Page 1 PROJECTION TV RECEIVER Chassis : J54A(P) C2.0 Model: SP43T7HF1X/BOB SP43T7HF1X/EUE SP42W5HF1X/XEG SP42W5HFX/XEU PROJECTION TV RECEIVER C O N T E N T S Alignment and Adjustments Exploded View and Parts List Electric Parts List PCB Diagrams Schematic Diagrams...
Page 3: Alignment And Adjustments
1. When EEPROM IC (IC902) is replaced, first connect the power cord and wait for about 4~5 seconds. 2. After replacing EEPROM IC (IC902), enter the Service mode. Next, enter the standard data or the previous EEPROM IC data before replacement. And then check and adjust any items related to Geometric, Picture, Option. Samsung Electronics...
Page 4 H Trapezium 0 ~ 63 0 ~ 63 Angle 0 ~ 63 V Position 0 ~ 63 Up UCG 0 ~ 3 Lo UCG 0 ~ 3 CXA Left Blk 0 ~ 63 CXA Right Blk 0 ~ 63 Samsung Electronics...
Page 5 0 ~ 23 Sut Tint 0 ~ 63 CTI Level 0 ~ 3 COL Axis 0 ~ 3 LTI Level 0 ~ 3 0 ~ 15 Melody Volume 0 ~ 20 LIT Mode 0 ~ 3 System 0 ~ 3 Samsung Electronics...
Page 6 VM Delay 0 ~ 3 SHP CD 0 ~ 3 SHP f0 0 / 1 SHP f1 & P/O AKB Time 0 ~ 63 BandPass 9407 HighPass 9407 S ABL 0 ~ 3 P ABL 0 ~ 15 Samsung Electronics...
Page 7 NR Low Ref 0 ~127 NR High Value 0 ~255 NR Low Value 0 ~255 NR Hight Ref(S) 0 ~127 NR Low Ref(s) 0 ~127 NR High Value(S) 0 ~255 NR Low Value(S) 0 ~255 NR Read M/S 0/27 Samsung Electronics...
Page 8 CS/CW Area Option SYSTEM A2-NICAM/Dolby-Prologic Dolby Prlogic SOUND WIDE / 4:3 Inch Option ASPECT ON/OFF Inch Option WIDE 4:3 ON/OFF X-RAY ON/OFF AUTO FM ON/OFF ON/OFF ON/OFF Letter Box West/East/CIS/Turk&Grk Area Option TTX Lang.Grp ON/OFF ON/OFF Natural Zoom Samsung Electronics...
Page 9 Alignment and Adjustments 1-2-1(G) YC DELAY Item Range P.YC(AV) Delay S.YC(AV) Delay N.YC(AV) Delay P.BG.YC Dealy P.DK.YC Delay P.I.YC Delay P.M.YC Delay P.N.YC Delay S.BG.YC Delay S.DK.YC Delay S.I.YC Delay S.M.YC Delay S.L.YC Delay N.M.YC Delay N4.43 YC Delay Samsung Electronics...
Page 10 H Trapezium 0 ~ 63 0 ~ 63 Angle 0 ~ 63 V Position 0 ~ 63 Up UCG 0 ~ 3 Lo UCG 0 ~ 3 CXA Left Blk 0 ~ 63 CXA Right Blk 0 ~ 63 Samsung Electronics...
Page 11 0 ~ 23 Sut Tint 0 ~ 63 CTI Level 0 ~ 3 COL Axis 0 ~ 3 LTI Level 0 ~ 3 0 ~ 15 Melody Volume 0 ~ 20 LIT Mode 0 ~ 3 System 0 ~ 3 Samsung Electronics...
Page 12 VM Delay 0 ~ 3 SHP CD 0 ~ 3 SHP f0 0 / 1 SHP f1 & P/O AKB Time 0 ~ 63 BandPass 9407 HighPass 9407 S ABL 0 ~ 3 P ABL 0 ~ 15 1-10 Samsung Electronics...
Page 13 NR Low Value(S) NR Read M/S 1-2-2(E) VIDEO ADJUST4 Remark Item Range Initial Data SECAM Color Main 0 ~255 SECAM Color Pip 0 ~255 Picture Limit 0 ~ 3 OSD Contrast 0 ~ 15 TTX Contrast 0 ~ 15 Samsung Electronics 1-11...
