- Page 1 Network Bullet Camera Quick Operation Guide ...
- Page 2 Network Bullet Camera·Quick Operation Guide Thank you for purchasing our product. If there are any questions, or quests, please do not hesitate to contact the dealer. About This Document This manual applies to the following models. Model HNC301‐XB HNC303‐XB This manual may contain several technical incorrect places or printing errors, and the content is subject to change without notice. The updates will be added to the new version of this manual. We will readily improve or update the products or procedures described in the manual. DISCLAIMER STATEMENT “Underwriters Laboratories Inc. (“UL”) has not tested the performance or reliability of the security or signaling aspects of this product. UL has only tested for fire, shock or casualty hazards as outlined in UL’s Standard(s) for Safety, UL60950‐1. UL Certification does not cover the performance or reliability of the security or signaling aspects of this product. UL MAKES NO REPRESENTATIONS, WARRANTIES OR CERTIFICATIONS WHATSOEVER REGARDING THE PERFORMANCE OR RELIABILITY OF ANY SECURITY OR SIGNALING RELATED FUNCTIONS OF THIS PRODUCT. 0501001031101 ...
- Page 3 Network Bullet Camera·Quick Operation Guide Regulatory Information FCC Information FCC compliance: This eq uipment has been tested and found to comply with the limits for a digital device, purs uant to part 15 of the FCC Rules. These limits are des igned to p rovide reasonable protection against harmful inte rference when the equipment is operated in a commercial en vironment. Th is equipment generates, uses, and can radiate radio f requency ener gy and, if not installed and used in accordance with the in struction m anual, may cause harmful interference to radio communications. Operation of this equipm ent in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense. FCC Conditions This device complies with pa rt 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference. 2. This device must accept any interference received, including interference that may cause undesired operation. EU Conformity Statement This product and ‐ if applicable ‐ the supplied accessories too are marked with "CE" and comply therefore with the applicab le harmonized European ...
- Page 4 Network Bullet Camera·Quick Operation Guide 2012/19/EU (W EEE directive): Products marked h this symbol cannot be disposed of as unsorted municipal waste in the European Union. For pro per recycling, return this product to your local supplier upon the purchase of equivalent new equipment, or dispose of it at designated collection points. For more informa tion see: www.recyclethis.info. 2006/66/EC (battery directive): This product contains a battery that cannot be disposed of as unsorted municipal waste in the European Union. See the product documentation for specific battery information. The battery is marked with this symbol, which may include lettering to indicate cadmium (Cd), lead (Pb), or mercury (Hg). Fo r proper recycling, return the battery to your supplier or to a designated collection point. For more informatio n see: www.recyclethis.info ...
- Page 5 Network Bullet Camera∙Quick Operation Guide Safety Instru ction These instruction s are intended to ensure that user can use the product correctl y to avoid danger or property loss. The precaution m easure is divided into “Warnings” and “Cautions” Warnings: Serious injury or death may occur if any of the warnings are neglected. Cautions: Injury or equipment damage may occur if any of the cautions are negl ected. Warnings Follow these Cautions Follow these safeguards to prevent precautions to prevent potential injury or material serious injury or death. damage. Warnings In the use of the product, you must be in strict compliance with the electrical safety regulations of the nation and region. Please refer to technical specifications for detailed information. Input voltage should meet both the SELV (Safety Extra Low Voltage) and the Limited Power Source with 24 VAC or 12 VDC according to the IEC60950‐1 standard. Please refer to technical specifications for detailed information. ...
- Page 6 Network Bullet Camera∙Quick Operation Guide Do not connect seve ral devices to one power adapter as adapter overload may cause over‐heating or a fire hazard. Please make sure that the plug is firmly connected to the power socket. When the product is mounted on wall or ceiling, the device shall be firmly fixed. If smoke, o dor or noise rise from the device, turn off the power at once and unplug the power cable, and then please conta ct the service center. Cautions Make sure the p ower supply voltage is correct be re using the camera. Do not drop the camera or s ubject it to physical shoc k. Do not touch sensor mo dule s with fingers. If cleaning is necessary, use clean cloth w ith a bit of et hanol and wipe it gently. If the camera will not be used for an extended period, please replace the lens cap to protect the sensor from dirt. not aim the ca mera at the sun or extra bright places. Blooming or smearing may occur otherwise (which is not a malfunction), and affect the endurance of sensor at the same time. ...
