Page 1
COLOR TELEVISION RECEIVER Chassis : K15D Model : CT3338FX/XAP CT5038FX/XAP CT2088BLFX/XAP CT20D8BWFX/XAP COLOR TELEVISION RECEIVER CONTENTS Precautions Specifications and IC Data Disassembly and Reassembly Alignment and Adjustment Troubleshooting Exploded View and Parts List Electrical Parts List Block Diagram Wiring Diagram...
Page 3
“VOLUME” keys ( Up or Down). The adjust- 6. Cancel the Adjustment Mode by re-pressing ment parameters are listed in the accompany- the “FACTORY” or “Power OFF” keys. ing table, and selected by pressing the CHAN- NEL keys ( Samsung Electronics...
Page 4
0 ~ 1 M atri x U S A FIX (Mono) A u tomatic Gain C ontrol 0 ~ 6 3 0 ~ 1 D y nami c S k i n Tone DVDB D VD B right Offs et Samsung Electronics...
Page 5
AIR/STD/HRC/AFN - U.S Army - Available (U.S.A, Army) X-RAY - Unavailable (South America) - Available (U.S.A) V-CHIP - Unavailable (Canada) TV ↔ AV AV Option TV ↔ AV ↔ DVD - Available (South America) DEMO - Unavailable (U.S.A) Samsung Electronics...
Page 6
7. Do not attempt to connect or disconnect any wires while the TV is turned on. Make sure that the power cord is disconnected before replacing any parts. 8. To protect against shock hazard, use an isola- tion transformer. Samsung Electronics...
Page 7
3. Use the P mode key (on the remote control) for the STANDARD picture. 4. Adjust the Screen VR (on the FBT) so that the voltage on the oscilloscope becomes 125+2.5V (See Fig. 4-1). 125 2.5V Fig. 4-1 Samsung Electronics...
Page 8
Mode with using CA100. See Fig. 4-4. Fig. 4-4 2. Adjust RG,BG so that the levels are suitable to each local area. (c) High-Light Adjustment 1. Set SCT to 50FL(13V : 60FL) in the Factory Service Mode with using CA100. See Fig. 4-4 . Samsung Electronics...
Page 9
8. Since the 4-pole magnets and 6-pole magnets lines in the center area of the screen. interact, the dot movement is complex (Fig. 4-5). RED/BLUE GREEN BLUE BLUE RED/BLUE GREEN 6-Pole Magnet Movement 4-Pole Magnet Movement Fig. 4-5 Center Convergence Adjustment Samsung Electronics...
Page 10
4. Fig. 4-7 4. Adjust with VSL (Vertical-Slope) so that the bottom margin of the picture is 4. Fig. 4-8 5. Adjust with HS (Horizontal Shift) so that the lion-head pattern and CRT centers are aligned. Samsung Electronics...
Page 11
Exploded View & Parts List 6. Exploded View & Parts List 6-1 CT3338FX/XAP Code No Description;Specification Q’ty Remark AA64-31147Q CABINET FRONT;3338,SV704P EPPV,HIPS,HB,G INLAY-A/V AA64-70127F BADGE-BRAND;AL,SS,SILVER,R800 BADGE AA64-40057A WINDOW-REMOCON;-,ABS,HB,-,-,33 AA64-10153J KNOB POWER;3338,ABS,-,G3676,NO-SILK,HB,- AA61-60003J SPRING-CS;-,-,SUS304,0.5,OD6,H SPRING 6003-001026 SCREW-TAPTITE;RH,+,B,M4,L15,ZPC(BLK),SWR KC+CF AA64-10052B KNOB-CONTROL;-,3338,G3676 JPN,ABS,HB,GRA AA96-00144A ASSY-SPEAKER;-,8OHM,2.5WX2,3001-000281,A...