Page 14 0N(AUSTRALIA) WEST EUROPE / EAST EUROPE TTX LANG WEST EUROPE WEST EUROPE ARABIC RUSSIAN / GREEK-TURKEY ARABIC / FARSI / AREB-HEBREW OFF / ON OFF/0N(Thailand) AV MEMORY OFF / ON AUSTRALIA OFF / ON CG BRIGHT OFF/ON 1-12 Samsung Electronics...
Page 15 Alignment and Adjustments 1-2-2(G) YC DELAY Item Range P.YC(AV) Delay S.YC(AV) Delay N.YC(AV) Delay P.BG.YC Dealy P.DK.YC Delay P.I.YC Delay P.M.YC Delay P.N.YC Delay S.BG.YC Delay S.DK.YC Delay S.I.YC Delay S.M.YC Delay S.L.YC Delay N.M.YC Delay N.443.YC Delay Samsung Electronics 1-13...
Page 16: Screen Change
Alignment and Adjustments 1-3 Screen Change (When Adjusting I C Bus Geometric Items) V AMP V - S - CORRECTION H Parabolra V SHIFT H EW H Trapezium H SHIFT V LINEARITY ANGLE 1-14 Samsung Electronics...
Page 17: Other Adjustments
3. Adjust VR(RR402S) so that the voltage becoms 2.25V. 1. Input a sub-brightness adjustment signal. 4. After the adjustments are complete be sure to (TOSHIBA PATTERN) mount VR(RR402S) correctly. 2. In the stand-by mode, press the remote-control Samsung Electronics 1-15...
Page 18 ADJUSTMENT 1. Loosen the lens screws. 2. Cover the two lenses that are not being adjusted. 3. Adjust the lens, observing the color aberration vertically and horizontally within 3 blocks of the center of the crosshatch pattern. 1-16 Samsung Electronics...
Page 19 14. Adjust the Focus-pack VR for fine focusing. 15. Press the button on the remote control, and the mode changes to the Convergence Adjustment mode. S.STD 16. Press the button on the remote control to return to normal viewing. Samsung Electronics 1-17...
Page 20 At this time, a high voltage protection point is combined with the detection value of DC high set. When QR401S turns ON, high voltage is voltage fluctuation by using C478. applied to PWM IC pin4 and then muted. 1-18 Samsung Electronics...
Page 21 C-block capacitor. displayed as shown in But, it can't detect actual dynamic fluctuation. figute side Also, its velocity of response to static fluctuation is late because +B power supply changes per Existing type Samsung Electronics 1-19...
Page 22 47W3 Screen Size : X 1045, Y 588 (X:764 = 22 x 2 + 60 x 12, Y:262 = 17 x 2 + 38 x 6)-PAL MODE 3 0 .0 9 m m 8 2 .0 7 m m 3 0 .0 9 m m 3 8 .1 5 m m 8 5 .2 8 m m 3 8 .1 5 m m 1-20 Samsung Electronics...
Page 23 65W3 Screen Size : X 1442, Y 838 (X:764 = 22 x 2 + 60 x 12, Y:262 = 17 x 2 + 38 x 6)-PAL MODE 4 1 .5 2 m m 3 .2 5 m m 4 1 .5 2 m m 5 4 .3 7 m m .5 4 m m 5 4 .3 7 m m Samsung Electronics 1-21...
Page 24 48T6 Screen Size : X 973.4 Y 738.4 (X:764 = 22 x 2 + 60 x 12, Y:262 = 17 x 2 + 38 x 6)-PAL MODE 2 8 .0 3 m m 6 .4 5 m m 2 8 .0 3 m m 4 7 .9 1 m m .1 0 m m 4 7 .9 1 m m 1-22 Samsung Electronics...
Page 25 62T6 Screen Size : X 1259.4, Y 948 (X:764 = 22 x 2 + 60 x 12, Y:262 = 17 x 2 + 38 x 6)-PAL MODE .2 7 m m 8 .8 1 m m 3 6 .2 7 m m 6 1 .5 1 m m .5 0 m m 6 1 .5 1 m m Samsung Electronics 1-23...
