LASER CLEAN HEATING SYSTEM/VENTED HEATER

INSTALLATION AND OPERATION INSTRUCTIONS

LASER CLEAN VENTED
Laser 300
MODEL
( Type A )
IMPORTANT
READ AND UNDERSTAND INSTRUCTIONS BEFORE INSTALLING OR USING HEATER.
RETAIN INSTRUCTIONS FOR FUTURE REFERENCE. CHECK LOCAL CODES AND ORDINANCES FOR PERMITTED USE.
················································ 2
·············································· 3
···················································· 5
··········································· 9
················································· 10
································ 4
················· 6
···································· 15
···································· 16
CONTENTS
························································ 33
·············································· 8
·········································· 9
······················ 20
························· 20
········································ 22
·························· 25
··············· 26
······················· 32

Advertisement

Table of Contents
loading

Summary of Contents for Toyostove Laser 300 A

  • Page 1: Table Of Contents

    LASER CLEAN HEATING SYSTEM/VENTED HEATER INSTALLATION AND OPERATION INSTRUCTIONS LASER CLEAN VENTED Laser 300 MODEL ( Type A ) IMPORTANT READ AND UNDERSTAND INSTRUCTIONS BEFORE INSTALLING OR USING HEATER. RETAIN INSTRUCTIONS FOR FUTURE REFERENCE. CHECK LOCAL CODES AND ORDINANCES FOR PERMITTED USE. CONTENTS SECTION A: SECTION G:...
  • Page 2: Section A

    SECTION A: SPECIFICATIONS Model: Laser 300 Heater Efficiency: 92.4% (1) Heat Rating: High - 15,000 BTU/h Med - 10,100 BTU/h Low - 5,310 BTU/h Fuel Consumption: High - 0.108 gal/h (0.409 L/h) Med - 0.076 gal/h (0.288 L/h) Low - 0.040 gal/h (0.151 L/h) Fuel System: External tank (2) Fuel Type:...
  • Page 3: Safety Features

    SAFETY FEATURES Your Laser 300 is equipped with the following safety features. Please familiarize yourself with these features. When your heater is extinguished due to a safety mechanism, be sure to identify and correct the problem. Heat shield plate Circulation fan Overheat protector Heat exchanger Peep hole...
  • Page 4: Section B

    SECTION B: SAFETY TIPS FOR OPERATION CAUTION: Heater and vent pipe system must be properly installed before operation. Please follow instructions under “Installation”, Section I. Never use any fuel other than clear or red colored kerosene (ASTM D3699 1-K RIGHT WRONG Kerosene, ASTM D396 Low Sulfur No.1 Fuel Oil, ASTM D975 Ultra Low Sulfur Diesel (ULSD), or Ultra Low Sulfur Heating Oil (ULSHO)).
  • Page 5: Section C

    FUEL GUIDE The Toyostove Laser 300 is designed for use with ASTM D3699 1-K kerosene, ASTM D396 Low Sulfur No.1 Fuel Oil, ASTM D975 Ultra Low Sulfur Diesel (ULSD), or Ultra Low Sulfur Heating Oil (ULSHO). Use of low-quality fuel will cause burner performance to drop, leading to abnormal combustion and reduced heater life.
  • Page 6: Section D

    SECTION D: OPERATING CONTROLS AND PART NAMES Before using heater, familiarize yourself with the following operating controls and names. Ciraulation air filter 17. Circuration fan Control panel Circulation fan motor Rear cover (upper) Rear cover (left) Front panel Rear cover (right) 18.
  • Page 7 1. ON/OFF button: Main button turns heater on and off. When switched on, heater begins operation and combustion starts after preheat period. 2. AUTO button: The button turns weekly timer operation modes on and off which have been programmed into weekly timer. 3.
  • Page 8 REF # PART # PART NAME REF # PART # PART NAME REF # PART # PART NAME 2 0 4 7 0 2 2 7 Front panel assembly 2 0 4 7 4 0 8 3 Fuel nozzle gasket 2 0 4 7 4 0 5 3 Screw F 2 0 4 7 0 8 2 7...
  • Page 9: Section E

    SECTION E: OPERATION BEFORE IGNITION 1. Open the Valve(s) Open the valve(s) of the external fuel tank. 2. Start the Fuel flow If using heater for the first time, press the red reset button in order to send fuel to Red reset button the fuel sump and release.
  • Page 10: Operation

