Asko TL751XXL Operating Instructions Manual
Asko tumble dryer operating instruction
Hide thumbs
Also See for TL751XXL:
- Training program (96 pages) ,
- Operating instructions manual (47 pages) ,
- Service manual (83 pages)
Table of Contents
Advertisement
Quick Links
Operating Instructions
Tumble dryer
Save these instructions for future reference
Dear customer,
Thank you for choosing this quality product from ASKO. We
hope it will meet all of your expectations and fullfill your needs for
many years to come. The Scandinavian design is a combination of
clean lines, everyday functionality and high quality. These are the
hallmarks for all of our products and this is why they are so highly
appreciated all over the world.
To get the most out of your new ASKO product, we recommend that
you read the installation and operating instructions before using the
machine.
Asko TL751 XXLW
1
Customer Care Center
1-800-898-1879
www.askousa.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Asko TL751XXL
Summary of Contents for Asko TL751XXL
-
Page 1: Operating Instructions
To get the most out of your new ASKO product, we recommend that you read the installation and operating instructions before using the machine. -
Page 3: Table Of Contents
Contents Before using your machine for the first time Important safety instructions Grounding instructions Interrupting a program Transport/Winter storage Packing material Recycling Child safety Description of the tumble dryer Front panel Advice and tips before you tumble dry Have the clothes been spun? Laundry labels Do not tumble dry Operating instructions... -
Page 4: Before Using Your Machine For The First Time
Before using your machine for the first time Do not tumble dry Certain materials are not suitable for tumble drying. Always check and follow the Instructions on each item’s laundry label. You can find more information in the “Advice and tips before you tumble dry"... -
Page 5: Important Safety Instructions
• The interior of the machine should be cleaned periodically by an authorized ASKO service agent. • Do not place items exposed to cooking oils in your dryer. Items contaminated with cooking oils may contribute to a chemical reaction that could cause a load to catch fire. -
Page 6: Interrupting A Program
Important safety instructions To reduce the risk of fire, this appliance must be exhausted outdoors or the equivalent. Do not exhaust into a chimney, wall, ceiling or concealed space in a building. Warning! Improper connection of the equipment- grounding conductor can result in a risk of electric shock. -
Page 7: Child Safety
Child safety Do not allow children to play with the Tumble dryer. The tumble dryer does not start automatically when the door closes (for example, if a child closes the door from inside). The tumble dryer has a door lock, which allows the door to be opened from the inside. -
Page 8: Description Of The Tumble Dryer
Description of the tumble dryer 1. Top plate 2. Program panel 3. Front cabinet 4. Lint filter holder 5. Fan (behind the front cabinet) 6. Adjustable leg 7. Glass door 8. Outer door Accessories Dryer Rack Pedestal Purchased Separately ❈ Design of pedestals is subject to change without manufacturers notice. -
Page 9: Front Panel
Front panel 1. Power button 2. Program selector 3. Display window 4. Settings buttons 5. Options buttons 6. Start/Stop button Customer Care Center 1-800-898-1879 www.askousa.com... -
Page 10: Advice And Tips Before You Tumble Dry
Advice and tips before you tumble dry Here are some tips that may help you before you begin tumble drying. Have the clothes been spun? Items to be tumble dried should be spun at 1000 rpm or faster. Higher spin speeds save both energy and drying time. -
Page 11: Operating Instructions
Operating instructions Warning! To reduce the risk of electric shock or injury to persons, read the “Important Safety Instructions” selection before operating this appliance. Below are step-by-step instructions to help you achieve the best possible tumble drying results. Sort your fabrics. You will achieve the most uniform drying results if the items are made of the same type of material. -
Page 12: Manual Dry Preset Program Settings
Operating instructions Sensor Dry Preset Program Settings Sensor Dry Programs Temperature Load Type Bulky Items High (Bulky, Heavy weight) Towels High (Jeans, Heavy weight) Everyday Wear Mid. High (Towel, Denim pants) Synthetics Medium (Work clothes, Corduroys) Gentle (Synthetics, Permanent press) Ultra Gentle (Lingerie, Sheets, Blouses) Iron Dry... -
Page 13: Options Guide
Operating instructions Programed settings and options guide Cycles Dry Sensor Default Normal Bulky items Select Default Normal Towels Select Default Normal Everyday wear Select Default Normal Synthetic Select Default Normal Gentle Select Default Normal Ultra gentle Select Default Damp dry Iron dry Select Default... - Page 14 Operating instructions Press the Start button Remaining drying item The remaining drying time will be shown on the display. For example, 1:35 means it will take approximately 1 hour and 35 minutes for the load to dry. If the Anti- crease option has been selected, the drum will rotate until you press the Power button or Start/Stop button.
