User Guide – HX400 Series
Professional compact handheld transceivers
Common Information
HX402/412/422/482(U)
HX402S/412S/422S/482S(U)
HX403/413/423/483(U)
HX405/415/425/485(U)
Advanced Selcall, 8-key
HX406/416/426/486(U)
Advanced Selcall, Full Keypad
v11/09
(all models)
Entry
Entry Selcall
Entry Display
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Entel HX402 HX422
Summary of Contents for Entel HX402 HX422
- Page 1 User Guide – HX400 Series v11/09 Professional compact handheld transceivers Common Information (all models) HX402/412/422/482(U) Entry HX402S/412S/422S/482S(U) Entry Selcall HX403/413/423/483(U) Entry Display HX405/415/425/485(U) Advanced Selcall, 8-key HX406/416/426/486(U) Advanced Selcall, Full Keypad...
-
Page 2: Table Of Contents
Introduction This guide covers the ‘basics’ of your radio’s operation. To meet your exact requirements the radio may have been customised by your Entel authorised dealer. These features will be explained in a separate guide issued by the dealer. Table of Contents... -
Page 3: Certification
CE Compliance Statement The HX400 series transceiver displays "CE" on the serial number label, indicating its compliance with the essential requirements of the EEC directive for Electromagnetic Compatibility. Declaration Of Conformity We Entel UK Limited 320 Centennial Avenue Centennial Park Elstree Borehamwood... -
Page 4: Radio / Battery Care
In aircraft, medical institutions or near persons known to be wearing a pacemaker Battery Care Introduction Battery Pack Precautions • Your Entel radio is supplied with a high Switch the transceiver OFF before performance Lithium-Ion (Li-Ion) battery. charging • These batteries: Charge the battery pack before use •... -
Page 5: Battery Care / Information
(around 0°C) part charged. Do not fully discharge the battery before storage. • Note: only genuine Entel batteries should be Each charge cycle reduces the battery’s life. used. Only genuine batteries offer the battery Minimise the number of times you charge... -
Page 6: Packing List
Packing List • HX4XX Radio • CNB450E Rechargeable 1800mAh Li-Ion battery • CBH450 Spring loaded belt clip • CATXXX Antenna • User guide CD • CSAHX Intelligent rapid charger (only supplied with HX4X2, HX4X2S & HX4X3 models) Optional Accessories Battery & Charger Options CNB450E Spare 1800mAh Lithium-Ion battery pack with rear clip CSAHX... -
Page 7: Preparing Your Radio For Use 6
CAT410S 66-88MHz uncut compressed antenna CAT400-40 30-50MHz antenna For complete up to date list of optional accessories visit www.entel.co.uk Preparing Your Radio For Use Attaching / Removing The Battery Pack To attach, locate the pegs on the bottom of the battery and place into the slots on the radio. - Page 8 Preparing Your Radio For Use cont... Attaching / Removing the Aerial To attach, carefully align the aerial with the socket. Screw in the aerial clockwise (taking care not to cross the thread) until it is seated firmly against the top of the radio. To remove, unscrew the aerial anti-clockwise.
- Page 9 HX402/412/422/482(U) Standard Features: • 16 programmable channels • Full transmit power output (5 Watts VHF, 4 Watts UHF) • CTCSS & DCS (analogue & digital squelch) with squelch tail elimination (removes the ‘shh’ noise) • Exceptionally loud and clear audio •...