Page 26 Convergence Data Convergence Data Left/Right Move Button UP/DOWN Move Button Menu Video Convergence Data UP/DOWN Move Button Test Normal Display P.Size Convergence H-PHASE Text/Mix Info. Sleep Perfect Focus Move Button(Right) Scan Swap Locate Convergence H-PHASE Move Button(Left) 1-24 Samsung Electronics...
Page 27: Cancel Key
Press to call the factory default values. S.Mode 11. SAVE BUTTON After the Convergence Adjustments are completed, press to save data. S.STD 12. EXIT BUTTON After the Convergence adjustments are completed, press to exit to TV mode. Samsung Electronics 1-25...
Page 28 14. CONVERGENCE PICTURE MOVE BUTTON (Right) (Up) (Left) (Down) Cg -Data Move Button 15. CONVERGENCE MOVE BUTTON Sleep Press to move the convergence right ( ) or left ( 16. CONVERGENCE DATA ZERO BUTTON Press to zero the convergence correction data. 1-26 Samsung Electronics...
Page 29 43” (43T7) SP43T7 5-485(Press in regular order) 48” (48T6) SP48T6 5-545(Press in regular order) 54” (54T6) SP54T6 5-625(Press in regular order) 62” (62T6) SP62T6 65”(65W3) SP65W3 Locate 18. Data shift Button Press to transmit data(PAL Mode/NTSC Mode). Samsung Electronics 1-27...
Page 30: Convergence Adjustment
If OSD displayed as shown in figure below, press the key to exit. Then, redo step 3 to enter the Convergence Mode. After entering the Convergence Mode, Stand by for about five seconds before doing the adjustments. 1-28 Samsung Electronics...
Page 31 Alignment and Adjustments Menu Menu Mute P.Size Samsung Electronics 1-29...
Page 32 Alignment and Adjustments LINE Adjust S.Mode Menu 1-30 Samsung Electronics...
Page 33 Alignment and Adjustments S.Mode Samsung Electronics 1-31...
Page 34 Alignment and Adjustments 1-8-2 Perfect Focus(Factory Mode) Up, Down Left, Right Perfect Focus Perfect Focus Exit Exit Process : 83% Process : 83% S.STD 1-32 Samsung Electronics...
Page 35 1-9 MICOM and Pins Voltage 1-9-1 Pin Layout(T_CM2P06_XXX) 1080i-SW SCL1 SDA1 SCAN-RST ST3.3B OSD-YS/YM ST3.3A XTAL1 ST3.3B XTAL2 SDA6001-B11 ST2.5A (T_CM2P06_XXX) OSD-R LDQM OSD-G UDQM OSD-B CSROM ST2.5A CLKEN CSSDRAM CLKSDRAM ST2.5A ST3.3B TTX-CVBS A15/CAS A14/RAS ST2.5A KEYS1 KEYS2 MAIN-AFT SUB-AFT Samsung Electronics 1-33...
Page 36 Alignment and Adjustments 1-9-2 Pin Layout(T_CMDEAC_XXX) 2.5V 3.3V 3.3V 2.5V SDA2 SCL2 BUS-STOP SDA1 SCL1 S-RESET V-MUTE TTX-CVBS OSD-F/B 2.5V OSD-B OSD-G MAIN-AFT OSG-R SUB-AFT 2.5V KEY2 KEY1 XTAL1 H-BLK XTAL2 V-BLK 1-34 Samsung Electronics...
Page 37 SCL2 SERIAL CLOCK LINE2 3.27[V] C-SPK MUTE CENTER SPEAKER MUTE 3.26[V] SDA2 SERIAL DATA LINE2 3.27[V] SW3(CONTROL) 5[mV] SW2(CONTROL) 2.08[V] SUB-AFT SUB TUNER AFT CONTROL 2.57[V] MAIN-AFT MAIN TUNER AFT CONTROL 1.04[V] BUS-STOP IIC BUS STOP 3.27[V] Samsung Electronics 1-35...