-
Page 15: Selecting Settings
Selecting Settings Dry Sensor • Use these buttons to set dry level. • First, select the Sensor Dry program. • Select dry level to adjust how much you want to dry the load. As the program runs, the control senses the dryness of the load and adjusts the time automatically based on the selected dryness level. -
Page 16: Selecting Options
Selecting Options Rack Dry Rack Dry is designed to use for items which are not suitable for tumble drying such as sweaters, silk, lingerie. This option may be used for drying sneakers. Note! During the Rack Dry cycle, • Time remaining goes to 55min and no default temperature. -
Page 17: Damp Signal
Selecting Options Note! Time change is available only with Manual dry, Dry Time and Rack dry programs. Damp Signal When you select the Damp Signal option, a beep will alert you when your load is just damp enough for ironing or pressing. This notice will allow you to remove lightweight items that are dried or other items that you may wish to iron. -
Page 18: Care And Maintenance Instructions
Care and maintenance instructions Cleaning the lint filter Clean the filter after each use and check it before use. Not cleaning or emptying the filter will increase drying time and energy consumption, potentially shortening the dryer life expectancy. 1. Open the door and pull the filter straight up. 2. -
Page 19: Troubleshooting Guide
Troubleshooting guide Troubleshooting Tip! Save time and money! Review the charts on the following pages first and you may not need to call for service. 1. Problem: My dryer won’t start. Question • Is the dryer plugged in? Confirm that the dryer’s plug is securely and completely pushed into the laundry room’s power outlet. -
Page 20: There Is Lint On My Clothes
Troubleshooting guide 5. Problem: There Is Lint On My Clothes Question • Is your lint filter full? Please refer to the manual section on cleaning the lint filter, and please confirm that the lint filter is clean. It is important that the lint filter is clean before each new load of laundry. -
Page 21: It Takes Too Long For My Clothes To Dry
Troubleshooting guide 9. Problem: It Takes Too Long For My Clothes To Dry Question • Did you properly sort your loads of laundry? • Are you drying large loads of heavy fabrics? • Are the dryer controls properly set? • Is the lint filter clean before each new load of laundry? •... -
Page 22: Technical Information
Technical information Technical data Height: Width: Depth: Weight: Cylinder volume: Max. drying capacity: Speed: Rated power: Drum material: Outer casing material: Setup 40 1/4'' (102.2 cm) 27” (68.6 cm) 31 1/2" (80 cm) 129 lb (58.5 kg) 7.3 cu.ft. (54.6 gal, 207 l) 22.9 lb (10.4 kg) 48 rpm See the rating label regarding detailed information. -
Page 23: Service And Guarantee
• Replacement parts or repair labor costs for units operated outside the continental United States. • Pickup and delivery. ASKO washers are designed to be repaired in the home. In no event shall Asko Appliances Inc. be responsible for any incidental or consequential damages. - Page 24 Asko Appliances Inc. will pay for: ASKO replacement parts and/or repair labor to correct defect in materials or workmanship. Service must be provided by an authorized ASKO service agent. ASKO replacement parts and/or repair labor to correct defect in materials or workmanship.
-
Page 25: Installation Instructions
Installation instructions The following instructions will guide you through the initial steps of setting up your dryer. Please note that every section of this manual provides important information regarding the preparation and use of your dryer, and it is important that you review this entire manual before proceeding with any installation or use. - Page 26 Installation instructions Minimum clearances on above, behind, and sides of the unit, as shown below, are required. Those required minimum clearances are set forth in the picture below. Please keep the following instructions in mind when installing in a closet or recessed area: •...
-
Page 27: Connecting The Exhaust System
Installation instructions Step 2. Connecting the exhaust system Warning! • To reduce the risk of fire this appliance MUST BE EXHAUSTED OUTDOORS. • The appliance should not be exhausted into a chimney, a wall, a ceiling, or a concealed space of a building. •... - Page 28 Installation instructions Alternate exhaust directions 1. Insert the 90° Elbow (4") into the end of the exhaust duct on the rear panel in the correct direction. 2. Connect the straight exhaust duct into the end of the 90° Elbow (4"). 3.