- Page 7 Network Bullet Camera∙Quick Operation Guide Do not place the camera in extremely hot, cold (the opera ting temperature shall be‐30 ~+60 ,or ‐40°C ~ 60°C if the cam era model has an “H” in its suffix), dusty or damp locations, and do not expose it to high electromagnetic radiation. To avoid heat accumulation, good ventilation is required for operating environment. Keep the camera away from liquid while in use. While in delivery, the camera shall be packed in its original packing, or packing of the same texture. ar part re acement: a few parts (e.g. electrolytic capaci tor) of the equipment shall be replaced regularly according to their average enduring time. The average time varies because of differences between operating environment and using history, so regular checking is recommended for all the users. Please contact with your dealer for more deta ils. Improper use or replacement of the battery may result in hazard of explosion. Replace with the same or equivalent type only. Dispose of used batteries according to the instructions provided by the battery manufacturer. If the product does not work properly, please contact your dealer or the nearest service center. Never attempt to disassemble the camera yourself. (We shall not assume any respon sibility for problems caused by unauthorized repair or maintenance.) ...
- Page 8 Network Bullet Camera∙Quick Operation Guide Table of Contents 1 Appearance Description ............... 2 Installation ................... 9 3 Setting the Network Camera over the LAN ......... 13 4 Accessing via Web Browser ............ 18 ...
-
Page 9: Appearance Description
Network Bullet Camera∙Quick Operation Guide 1 Appearance Description Figure 1‐1 Bullet Camera Overview Table 1‐1 Description No. Description 1 Lens 2 IR LED 3 Sun Shield 4 Adjusting Screw 5 Network Cable 6 Power Cable ... -
Page 10: Installation
Network Bullet Camera∙Quick Operation Guide 2 Installation Before you start: Make sure the device in the package is in good condition and all the assembly parts are included. Make sure all the related equipment is power‐off during the installation. Check the specification of the products for the installation environment. Make sure the power supply is matched with your required voltage to avoid damage. If the pr oduct does not function properly, pl ease contact your dealer or the nearest service center. Do not disassemble the camera for repair or maintenance by yourself. Make sur e tha t the wall is strong enough to with stand three times the weigh t of the camera. era u are require For the cam that supports IR, yo d to pay attention to the followin g pr ecautions to pre vent IR reflection: Dust or grease on the dome cover will cause ... - Page 11 Network Bullet Camera∙Quick Operation Guide Make sure that there is no reflective surface too close to the camera lens. The IR light from the camera may reflect back into the lens causing reflection. The foam ring around the lens must be seated flush against the inner surface of the bubble to isolate the lens from the IR LEDS. Fasten the dome cover to came ra body so that the foam ring and the dome cover are attached seamlessly. Steps: 1. Drill the cable hole and the screw hole in the ceiling according to the supplied dr ill template. Ceiling Mounting 1:Screw Hole for 2:Screw Hole for Bracket Mounting Base Figure 2‐1 The Drill Template 2. Hammer the supplied plastic expansion bolt into the screw ho les. 3. Route the cables to the cable hole and connect the corresponding power cable and video cable 4. Fix the camera to the wall with the supplied screws ...
- Page 12 Network Bullet Camera∙Quick Operation Guide Adjusting Screw Figure 2‐2 Fix the Camera to the Ceiling 5. Adjust the surveillance angle. 1). Loosen No.1 adjusting screw to adjust the panning position [0° ~ 360°]. 2). Tighten No.1 adjusting screw. 3). Loosen the No.2 adjusting screw to adjust the tilting position [0° ~ 100°]. 4). Tighten No.2 adjusting screw. Loosen No.3 adjusting screw to adjust the a zimuth angle [0° ~ 360°]. 6). Tighten No.3 adjusting screw. ...
- Page 13 Network Bullet Camera∙Quick Operation Guide Figure 2‐3 3‐axis Adjustment ...