Page 38 VERTICAL SYNC HORIZONTAL SYNC 215.51[mV] TTX-CVBS TTX/CAPTION-CVBS 1.19[V] AN-LINK NOT USE OSD-TTX-R ON SCREEN DISPLAY RED 168[mV] OSD-TTX-G ON SCREEN DISPLAY GREEN 0.46[V] WRITE PROTECT OSD-TTX-B ON SCREEN DISPLAY BLUE 0.46[V] 3.3[V] 3.3[V] 3.26[V] OSD-TTX-FB OSD/TTX-FB 7.31[mV] 1-36 Samsung Electronics...
Page 39: Dynamic Focus
SERIAL CLOCK LINE 3.42[V] SDA1 SERIAL DATA LINE 3.50[V] COMP COMP 27.28[mV] CG-R CONVERGENCE RED 0.27[mV] CG-G CONVERGENCE GREEN 0.27[mV] CG-B CONVERGENCE BLUE 0.29[mV] CG-SYNC CONVERGENCE SYNC 180.03[mV] DYNAMIC FOCUS 1.5[V] 9[V] 9[V] 9[V] 13.5[V] 13.5[V] 14.05[V] Samsung Electronics 1-37...
Page 40 2.08[V] PIP-C PIP-C INPUT 1.20[mV] PIP-Y CVBS PIP-Y/CVBS INPUT 1.33[mV] MAIN-C MAIN-C INPUT 1.34[mV] MAIN-Y CVBS MAIN-Y/CVBS INPUT 1.57[mV] RF2-CVBS RF2-CVBS DVD-Pr/R DVD-Pr/R(SCART) DVD-Y/G DVD-Y/G(SCART) DVD-Pb/B DVD-Pb/B(SCART) FB(SCART) DVD-Pr DVD-Pr DVD-Y DVD-Y DVD-Pb DVD-Pb 5[V]-DW2 5[V]-DW2 4.89[V] 1-38 Samsung Electronics...
Page 41 BLUE VERTICAL OUT 34.27[mV] BLUE HORIZONTAL OUT -107.32[mV] GREEN VERTICAL OUT 101.52[mV] GREEN HORIZONTAL OUT -15.83[mV] RED VERTICAL OUT 104.32[mV] RED HORIZONTAL OUT -88.95[mV] H-BLK HORIZONTAL BLANK 275[mV] V-BLK VERTICAL BLANK -13.22[mV] -5[V] -5[V] -4.99[V] 5[V] 5[V] 5.24[V] Samsung Electronics 1-39...
Page 42 Alignment and Adjustments MEMO 1-40 Samsung Electronics...
Page 43 2. Exploded View & Parts List 2-1 SP43T7HF1 You can search for the updated part code through ITSELF web site. Code No Description Specification Q’ty Remark S.N.A URL : http://itself.sec.samsung.co.kr ASSY COVER P-CABINET,MASK;SP-43T7HF,HIPS SCREEN-FRESNEL;43N,-,T2,910*692,-,-,-,- SCREEN-TINT;43,908*690,P=0.52,DNP BRACKET-SCREEN,RIGHT-ASSY;43T7,SECC,T1.0 S.N.A SCREW-SPECIAL;BH,+,-,M4,L12(11),ZPC(BLK) BS+CFM BRACKET-SCREEN,TOP-ASSY;43T7,SECC,T1.0,S S.N.A...
Page 44 Exploded View & Parts List 2-2 SP42W5HF You can search for the updated part code through ITSELF web site. Code No Description Specification Q’ty Remark S.N.A URL : http://itself.sec.samsung.co.kr ASSY-FRONT,MASK;,HIPS HB,G4309,SVM1132,4 ASSY-CABINET,WOOD;,WOOD,EUP,42W5 S.N.A SCREEN-FILTER;T=82%,960*552*2,G=110,AG SCREEN-TINT;42W,958*550,T=0.7,P=052 SCREEN-FRESNEL;42W,960*552,T=2.0 BADGE-BRAND;72MM,AL FORGING,SVM1132,SAMS MODULE-FOCUS,PACK;SVP-5200,S300-P3,-,-,- ASSY PRT;SP42W5HFX/XEO,J52A S.N.A...