    3) Setting of a day of the week “dAy” sign is shown on the display and all of days of the week will blink. Press the “▲MIN.” button or the “▼HOUR” button to set a day of the week. A day of the week will blink. (Initial setting is “SUN”.) The other days of the week will go off.
  • Page 11 2. Adjusting Room Temperature A. Press “HOUR” or “MIN.” button. ˚F or ˚C will start to flash. Note: “HOUR” or “MIN.” button will change the temperature in increment of 2˚F (1˚C). B. Press “MIN.” for up and “HOUR” for down. Room temperature can be set from 50˚F (10˚C) to 90°F (32˚C). (Initial setting : 56˚F (13˚C)) C.
  • Page 12 Approx. +10˚F Approx. +1˚F TEMP. High Medium Re-lgnition CHILD LOCK OPERATION Press the CHILD LOCK (CLEAR) button for more than 3 seconds to set the child lock while in operation or not in operation. “CHILD LOCK” sign will be shown on the digital indicator. If the ON/OFF Switch is pressed while the Child Lock is on while in not operation, you can hear the beep sound, but the unit does not start.
  • Page 13: Weekly Timer Operation

    WEEKLY TIMER OPERATION 1. Set the Weekly Timer Note: The following programs are set at the factory in advance. Program # Clock Time Temp. AM 6:00 68˚F (20˚C) “MON” “TUE” “WED” “THU” “FRI” AM 8:30 62˚F (16˚C) “MON” “TUE” “WED” “THU” “FRI” PM 5:00 68˚F (20˚C) “MON”...
  • Page 14 2) Set the timer The timer is shown on the display. (In the case that the timer time is not set, dashes are shown on the display.) Press the “▲MIN.” button or the “▼HOUR” button to set timer time. “AM 12:00” will be shown on the display. (The all signs except the colon will blink.) When pressing the “▼HOUR”...
  • Page 15: Turning Heater Off

    2. Activate Weekly Timer Operation During operation (in ON position), press the “AUTO” button to turn on the weekly timer operation mode. However, if no program are set, you will hear the beep sound and cannot turn on the weekly timer operation mode. Press the “▲MIN.” button or the “▼HOUR”...
  • Page 16: Section F

    SECTION F: ROUTINE MAINTENANCE CAUTION: Be sure to turn off and unplug heater before performing any checks or cleaning. CAUTION: Allow heater to cool completely before cleaning or maintenance. FOR OPTIMUM HEATER PERFORMANCE, THE PARTS SHOWN BELOW SHOULD BE CLEANED REGULARLY: Ciraulation air filter Louver Fuel strainer...
  • Page 17 Please ask your authorized Toyostove dealer for details and scheduling. When using Ultra Low Sulfur Diesel (ULSD) or Ultra Low Sulfur Heating Oil the heater should be serviced at least every two years because the distillation of ULSHO is heavier than 1-K Kerosene and No.
  • Page 18: Section G

    SECTION G: TROUBLESHOOTING NOTE BEFORE REQUESTING FOR REPAIR AND SERVICES The following symptoms are normal during operation of the heater. CONDITION REASON White smoke or smell at initial use after Machine oil or dust burns off of the surfaces the purchase.
  • Page 19: Section H

    SECTION H: LONG TERM STORAGE At the end of each heating season, or when you do not plan to use your heater for an extended period, the following procedures are recommended. As the end of the season approaches, calculate your fuel purchases so that you can use up all the fuel you have on hand.
  • Page 20: Section I

    STANDARD INSTALLATION PARTS The following standard installation parts are enclosed with heater. For alternate installation methods, you may need to purchase additional accessories which are available from your TOYOSTOVE dealer. See “Accessory Parts”, page 22. Wall Brackets (2 sets) (PART #20479562)
  • Page 21 15-3/4” Flue Pipe (1) (PART #20479891) Exhaust Air Cap (1) (PART #20479845) Intake Air Cap (1) (PART #20474949) Screw 4G (3) (PART #20474985) Inlet Hose (1) (PART #20470261) 8-1/4” Bent Joint (1) (PART #20479584) L-Shaped Hose (2) (PART #20474975) Oil Catch (1) (PART #20474925) Hose Band (2) (PART #20474977) 10-5/8”...
  • Page 22: Accessary Parts