-
Page 14: Setting The Network Camera Over The Lan
Network Bullet Camera∙Quick Operation Guide 3 Setting the Network Camera over the LAN Purpose: To view and configure the camera via LAN (Local Area Network), you need to connect the network camera in the same subnet with your PC. Then, install the SADP or PCNVR software to search and change the IP of network camera. The following figure shows the cable connection of network mera and PC: Figure 3‐1 Wiring over LAN Set the IP address of the camera for accessing via LAN. Steps: To get the IP address, you can choose either of the following methods: Use SADP, a software tool which can automatically detect network camera in the LAN and list the device information like IP address, subnet mask, port number, device serial number, device version, etc., shown in 0. ... - Page 15 Network Bullet Camera∙Quick Operation Guide Use PCNVR software and to list the online devices. Please refer to the user manual of PCNVR client software for detailed inform ation. 2. Change the IP address and subnet mask to the same subnet as of your PC. Refer to the following introductions to set IP address with SADP software: Search active devices online Search online device s automatically: After launch the SADP software, it automatically searches the online devices every 15 seconds from the subnet where your computer locates. It displays the total number and information of the searched devices in the Online Devices interface. Device information including the device type, IP address, port number, gateway, etc. will be displayed. ...
- Page 16 Network Bullet Camera∙Quick Operation Guide Figure 3‐2 Search Online Devices Device can be searched and displayed in the list in 15 seconds after it goes online; it will be removed from the list in 45 seconds after it goes offline. Search online devices manually: You can also click to refresh the online device list manually. The newly searched devices will be added to the list. ...
- Page 17 Network Bullet Camera∙Quick Operation Guide You can click on each column heading to order the informat ion; can c lick to show the device table and hide the netwo k para ter panel on the right side, or click sho w the ne ork par ameter panel. Modify device information Steps: 1). Select the device to be modified in the device list as shown in Figure 3‐3. The network parameters of the device will be displayed in the Modify Network Paramete rs panel on the right side as shown in Figure 3‐4. Edit the modifiable network parameters, e.g. IP address and port number. Enter the password of the admin account of the device in the assword field and click Save to save the changes. ...
- Page 18 Network Bullet Camera∙Quick Operation Guide Figure 3‐4 Modify Network Parameters 3. Enter the IP addr ess of network camera in the address field of the web browser to view the live video. The default value of the IP address is “192.0.0.64”. The default user name is “admin”, and password is “12345”. For accessing the network camera from different subnets, please set the gateway for the network camera after you log in. ...
-
Page 19: Accessing Via Web Browser
Network Bullet Camera∙Quick Operation Guide 4 Accessing via Web Browser System Requirement: Operating System: Microsoft Windows XP SP1 and above version / Vista / Win7 / Server 2003 / Server 2008 32bits CPU: Intel Pentium IV 3.0 GHz or higher RAM: 1G or higher Display: 1024×768 resolution or higher Web Browser: Internet Explorer 6.0 and above version, Apple Safari 5.02 and above version, Mozilla Firefox 3.5 and above version and Google Chrome8 and above version Steps: 1. Open the web browser. 2. In the browser address bar, input the IP address of the network camera, e.g., 192.0.0.64 and press the Enter key to enter the login interface. 3. Input the user name and password. Click Login. ... - Page 20 Network Bullet Camera∙Quick Operation Guide Figure 4‐1 Login Interface 5. Inst all the plug‐in before viewing the live video and managing the camera. Please follow the installation prompts to install the plug‐in. You may have to close the web browser to finish the installation of the plug‐in. ...
- Page 21 Network Bullet Camera∙Quick Operation Guide Figure 4‐2 Download Plug‐in Figure 4‐3 Install Plug‐in (1) ...
- Page 22 Network Bullet Camera∙Quick Operation Guide Figure 4‐4 Install Plug‐in (2) 6. Re open the web browser after the installation of the plug‐in and repeat steps 2‐4 to login. For detailed instructions of further configuration, please refer to the user manual of network camera. ...
- Page 23 Network Bullet Camera a∙Quick Operation Guide ...