Page 45: General Alignment Instructions
2. Turn on the TV. Set the Brightness and Contrast controls to minimum (zero beam current). 3. Adjust the Brightness and contrast controls to both extremes. Ensure that the high voltage does not exceed 32 KV under any conditions. Samsung Electronics...
Page 46: Video Adjustment
V Peaking 0 ~12 TTX Cont 0 ~15 TTX Bright 0 ~ 63 PIP Cont 0 ~15 PIP Bright 0 ~15 CG R Contrast 0 ~ 63 CG G Contrast 0 ~ 63 CG B Contrast 0 ~ 63 Samsung Electronics...
Page 47 -128 ~ +127 P.BOW -128 ~ +127 P.ANGLE -128 ~ +127 P.EW-UPCR -128 ~ +127 P.EW-LOCR -128 ~ +127 P.HOR-EHT 0 ~ +255 P.VER-EHT 0 ~ +255 P.INT. VOL. REF -16 ~ +15 P.HSYNC DELAY -128 ~ +127 Samsung Electronics...
Page 48 0 ~ 3 R-Y/R 0 ~ 15 R-Y/B 0 ~ 15 G-Y/R 0 ~ 15 G-Y/B 0 ~ 15 LRGB2-LEVEL 0 ~ 15 PABL-LEVEL 0 ~ 15 BLK-BOTTOM 0 ~ 15 SUB-SHP 0 ~ 3 SUB-FO 0 ~ 3 Samsung Electronics...
Page 49 0 ~ 15 G-Y/B 0 ~ 15 SUB-SHP 0 ~ 3 SUB-FO 0 ~ 3 PRE-OVER 0 ~ 3 LT1-LEVEL 0 ~ 3 VM-LEVEL 0 ~ 3 VM-DELAY 0 ~ 3 DC-TRAN 0 ~ 3 D-PIC 0 ~ 3 Samsung Electronics...
Page 50 INITIAL DATA REMARK SYSTEM 0 ~ 3 CLP-MASK 0 ~ 3 DTV-SYNC 0 ~ 255 CR-OFFSET1 0 ~ 15 CB-OFFSET1 0 ~ 15 CTI-LEVEL 0 ~ 3 R-Y/R 0 ~ 15 R-Y/B 0 ~ 15 G-Y/R 0 ~ 15 Samsung Electronics...
Page 51 0 ~ 15 G-Y/B 0 ~ 15 SUB-SHP 0 ~ 15 SIB-FO 0 ~ 3 PRE-OVER 0 ~ 3 LTI-LEVEL 0 ~ 3 VM-LEVEL 0 ~ 3 VM-DELAY 0 ~ 3 DC-TRAN 0 ~ 3 D-PIC 0 ~ 3 Samsung Electronics...
Page 52 HIGH DEVIATION ON <--> OFF E-EUROPE -> RUSSIAN -> ARABIC W-EUROPE TTX GROUP W-EUROPE W-EUROPE -> ICELANDIC -> HEBREW GARRIER MUTE ON <--> OFF STANDARD -> SPORT -> MILD STANDARD STANDARD STANDARD STANDARD -> NATURAL -> CUSTOM -> NDEN Samsung Electronics...
Page 53 0 ~ 255 Up Corner 0 ~ 255 Low Corner 0 ~ 255 H EHT 0 ~ 255 H Shift 0 ~ 127 V Angle 0 ~ 255 V BOW 0 ~ 255 H Sync Phase 0 ~ 255 Samsung Electronics...
Page 54 Sharp FO 0 ~ 3 Prev Over 0 ~ 3 0 ~ 3 0 ~ 3 VM-Level 0 ~ 3 VM-Delay 0 ~ 3 DC-TRAN 0 ~ 3 D Picture 0 ~ 3 H Width 0 ~ 3 4-10 Samsung Electronics...
Page 55 -64 ~ 63 Offset H Shift -64 ~ 63 Cg R Contrast 0 ~ 100 Cg G Contrast 0 ~ 100 Cg B Contrast 0 ~ 100 Cg VAO PAL 0 ~ 100 Cg VAO NTSC 0 ~ 100 Samsung Electronics 4-11...
