- Page 1 FT-TSC600 FlipTop™ Touch Screen Control System Supplemental Guide Crestron Electronics, Inc.
- Page 2 Microsoft Corporation in the United States and/or other countries. Other trademarks, registered trademarks, and trade names may be used in this document to refer to either the entities claiming the marks and names or their products. Crestron disclaims any proprietary interest in the marks and names of others.
-
Page 3: Table Of Contents
Contents Access the Setup Screens Configure the FT-TSC600 Ethernet Setup ......................2 Edit the Hostname ..................3 Edit the IP Address ..................3 Edit Additional Ethernet Parameters ............4 Edit the Advanced Settings ................ 4 Edit the Ethernet Diagnostics ..............6 Edit the MyCrestron Dynamic DNS Settings .......... -
Page 5: Access The Setup Screens
Control System Access the Setup Screens The FT-TSC600 Setup screen is the starting point for configuring the TF-TSC600 FlipTop™ Touch Screen Control System from Crestron ® NOTE: If no project has been loaded or if an invalid project has been loaded, the screen displays the following message: “There is no display project to start. -
Page 6: Configure The Ft-Tsc600
The FT-TSC600 Setup screen is displayed. FT-TSC600 Setup Screen The FT-TSC600 Setup screen is comprised of buttons for Ethernet setup, audio setup, display setup, application setup, standby timeout, and diagnostics. In addition, there is an About button that provides information about the touch screen and a Save & Exit button. The functions of each are detailed in the following pages of this guide. -
Page 7: Edit The Hostname
Edit the Hostname To edit the hostname, tap Edit. The Edit Hostname screen opens. Edit Hostname Screen Use the keyboard to enter the new name. Tap Clear to clear a previous entry, Save to save a new entry, or Cancel to return to the previous screen. Edit the IP Address To edit the IP address, tap Edit. -
Page 8: Edit Additional Ethernet Parameters
Edit Additional Ethernet Parameters Tap the ellipsis (…) at the top of the Ethernet Setup screen to display additional Ethernet parameters and the controls that allow their entry. Ethernet Setup Screen (Additional Parameters) To edit the subnet mask, default router, or domain, tap the corresponding Edit button and use the keyboard to enter the new information. - Page 9 For more details on SSL settings, refer to the 3-Series Control Systems Reference ® Guide (Doc. 7150) at www.crestron.com/manuals. To edit the CIP port, secure CIP port, CTP port, or secure CTP port, tap the corresponding Edit button and use the keyboard to enter the new information.
-
Page 10: Edit The Ethernet Diagnostics
The Ethernet Diagnostics screen provides controls for verifying connections. Tap Ping Default Router to verify connection to the router. (The screen displays a “Passed” message to show successful connection.) Tap Ping Crestron.com to verify connection to an external DNS server. -
Page 11: Edit The Mycrestron Dynamic Dns Settings
® www.mycrestron.com and register a system with Crestron. With the information provided from the MyCrestron home page, complete the information on the MyCrestron Dynamic DNS Setup screen. To enter the domain and password, tap Edit. Then, tap Register This System. -
Page 12: Display Setup
Display Setup On the FT-TSC600 Setup screen, tap Display Setup to enter the Display Setup screen. Display Setup Screen The Display Setup screen provides controls to adjust the screen’s LCD brightness. Application Setup On the FT-TSC600 Setup screen, tap Application Setup to display the Application Setup screen. -
Page 13: Standby Timeout
Standby Timeout On the FT-TSC600 Setup screen, tap Standby Timeout to display the Standby Timeout screen. Standby Timeout Screen The Standby Timeout screen provides controls to adjust standby timeout from 0 to 120 minutes. Diagnostics On the FT-TSC600 Setup screen, tap Diagnostics to display the Diagnostics screen. Diagnostics Screen The Diagnostics screen displays the available memory and contains controls to show hardware configurations, show Cresnet... -
Page 14: Keypad Test
Keypad Test On the Diagnostics screen, tap Keypad Test to display the Diagnostic – Keypad Test screen. Diagnostic – Keypad Test Screen The Diagnostic – Keypad Test screen can be used to test the function of the hard keys. When a hard key is pressed, its corresponding indicator on the screen lights. Touch Test On the Diagnostics screen, tap Touch Test to display the touch test screen. -
Page 15: Rava
On the Diagnostics screen, tap RAVA to display the Diagnostics – RAVA screen. Diagnostics – RAVA Screen The Diagnostics - Rava screen provides controls for testing the use of Crestron’s Rava ® SIP Intercom with the FT-TSC600. It can be used to test projects and settings. If the intercom works but the project does not, there is an issue with the project;... -
Page 16: About
About On the FT-TSC600 Setup screen, tap About to display the About screen. About Screen The About screen displays information about the firmware in the unit. Tap Show Details to display more information. About Screen (Details) Save & Edit On the FT-TSC600 Setup screen, tap Save & Exit to save all settings, exit the setup screens, and return to the main project. - Page 17 This page is intentionally left blank. FT-TSC600: FlipTop Touch Screen Control System • 13 Supplemental Guide – DOC. 7593C...
- Page 18 Crestron Electronics, Inc. Supplemental Guide – DOC. 7593C 15 Volvo Drive Rockleigh, NJ 07647 (2038115) Tel: 888.CRESTRON 04.15 Fax: 201.767.7576 Specifications subject to www.crestron.com change without notice.
