Hunt CCTV HTC-79C User Manual

Ir color camera

Advertisement

The CAMERA HTC-79C has a CCD image Sensor and all solid-state circuitry, which provide Extremely long
life and high sensitivity.
High quality picture, aesthetic and easy to install, the HTC-79C is good complements for your line of CCTV
system.

AUTOMATIC GAIN CONTROL (AGC)

The adoption of an AUTOMATIC GAIN CONTROL (AGC) provides clear image in low light condition.
During the low light condition, the LED would automatically illuminate

ELECTRONIC IRIS

The color CCD CAMERA HTC-79C incorporates the ELECTRONIC IRIS UP to 1/100,000 sec.

GAMMA CHARACTERISTIC

The color CCD CAMERA HTC-79C incorporates of GAMMA 0.45.

CHANGEABLE LENS MOUNT

The camera HTC-79C includes a 6mm lens and we can also use the optional lens 4.3mm F2.0 lens.

SPECIFICATIONS

ITEMS
PICK UP ELEMENT
PICTURE ELEMENTS
HORIZONTAL RESOLUTION
HORIZ. SYNC. FREQUENCY
SCANNING SYSTEM
SENSITIVITY
SYNCHRIZATION
S/N RATIO
ELECTRONIC SHUTTER
GAMMA
LENS
VIDEO OUTPUT
AGC
POWER SUPPLY
POWER CONSUMPTION
DIMENSIONS
WEIGHT
gr
STORAGE TEMPERATURE
OPERATING TEMPERATURE
*SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE.

IR COLOR CAMERA

HTC-79C
HTC-79C
1/3" CCD IMAGE SENSOR
H*V
NTSC:510 * 492, PAL: 500 * 582
More than 400 TV lines
NTSC: 15.734kHz, PAL:15.625kHz
2:1 INTERNAL
0 Lux when IR LED on
INTERNAL
More than 48 dB
Auto, UP to 1/100,000 sec.
0.45
6.0mm F1.8
1 Vpp, 75 Ohms
Auto
12VDC (+/- 10%)
450mA
ψ 68 x w 103.5
mm
500
-30 to + 60 Degree C
-10 to + 45 Degree C
Version: V1.0