-
Page 29: Electrical Plug Connections
Installation instructions Step 3. Electrical plug connections The following steps are several warnings and instructions concerning making the electrical connection for electric dryers. More detailed information concerning the electrical connection is provided in the manual section entitled Electrical Requirements for Electric Dryer. It is important that you thoroughly review that section and the remainder of this manual, before taking any steps to install or use this... -
Page 30: Dryer Airflow
Installation instructions Step 6. Dryer airflow Effective dryer operation requires appropriate dryer airflow. The adequacy of the airflow can be measured by evaluating the static pressure. Static pressure in the exhaust duct can be measured with a manometer, placed on the exhaust duct approximately 1 ft. -
Page 31: Important Warning
Installation instructions installed with a clearance of 1/2” (1.2cm) at the sides and back of the dryer. 8) Please be aware that venting materials are not supplied with the dryer. You should obtain the venting materials necessary for proper installation. Warning! DO NOT connect exhaust ducts with metal screws or fasteners that extend into the... -
Page 32: Electrical Requirements
Electrical requirements Review the following options to determine the appropriate electrical connection for your Home: Use the instructions in this section if your home has a 4-wire receptacle (NEMA type 14-30R) and you will be using a UL listed, 120/240V 30amp, dryer power supply cord. 4-wire receptacle (NEMA type14-30R) If this type is available at your home, you will... - Page 33 Electrical requirements 4-wire connection: Direct wire Important! Grounding through the neutral conductor is prohibited for (1) new branch-circuit installations, (2) mobile homes, (3) recreational vehicles, and (4) areas where local codes prohibit grounding through the neutral conductor. Prepare minimum 5 ft (1.52 m) of length in order for dryer to be replaced.
- Page 34 Electrical requirements 3-wire connection : Direct wire Important! Grounding through the neutral conductor is prohibited for (1) new branch-circuit installations, (2) mobile homes, (3) recreational vehicles, and (4)areas where local codes prohibit grounding through the neutral conductor. Prepare minimum 5 ft (1.52 m) of length in order for dryer to be replaced.
-
Page 35: Option 1: 4-Wire Connection With A Power Supply Cord
Electrical requirements Option 1: 4-wire connection with a power supply cord • lf your local codes or ordinances do not allow the use of a 3-wire connection, or you are installing your dryer in a mobile home, you must use a 4-wire connection. 1. -
Page 36: Option 3: Optional 3-Wire Connection
Electrical requirements Option 2: 3-Wire connection with a power supply cord lf your local codes or ordinances permit the connection of a frame-grounding conductor to the neutral wire, use these instructions. If your local codes or ordinances do not allow the connection of a frame-grounding conductor to the neutral wire, use the instructions under Section 1: Optional 3- wire... - Page 37 Electrical requirements The following are important instructions and information concerning the exhaust requirements for your dryer. Important Warning! To reduce the risk of fire, electric shock, or injury to person, read the IMPORTANT SAFETY INSTRUCTIONS before operating this appliance. To reduce the risk of fire, combustion, or accumulation of combustible gases, DO NOT exhaust dryer air into an enclosed and unventilated area, such as an attic, wall, ceiling, crawl space, chimney, gas vent, or concealed space of a building.
-
Page 38: User-Maintenance Instructions
User-maintenance instructions Exhaust requirements and instructions: 1. Venting materials are not provided with the dryer and you should obtain the necessary venting materials. For example, the outer end of exhaust pipe must have a weather hood with hinged dampers to prevent back draft when the dryer is not in use. -
Page 39: Exhaust Requirements And Maintenance
Exhaust requirements and maintenance Cleaning the lint screen 1. Clean the lint filter once either before or after drying each load. Always make sure the lint filter is clean before starting a new load, because a clogged lint filter may increase drying times. -
Page 40: Reversing The Door
Reversing the door Door hanging The tumble dryer come with the door hinged on the right. However, it is possible to change the door to be hinged on the left. Following these instructions: 1. Open the door and remove the two bolts holding the hinge. -
Page 41: Quick Guide
Quick guide Sort your Fabrics • Dry fabrics of the same type together to ensure they dry as evenly as possible. Turn on the main power button Open the door, load the items and then close the door Select a program •...
