBLE CAUSE PROBLEM Motor does not 1.
Page 12
TROUBLE- SHOOTING Continued OBSERVED POSSIBLE CAUSE PROBLEM Heater will not 1. A) Fuel tank empty ignite, but motor B) Water in fuel runs for a short C) Wrong fuel period of time. 2. Dirt in nozzle 3. Very low temperature may cause fuel to thicken and not flow 4.
Page 13
OBSERVED TROUBLE- PROBLEM SHOOTING Heater ignites, but Continued safety control shuts off heater after a short period of time. Heater burns, but puffs of smoke can be seen. Heater does not burn steady. Heater burns with odor. Heater smokes continuously. 099565 POSSIBLE CAUSE REMEDY...
SERVICE PROCEDURES Upper Shell Removal 1. Remove screws along each side and top of heater using 5/ 16" nut-driver. These screws attach upper and lower shells together (see Figure 5). 2. Lift upper shell off. Fan Blades 1. Remove upper shell (see above).
Spark Plug 1. Remove upper shell (see page 14). 2. Remove spark plug wire from spark plug (see Figure 7). 3. Remove spark plug from burner head using 13/16" open- end wrench (see Figure 7). 4. Replace spark plug if damaged or heavily coated with carbon.
Pump Pressure Adjustment 1. Remove pressure gage plug from fuel pump port marked “GAGE.” 2. Install accessory pressure gage (part number M4574) to fuel pump port marked “GAGE” (see Figure 10). 3. Start heater (see Operation, page 8). Allow motor to reach full speed.
Fuel Filters A. Tank Fuel Filter 1. Disconnect fuel lines from pump and pump fuel filter assembly with 7/16" wrench (see Figure 15). 2. Carefully pry fuel filter loose from fuel tank with flat end of screwdriver. 3. Inspect fuel filter for water or dirt.
SPECIFICATIONS WIRING DIAGRAM ACCESSORY Output Rating (BTU/Hr) Fuel Fuel Tank Capacity (U.S. Gal./Liters) Fuel Consumption (Gal. Per Hr/Liter Per Hr) Electric Requirements Amperage (Normal Run) Motor RPM Fuel Pump Pressure (PSI) Spark Plug Gap Weight (approx. lbs./kilograms) Dry (net) With Full Fuel Tank Black Relay White...
PARTS LIST Burner Head Assembly PART NO. DESCRIPTION M10908-2 Screw, #6-32 x 3/8" 099229-01 Photocell bracket HA3012 Spark plug M51070-02 Nozzle M51170-01 Plug M50924-02 Burner head body 69246 Straight nipple M50077-02 Solenoid valve M50297 Compression elbow Motor and Pump Assembly REF.
WARRANTY AND REPAIR SERVICE EQUIPMENT - LIMITED 90 DAY WARRANTY DESA International warrants new Products sold by it to be free from defects in material or workmanship for a period of ninety days after date of delivery to the first user and subject to the following conditions: DESA International's obligation and liability under this Warranty is expressly limited to repairing or replacing at DESA...