Page 56 DOLBY <--> A2/NICAM <--> V-DOLBY DOLBY WIDE ON <--> OFF SCART1 ON <--> OFF ON <--> OFF AUTO FM ON <--> OFF DOUBLE DOUBLE OFF <--> 1-TUNER <--> 2-TUNER <--> DOUBLE DOUBLE HIGH DEVIATION ON <--> OFF 4-12 Samsung Electronics...
Page 57 0 (0 ~ 63) PIP Contrast VPC3230 43 (0 ~ 63) Not used Cg R Contrast CXA2101 31 (0 ~ 63) Cg G Contrast CXA2101 31 (0 ~ 63) Cg B Contrast CXA2101 15 (0 ~ 63) Samsung Electronics 4-13...
Page 58 N.PIP V-Position P.PIP V-Position VPC3230 VPC3230 7 (0 ~ 15) 7 (0 ~ 15) N.Not used P.Not used N.Not used P.Not used N.CG V-amp Offset P.CG V-amp Offset SDA9361 SDA9361 30 (-128 ~ 127) 30 (-128 ~ 127) 4-14 Samsung Electronics...
Page 59 Digital Color Transition Improvement Control SDA9280 Luminance Peaking Control BPF-LPF 70 (0 ~ 255) SDA9280 -Gain of band-pass filter -Gain of low-pass filter Luminance Peaking Control HPF-Coing 8 (0 ~ 255) SDA9280 -Gain of high-pass filter -Gain of high-and band-pass filter Samsung Electronics 4-15...
Page 60 2 (0 ~ 3) VM-OUT level control CXA2101 VM-Delay 0 (0 ~ 3) VM-OUT phase control CXA2101 DC-TRAN 2 (0 ~ 3) Y system DC transmission ratio setting CXA2101 D-PIC 3 (0 ~ 3) Dynamic picture(black expansion)control CXA2101 4-16 Samsung Electronics...
Page 61 Vertical Peaking VPC3230 Luminance Peaking Control BPF-LPF 72 (0 ~ 255) SDA9280 -Gain of band-pass filter -Gain of low-pass filter Luminance Peaking Control HPF-Coring 10 (0 ~ 255) SDA9280 -Gain of band-pass filter -Gain of low-pass filter Samsung Electronics 4-17...
Page 62 Vertical Peaking VPC3230 Luminance Peaking Control BPF-LPF 72 (0 ~ 255) SDA9280 -Gain of band-pass filter -Gain of low-pass filter Luminance Peaking Control HPF-Coring 10 (0 ~ 255) SDA9280 -Gain of high-pass filter -Gain of high-and band-pass filter 4-18 Samsung Electronics...
Page 63 RGB Mode Color 5 (0 ~ 255) VPC3230 RGB Color_L 209 (0 ~ 255) RGB Mode Color VPC3230 RGB Tint 0 (0 ~ 255) RGB Mode Tint VPC3230 RGB Bri_Cont 27 90 ~ 255) RGB Mode Brightness, Contrast VPC3230 Samsung Electronics 4-19...
Page 64 SDA9280 Side Panel Level 7 (0 ~ 15) Side Panel Luminance Control SDA9280 Side Panel B-Y 0 (0 ~ 15) Side Panel Chrominance Control SDA9280 Side Panel R-Y 0 (0 ~ 15) Side Panel Chrominance Control SDA9280 4-20 Samsung Electronics...
Page 65 Alignment and Adjustments 4-5 Screen Change (When adjusting I C Bus Geometric items) V SHIFT V SIZE V LINEARITY V - S - CORRECTION PIN PHASE H SIZE PIN AMP H SHIFT V BOW V ANGLE Samsung Electronics 4-21...
Page 66 4. After the adjustments are complete, be sure to mount VR (RR402S) correctly. 1. Input a sub-brightness adjustment signal. (TOSHIBA PATTERN) 2. In the stand-by mode, press the remote-control keys in the following sequence : Displsy → Menu → Mute → Power ON 4-22 Samsung Electronics...
Page 67: Static Focus Adjustment
Crimson. 7. Blue lens adjustment Set the Blue lens at the point where Purple becomes Green. Examine these points together Fig. 4-1 Crosshatch Pattern. RED ABERRATION BLUE ABERRATION L1, L2 < P Fig. 4-2 Color Aberration Samsung Electronics 4-23...
