8. Block Diagram

TU01*
TUNER
TELH9-212A
IC902
EEPROM
KS24C020
IC901*
MICOM
SZM-354ET
D807 ~ D810
Samsung Electronics
SAW
M1859M
IC201
2
I C BUS
EXT IN EXT IN
AUDIO
VIDEO
T801*
SWITCHING
TRANS
S:125V,12.5V
IC801*
PC802
SPS CONTROL
KA3SO680
COULPER
KA3S0765
IC601
1CHIP
IF/V/C/D
KA2163B
Q401*
H-TR
KSC5368
VERTICAL-AMP
KA2131
(125V)
(12.5V)
IC802
SOUND-AMP
2.5W x 1CH
LA4425
R.G.B
CRT
T444*
14" : FSV14A001
20" : FSV20A001
21" : FSV20A001
(5V)
MICOM
MULTI-REGULATOR
KA7631
1CHIP
(9V)
Block Diagram
DUAL
F.B.T
8-1
