1/3" color Hi Resolution
15M IR Color Camera
With Vari Focal Lens
MAIN FEATURES
This product is a CCD CAMERA and
incorporates advanced 1/3" high
performing CCD Sensor and digital
signal circuit.
PRECAUTIONS
1.
HTC-5AH2810D
installed by the assigned engineer
or the specific installer.
2.
Please DO NOT take apart the
camera. The caused damage will
not include within the warranty
condition.
HTC-5AH2810D 15M IR COLOR CAMERA
has
to
be
The main features of HTC-5AH2810D
includes high quality images Up to 520
TV Lines with Aspherical D/N Lens,
focus of lens is adjusted by External
Controller with Removable IR cut filter
and built in IR LEDs for night
application.
3.
Notice the storage and placed
position of the camera to avoid
unnecessary damage.
4.
If the camera body has to be
cleaned, please use the dry cloth.
Meanwhile, to have no alternative,
use the lens tissue with the specific
detergents to remove the dust or
dirty on the lens.
1
V1.0
Advertisement
Related Manuals for Hunt CCTV HTC-5AH2810D
Summary of Contents for Hunt CCTV HTC-5AH2810D
- Page 1 HTC-5AH2810D 15M IR COLOR CAMERA 1/3” color Hi Resolution 15M IR Color Camera With Vari Focal Lens MAIN FEATURES The main features of HTC-5AH2810D This product is a CCD CAMERA and includes high quality images Up to 520 incorporates advanced 1/3” high...
- Page 2 PACKAGE CONTENT After un-pack the case, please check the following items are contained inside. (Figure There are: The HTC-5AH2810D camera base with the shield… 1 SET (A) The camera bracket… 1 SET (D) Plastic Anchor… 3 PCS (E) Flat Head Self-Tapping Screw… 3...
- Page 3 CAMERA ADJUSTMENTS Notice: The most dramatic characteristic of HTC-5AH2810D is its external controller. Contrasted with other IR camera, which has complex adjusting procedure of lens, HTC-5AH2810D provides this convenient function (external controller) to adjust the ZOOM and FOCUS of lens easily.
- Page 4 SPECIFICATIONS ITEMS HTC-5AH2810D (External Controller) Pick Up Device 1/3” CCD Image Sensor System NTSC Picture Elements 768 × 494 752 × 582 H. Sync. Frequency 15.734KHz 15.625KHz V. Sync. Frequency 59.94Hz 50Hz Horizontal Resolution 520 TV Lines Scanning System 2:1 Interlace...