    The following accessory parts are available for use in non-standard installation of the Laser 300. After giving careful consideration to your desired heater and flue pipe locations and fueling system, consult your TOYOSTOVE dealer to purchase the necessary accessory parts.
  • Page 23 EXTENSION KIT Extension Pipe Kit (L) PART #20479898 INSTALLATION WITH EXTENSION PIPE KIT (L) Max. 39- ~ Min. 22- inch (# 20479861) (# 20474963) (# 20479853) (# 20474950) inch Pipe Support Hardware (# 20479872) Pipe Holder (2 pcs.) 80 inch Adjustable Exhaust Pipe Intake Hose...
  • Page 24 Extension Pipe Kit (M) PART #20479897 Extension Pipe Kit (S) PART #20479896 Max. 39- ~ Min. 22- inch Max. 19- ~ Min. 12- inch (# 20479861) (# 20474963) (# 20479861) (# 20474963) (# 20479853) (# 20479858) (# 20474950) (# 20474950) Pipe Support Hardware Pipe Support Hardware 40 inch...
  • Page 25: Safety Tips For Installation

    SAFETY TIPS FOR INSTALLATION SAFETY TIPS FOR INSTALLATION Follow the safety tips below when planning the installation of your Laser 300. Intake and exhaust flue pipe openings must be fully exposed to outside air. Do not vent into chimney, garage, basement under the floor, or into any enclosed area. Do not install flue pipe in close proximity to other objects or materials (See page 26).
  • Page 26: Installation Of Heater And Flue Pipe

    INSTALLATION OF HEATER AND FLUE PIPE IMPORTANT: Check and comply with all state and local codes that may apply to vented heaters before beginning installation. NOTE: This heater is designed to be used at altitudes up to 3,000 ft. above sea level. For use at altitudes higher than 3,000 FT.
  • Page 27 For standard installation, use the template enclosed with the heater to position the hole for the flue pipe. Tack or tape template to the wall at the desired position (See Fig. 4). Tape Fig. 4 NOTE: Heater should be installed on a sturdy floor that is level and flat. Cut the hole for the flue pipe from inside the room.
  • Page 28 Install the inner flue pipe. For wall thickness 5- ” to 9” From inside the room, insert the inner flue pipe through the hole. Make sure the arrow on the inner flue pipe is pointing up. Secure the inner flue pipe to the wall with the three wood screws. (See Fig.
  • Page 29 6. Insert the bent joint to the exhaust opening of the flue pipe. Cut the inlet hose for desired length if necessary. Attach the L-shaped hose to each end of the inlet hose and attach the L-shaped hose to the intake opening of the flue pipe.
  • Page 30 Secure the L-shaped hose to the intake inlet opening with the hose band. Secure the bent joint to the standard flue pipe with the pipe holder (If the extension pipe is used, also attach the pipe holder to the connection of the bent joint and the extension pipe).
  • Page 31 A room temperature sensor is provided with approx. eight (8) feet long extension wire. It is located on the rear of the cabinet. Make sure that the extension wire is not touching the exhaust pipe. The room temperature sen- sor can be installed either with the self adhesive tape on the back or with a wood screw provided with the sen- sor depending on the type of surface chosen for installation.
  • Page 32: Permanent Wiring Installation

    Several inverter manufacturers offer true sine wave inverters which should operate the unit without any problems if properly sized and configured. If you have any questions about appropriate power supply, consult your authorized TOYOSTOVE dealer.
  • Page 33: Section J

    SECTION J: FUELING WARNING: Use only ASTM D3699 1-K kerosene, ASTM D396 Low Sulfur No.1 Fuel Oil, ASTM D975 Ultra Low Sulfur Diesel (ULSD), or Ultra Low Sulfur Heating Oil (ULSHO). NEVER USE GASOLINE. Use of gasoline can lead to uncon- trollable flames resulting in destructive fire.
  • Page 34 Outdoor fuel tank Tank vent Laser 300 Fuel filter (1) 81/2ft.maximum 16in.minimum Shut off valve Shut-off valve 3/8in.OD copper tubing NOTE: Please check local codes for permitted use. (1) 15 or less Micron Filter is recommened.
  • Page 35 CUSTOMER’S RECORD PROGRAM MANAGEMENT TABLE Monday (Tue.) Tuesday (Wed.) Wednesday (Thu.) Thursday (Fri.) Friday (Sat.) Saturday (Sun.) Sunday (Mon.) PROGRAM # TIME TEMPERATURE...
  • Page 36: Limited Warranty

    LIMITED WARRANTY TOYOTOMI U.S.A., INC.("TOYOTOMI") warrants each product and any parts thereof sold by it to be free from defects in materials or workmanship under normal use and service for TWELVE (12) MONTHS* from the date of delivery to the original purchaser at retail subject to the following terms and conditions : WHAT IS COVERED : Product or any parts thereof which are defective in materials of workmanship.