Page 68 D-Focus and the '-' terminal to GND. 4. Adjust L434 located on the sub PCB so that the digital multimeter indicates AC690 20Vp-p.(WIDE AC600 20Vp-p) 5. Balance the left and right sides of the dynamic focus lines. 4-24 Samsung Electronics...
Page 69 2 6 .1 5 m m 8 7 .1 7 m m 2 6 .1 5 m m 5 2 .6 5 m m 1 2 0 .3 5 m m 5 2 .6 5 m m Samsung Electronics 4-25...
Page 70 4-7-4 55W3 Normal Mode N o r m al 4 : 3 m o d e Sc reen Size : X 1225, Y 686 (X:378= 9* 2+ 30* 12, Y: 440=28*2+ 64* 6) 29.17mm 97.22mm 29.17mm 43.65mm 99.78mm 43.65mm 4-26 Samsung Electronics...
Page 71 3 4 .3 3 m m 1 1 4 .4 4 m m 3 4 .3 3 m m 5 3 .3 3 m m 1 2 1 .8 9 m m 5 3 .3 3 m m Samsung Electronics 4-27...
Page 72 Alignment and Adjustments 4-8 Remote Control for Servicing 4-8-1 WESTERN EUROPE Power 4-28 Samsung Electronics...
Page 73 Alignment and Adjustments 4-8-2 CHINA Power Samsung Electronics 4-29...
Page 74: Exit Button
Press to switch the cursor direction horizontally or vertically. 12. SAVE BUTTON After the Convergence Adjustments are completed, press to save data. 13 EXIT BUTTON After the Convergence adjustments are completed, press to exit to TV mode. 4-30 Samsung Electronics...
Page 75 White Oval on the background (white circle) SP55W3 55”(55W3) 5-559 (Press in regular order) White Oval on the background SP65W3 65”(65W3) 5-659 (Press in regular order) (white border) 20. Data Shift Button Press to transmit data(PAL Mode/NTSC Mode) Samsung Electronics 4-31...
Page 76 If OSD displayed as shown in figure below, press the key to exit. Then, redo step 3 to enter the Convergence Mode. After entering the Convergence Mode, Stand by for about five seconds before doing the adjustments. 4-32 Samsung Electronics...
Page 77 Alignment and Adjustments Samsung Electronics 4-33...
Page 78 Alignment and Adjustments 4-34 Samsung Electronics...
Page 79 Samsung Electronics 4-35...
Page 80 Alignment and Adjustments 4-36 Samsung Electronics...
Page 81 VSS VSSD P1.0 A2 A2 A1 A1 A0 A0 XTAL2 XTAL2 D3 D3 XTAL1 XTAL1 D2 D2 RESET D4 D4 D1 D1 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 Samsung Electronics 4-37...
Page 82 Alignment and Adjustments 4-10-2 MICOM Pins(CW) PIN NO. ITEM FUNCTION OUT VOLT PROTECT PROTECT ST-BY LED ST-BY LED TIMER LED TIMER LED POWER POWER POWER2 POWER2 XTAL2 XTAL2 XTAL1 XTAL1 RESET RESET 4-38 Samsung Electronics...
Page 83 Alignment and Adjustments PIN NO. ITEM FUNCTION OUT VOLT SCL1 SCL1 SDA1 SDA1 SDA2 SDA2 SCL2 SCL2 AMP-MUTE AMP-MUTE CENTER-MUTE CENTER-MUTE BUS-STOP BUS-STOP KEY1 KEY1 Samsung Electronics 4-39...
Page 84 Alignment and Adjustments PIN NO. ITEM FUNCTION OUT VOLT KEY2 KEY2 MAIN-AFT MAIN-AFT SUB-AFT SUB-AFT M3L CLK M3L CLK M3L DAT M3L DATA M3L ENABLE M3L ENABLE 4-40 Samsung Electronics...
