- Page 1 User Guide – HX400 Series v10/10 Professional compact handheld transceivers Common Information (all models) HX402/412/422/482(U) Entry HX402S/412S/422S/482S(U) Entry Selcall HX403/413/423/483(U) Entry Display HX405/415/425/485(U) Advanced Selcall, 8-key HX406/416/426/486(U) Advanced Selcall, Full Keypad...
-
Page 2: Table Of Contents
Introduction This guide covers the ‘basics’ of your radio’s operation. To meet your exact requirements the radio may have been customised by your Entel authorised dealer. These features will be explained in a separate guide issued by the dealer. Table of Contents... -
Page 3: Certification
Certification Declaration of Conformity We Entel UK Limited of: 320 Centennial Avenue Centennial Park Elstree Borehamwood Hertfordshire WD6 3TJ United Kingdom Declares under our sole responsibility that the product range: HX400 VHF/UHF Handheld Radio Transceiver Conforms to the following standards or other nominative docum ents: •... -
Page 4: Radio / Battery Care
End of Life Disposal Warning Turn the transceiver off in the following locations: • When your Entel transceiver reaches the end of its useful life, please ensure that the unit is • In explosive atmospheres (flammable gas, dust disposed of in an environmentally friendly way. -
Page 5: Battery Care / Information
(around 0°C) part charged. Do not fully discharge the battery before storage. • Note: only genuine Entel batteries should be Each charge cycle reduces the battery’s life. used. Only genuine batteries offer the battery Minimise the number of times you charge... -
Page 6: Packing List
Packing List • HX4XX Radio • CNB450E Rechargeable 1800mAh Li-Ion battery • CBH450 Spring loaded belt clip • CATXXX Antenna • User guide CD • CSAHX Intelligent rapid charger (only supplied with HX4X2, HX4X2S & HX4X3 models) Optional Accessories Battery & Charger Options CNB450E Spare 1800mAh Lithium-Ion battery pack with rear clip CSAHX... -
Page 7: Preparing Your Radio For Use
CAT410S 66-88MHz uncut compressed antenna CAT400-40 30-50MHz antenna For complete up to date list of optional accessories visit www.entel.co.uk Preparing Your Radio For Use Attaching / Removing The Battery Pack To attach, locate the pegs on the bottom of the battery and place into the slots on the radio. - Page 8 Preparing Your Radio For Use cont... Attaching / Removing the Aerial To attach, carefully align the aerial with the socket. Screw in the aerial clockwise (taking care not to cross the thread) until it is seated firmly against the top of the radio. To remove, unscrew the aerial anti-clockwise.
-
Page 9: Hx402/412/422/482(U)
HX402/412/422/482(U) Standard Features: • 16 programmable channels • Full transmit power output (5 Watts VHF, 4 Watts UHF) • CTCSS & DCS (analogue & digital squelch) with squelch tail elimination (removes the ‘shh’ noise) • Exceptionally loud and clear audio •... -
Page 10: Controls & Indicators
Controls & Indicators Channel / Scan control Antenna On / Off / Volume control Dealer programmable button 3 & LED indicator Speaker Push To Talk (PTT) button Microphone Dealer programmable buttons 1 & 2 On / Off / Volume control. Rotate clockwise to turn on and increase volume, anticlockwise to reduce volume and turn off. -
Page 11: Hx402S/412S/422S/482S(U)
HX402S/412S/422S/482S(U) All the features of the HX402/412/422/482 (see page 8) plus the following features: Standard Features: • Entry level selective calling Dealer programmable features: • Open or closed channel modes (allows private conversations) • Call a group, individual or all radios at once •... -
Page 12: Controls & Indicators
Controls & Indicators Channel / Scan Control Antenna On / Off / Volume control Dealer programmable button 3 & LED indicator Speaker Push To Talk (PTT) button Microphone Dealer programmable buttons 1 & 2 On / Off / Volume control. Rotate clockwise to turn on and increase volume, anticlockwise to reduce volume and turn off. -
Page 13: Hx403/413/423/483(U)
HX403/413/423/483(U) Standard Features: • LCD screen • 255 channel capacity • Full transmit power output (5 Watts VHF, 4 Watts UHF) • CTCSS & DCS (analogue & digital squelch) with squelch tail elimination (removes the ‘shh’ noise) • Exceptionally loud and clear audio •... -
Page 14: Controls & Indicators
Controls & Indicators Multi-function control Antenna On / Off / Volume control Dealer programmable button 3 & LED indicator Speaker Push To Talk (PTT) button Microphone Dealer programmable buttons 1 & 2 On / Off / Volume control. Rotate clockwise to turn on and increase volume, anticlockwise to reduce volume and turn off. -
Page 15: Lcd Icons
LCD Indicators • Missed Call • Keypad Locked • Bluetooth Device Connected • Accessory Connected • VOX Enabled • Scramble Enabled • Whisper Mode • Battery State • Receive Strength / TX Output Low / Mid / High RX / L / M / H •... - Page 16 INTENTIONALLY LEFT BLANK...
-
Page 17: Hx405/415/425/485(U)
HX405/415/425/485(U) All the features of the HX402S/412S/422S/482S (see page 10) plus the following features: Standard Features: • LCD screen • 255 channel capacity • Intuitive menus (like a mobile phone) • Info button (user guide built-in to radio) Dealer programmable features: •... -
Page 18: Controls & Indicators
Controls & Indicators Multi-function control Antenna On / Off / Volume control Dealer programmable button 3 & LED indicator Speaker Push To Talk (PTT) button Microphone Dealer Dealer programmable programmable function keys buttons 1 & 2 On / Off / Volume control. Rotate clockwise to turn on and increase volume, anticlockwise to reduce volume and turn off. -
Page 19: Lcd Icons
LCD Indicators • Message Received • Missed Call • Key Bleeps Off • Silent Profile • Keypad Locked • Man Down • Lone Worker • Bluetooth Device Connected • Accessory Connected • VOX Enabled • Scramble Enabled • Do Not Disturb •... - Page 20 INTENTIONALLY LEFT BLANK...
-
Page 21: Hx406/416/426/486(U)
HX406/416/426/486(U) All the features of the HX405/415/425/485 (see page 12) plus the following features: Standard Features: • Keypad Dealer programmable features: • Edit contact list • Free dial radio contacts • Free dial telephone numbers • Free dial DTMF numbers... -
Page 22: Controls & Indicators
Controls & Indicators Multi-function control Antenna On / Off / Volume control Dealer programmable button 3 & LED indicator Speaker Push To Talk (PTT) button Microphone Dealer Dealer programmable programmable function keys buttons 1 & 2 Keypad On / Off / Volume control. Rotate clockwise to turn on and increase volume, anticlockwise to reduce volume and turn off. -
Page 23: Lcd Icons
LCD Indicators • Message Received • Missed Call • Key Bleeps Off • Silent Profile • Keypad Locked • Man Down • Lone Worker • Bluetooth Device Connected • Accessory Connected • VOX Enabled • Scramble Enabled • Do Not Disturb •... - Page 24 Notes Use this page to record important information, such as the serial number of your radio and any private channels programmed by your dealer etc.
- Page 25 Notes...
- Page 26 ‘the professional’s choice’ <Intended Country Of Use> Registered Community Design Application 000810890 U.S. Design Patent Pending No. 23/182,829 Copyright and Unregistered Design Right Entel UK 2009 All rights reserved Headquarters: United Kingdom www.entel.co.uk...
