The lightning flash with an arrowhead symbol, within an equilateral
triangle is intended to alert the user to the presence of uninsulated
dangerous voltage within the product's enclosure that may be of
sufficient magnitude to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert
the user to the presence of important operating and maintenance
(servicing) instructions in the literature accompanying the appliance.
INFORMATION - This equipment has been tested and found to comply with
limits for a Class A digital device, pursuant to part 15 of the FCC Rules & CE Rules.
These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment.
This equipment generates, uses, and can radiate radio frequency energy and, if
not installed and used in accordance with the instruction manual, may cause
harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at
his own expense.
WARNING - Changes or modifications not expressly approved by the
manufacturer could void the user's authority to operate the equipment.
CAUTION : To prevent electric shock and risk of fire hazards:
◆ Do NOT use power sources other than those specified.
◆ Do NOT expose this appliance to rain or moisture.
This installation should be made by a qualified service person and
should conform to all local codes.
1
Super DNR High Resolution Day/Night Dome Camera
Advertisement
Table of Contents
Related Manuals for Hunt CCTV HTC-T16G28D
Summary of Contents for Hunt CCTV HTC-T16G28D
- Page 1 The lightning flash with an arrowhead symbol, within an equilateral triangle is intended to alert the user to the presence of uninsulated dangerous voltage within the product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.
-
Page 2: Table Of Contents
■ Contents Features How to Use the Camera ■ Function Menu Structure Warnings and Precautions ■ How to Set up the Functions ㆍLENS Components ㆍEXPOSURE Names and Functions of Parts ㆍWHITE BALANCE control ■ Lens ㆍBACKLIGHT ■ OSD ㆍDNR (Digital Noise Reduction) ■... -
Page 3: Features
■ Features Warning ■ Ultra High Resolution The camera requires periodic inspection. Day & Night By adopting a double-speed 410,000 pixel The camera identifies whether it is day or night Contact an authorised technician to carry out the inspection. Sony CCD, the camera produces clear picture and automatically switches to the appropriate quality with a horizontal resolution of 580 TV lines mode, depending on its environment. - Page 4 ■ Precautions Do not install the camera in Do not install or use the camera in an Do not drop the camera or protect Never keep the camera pointed extreme temperature conditions. environment where the humidity is high. it from physical shocks. directly at strong light.
-
Page 5: Components
■ Components Names and Functions of Parts ■ 1. COLOR DOME CAMERA 2. SCREWS 3. WIRE FOR VBS-EXTRA 4. INSTRUCTION GUIDE Super DNR High Resolution Day/Night Dome Camera Super DNR High Resolution Day/Night Dome Camera... -
Page 6: Names And Functions Of Parts
■ Names and Functions of Parts Names and Functions of Parts ■ LENS : Vari-Focal DC Auto Iris Lens VBS-EXTRA FOR CONNECTING TO LCD ① ③ Please use the supplied wire when connecting to external monitor VBS-EXTRA 3 AXIS BRACKET ④... -
Page 7: Installation
■ Installation 1. Dome Base Mounting - Open the dome cover by loosening 3 screws using special wrench provided. - Mount the base of camera to a sturdy surface using 4 screws (1.5 inch) and 4 premade holes on the base of the dome. DECORATION RING 2. -
Page 8: Installation
How to Use the Camera ■ ■ Installation Function Menu Structure Adapter Plate Setup Menu LENS 3.5x25 tapping MANUAL • • screw (provided) SHUTTER SENS-UP • • • Camera Body EXPOSURE RETURN • MANUAL AWC SET • • • WHITE BALANCE OUTDOOR INDOOR Locking... -
Page 9: How To Set Up The Functions
■ How to Use the Camera How to Set up the Functions Settings can be made using the 5 buttons located in the camera. MAIN SETUP Select the desired menu 1. LENS Modes can be changed item by using the UP and using the LEFT and 2. - Page 10 ■ How to Use the Camera EXPOSURE ● DC : Select Auto Iris Lens MAIN SETUP • When DC is selected, you can control screen brightness. The range 1. LENS of brightness control is between 1 and 70. 2. EXPOSURE Adjust the brightness appropriately for optimal screen brightness.
- Page 11 ■ How to Use the Camera White Balance (White Bal.) Note Use the White Balance function to adjust the screen colors. • When the SHUTTER is set to ESC, and the camera is set to Internal Synchronisation, the picture may become unstable if the camera 1.
- Page 12 ■ How to Use the Camera ● BLC : Enables a user to directly select a desired area from a picture, and Note to view the area more clearly. • Under the following conditions White Balance may not work properly. In such cases, select the AWC mode.
-
Page 13: ㆍDay/Night
■ How to Use the Camera 3. Set the DNR mode to 'ON' and press the SET button. The noise reduction Note level can now be adjusted. • Because there can be a difference in the effectiveness of HLC according to the amount of light area in the screen, optimize the installation angle for the best HLC performance. -
Page 14: Image Adj
■ How to Use the Camera IMAGE ADJ. 2. Select the desired mode using the Left and Right buttons. ● COLOR : The picture is displayed in color. 1. When the SETUP menu screen is displayed, select 'IMAGE ADJ.' using ●... - Page 15 ■ How to Use the Camera SPECIAL ● D-ZOOM : Digitally zooms, the range is x1~x10. 1. When the SETUP menu screen is displayed, select 'SPECIAL' using the Up and Down buttons. MAIN SETUP 1. LENS 2. EXPOSURE 3. WHITE BAL 4.
- Page 16 ■ How to Use the Camera ⑤ Enter a title, move the cursor to 'POS' and press the SET button. The ② Set to 'ON' using the Left and Right buttons. entered title appears on the screen. Select the position to display the title on the screen using the 4 directional buttons and press the SET button.
- Page 17 ■ How to Use the Camera ① When the SPECIAL menu screen is displayed, press the Up and - MASK COLOR : Determine area color. Select Grey, Green, Red, Blue, Black or White. Down buttons so that the cursor points to MOTION DET. ②...
-
Page 18: Troubleshooting
■ Troubleshooting If you have trouble operating your camera, refer to the following table. If the guidelines do not enable you to solve the problem, contact an Problem Solution authorized technician. The Motion Detection • Check that MOTION DET in the SPECIAL SETUP Problem Solution function does not... -
Page 19: Specifications
■ Specifications NTSC AC24V / DC12V DC12V AC24V / DC12V DC12V Power Source 300mA(AC24V)/450mA(DC12V) 400mA 300mA(AC24V)/450mA(DC12V) 400mA Size SONY 1/3" Super HAD High Sensitivity Color CCD 811(H) x 508(V) 795(H) x 596(V) Total Pixels 768(H) x 494(V) 752(H) x 582(V) Effective Pixels 2:1 Interlace Scanning System... - Page 20 Modle : HTC-T16G28D Super DNR High Resolution Day/Night Dome Camera Instruction Guide Modle : HTC-T16G28D Super DNR High Resolution Day/Night Dome Camera Printed in KOREA...
