Ier 577 Quick Reference Manual

IER 577 Printer Quick Reference Guide
1. GENERAL PRINTER DESCRIPTION
Print head Top cover
module
Burster
module
Magnetic module
pressure plate
Triple feeder
module
Cabinet
Side cover
Stock 3
Stock 2
Stock 1
Secured output
Folding door
stacker
Control
panel
Front panel
Diskette
drive
AC power
Ready/Receive
Resume/Escape
Profile 1
N00302A IER 577 Printer Quick Reference Guide
Powering up the Printer
a) Set the power switch to the I-position (I=Power ON/O=Power OFF).
b) At the end of printer initialization, the display shows:
On line
xxxxxx
If a different message is displayed, refer to the Error and
Information Message Section.
Printing the Status Coupon
a) Press the On line/Menu key to access the main menu (Menu
mode). The display shows:
b) Press the Enter key to confirm. The display shows:
c) Use the Up and Down arrow keys to select
the desired bin x (1, 2 or 3).
d) Press Enter to confirm.
printed.
Inserting a Coupon through the Front Feed
Slot (Option)
a) Initiate coupon printing from the host.
b) The
rapidly.
c) Insert the coupon as shown.
d) The coupon is printed and output into the
secured stacker at the front of the printer.
e) If the size of the coupon is not compatible, it
is rejected through the front insertion slot.
a) Power up the printer. If the Load Stock In bin 1 2 3 message is dis-
played,
switch
appropriate stock into
the bin that is out of
stock.
b) Read the instructions on
the stock box before
opening
On line/Menu
proper orientation.
c) Insert the staple stub of
the top coupon into the
Software load
Enter
appropriate
Preprinted
on the stock will appear
Profile 4
'upside down' when it is
Profile 3
Profile 2
oriented correctly in the
printer.
Revision Level 1
April 5, 2000
2. OPERATION
Note: The second line of the display message
(xxxxxx) specifies the current
configuration (Profile 1, 2, 3 or 4).
Print Status Coupon
Print Status Coupon
From bin x
The coupon is
Ready/Receive indicator flashes
3. LOADING COUPON STOCK
reload the
Printable
side
to assure
feeder.
information
Revision Level 1
N00302A IER 577 Printer Quick Reference Guide
4. CLEARING COUPON JAMS
If a paper jam error message is displayed (see Error Message Section),
leave the printer powered up and try to remove the coupon by pressing
the Resume/Escape key. If this does not work, proceed as follows:
a) To remove the jammed coupon from the paper path, unlock and
open the magnetic module pressure plate, print head module
printer and/or front panel to access and remove the jammed coupon.
b) For jams in the triple feeder
module, open the folding door of
the cabinet, grasp the coupon
and carefully pull it out from the
bottom of the feeder assembly.
c) If the coupon cannot be removed
from the bottom of the triple
feeder, raise the
module pressure
remove it from there.
We recommend that you feed the
coupon (see arrow 1) with your
finger either up to the magnetic
module pressure plate or down to
the cabinet to remove it more
easily.
d) Close and lock the magnetic module pressure plate by pressing the
button marked PUSH.
e) After the jam is cleared, close
and lock all paper path module
covers, side cover, top cover and
folding door, then press the
Resume/Escape key to resume
printing.
Back-
side
April 5, 2000
N00302A
1
magnetic
plate and
Revision Level 1
April 5, 2000