Page 85 VDD 2.5V VDD 3.3V OSD F/B CVBS IN OSD B VDD 2.5V OSD G OSD R VDD 2.5V SUB-AFT KEY2 X-OUT KEY1 X-IN H-BLK RESET V-BLK KEY3 PROTECT VDD 3.3V SCONT1 IR-IN RTXD ST-BY LED TIMER LED Samsung Electronics 4-41...
Page 86 SUB AUTO FINE TURNING CONTROL KEY2 KEY SCAN 2 KEY1 KEY SCAN 1 HSYNC HORIZONTAL SYNC INPUT VSYNC VERTICAL SYNC INPUT KEY3 KEY SCAN 3 PROTECT PROTECT PORT S-CONTO SOUND MODE SELECT IR IN REMOCON INPUT CONVERGENCE D3 TIMER-LED TIMER LED 4-42 Samsung Electronics...
Page 87 ON SCREEN DISPLAY BLUE OUTPUT OSD F-B OSD BLAKING SIGNAL OUTPUT VDD 2.5V VDD 3.3V DVD-IDENT DVD-IDENT DTV-INENT DTV-IDENT CENTER SPK MUTE MODE SELECT DVD MODE SELECT(480i/480p) AMP-MUTE MAIN AMP MUTE POWER POWERR ON/OFF RELAY CONTROL S-CONTO SOUND MODE SELECT Samsung Electronics 4-43...
Page 88 SERIAL DATA LINE 4.7V SERIAL CLOCK LINE 4.8V OPTION H-OUT HORIZENTAL-OUT V-OUT VERTICAL-OUT EAST WEST OUT 2.2V V-BLK V-BLANKING ABL INPUT 2.15V VERTICAL DRIVE(-VOLTAGE) 2.95V VERTICAL DRIVE(+VOLTAGE) 2.90V H-BLK H-BLANKING INPUT H-DRIVE OUT 1.6V PIP-RF PIP-C PIP-V/Y CVBS-Y 4-44 Samsung Electronics...
Page 89 HALF TONE INPUT YS/YM VIDEO MUTE (V-CHIP ON) 4.72V YS/YM D-Pr INPUT HD-Pr D-Y INPUT HD-Y D-Pb INPUT HD-Pb GND GND R-OUT R-OUT G-OUT G-OUT B-OUT B-OUT IK OUT 3.65V SPOT OUT VM-Y VM-Y OUT 5.42V CG-SYND CG-SYNC INPUT Samsung Electronics 4-45...
Page 90 Alignment and Adjustments PIN NO. ITEM FUNCTION OUT VOLT CG-B CG-B INPUT CG-G CG-G INPUT CG-R CG-R INPUT 4-46 Samsung Electronics...
Page 91 OUT VOLT S-RESET SOUND RESET MAIN-L MAIN LEFT OUT MAIN-R MAIN RIGHT OUT SCL-1 SERIAL CLOCK LINE SDA-1 SERIAL DATA LINE CENTER CENTER OUT GNAD SURROUND SURROUND OUT S-F1 S-F1(ANT1) AV4-L-IN AV4 LEFT INPUT A-MONO-IN A-MONO INPUT Samsung Electronics 4-47...
Page 92 EXTERNAL LEFT INPUT H-PHONE-L HEADPHONE LEFT OUT EXT-R-IN EXTERNAL RIGHT INPUT H-PHONE-R HEADPHONE RIGHT OUT AV2-L-IN AV2 LEFT INPUT MONITOR-L MONITOR OUT AV2-R-IN AV2 RIGHT INPUT MONITOR-R MONITOR OUT AV1-L-IN AV1 LEFT INPUT AV1-L-OUT AV1 LEFT OUTPUT 4-48 Samsung Electronics...
Page 93 Alignment and Adjustments PIN NO. ITEM FUNCTION OUT VOLT AV1-R-IN AV1 RIGHT INPUT AV1-R-OUT AV1 RIGHT OUT Samsung Electronics 4-49...
Page 94 0.2V CTRL CTRL INPUT REMOCON COMP COMP VIDEO OUTPUT BLUE VERTICAL OUT BLUE HORIZONTAL OUT GREEN VERTICAL OUT GREEN HORIZONTAL OUT RED VERTICAL OUT RED HORIZONTAL OUT H-BLK H-BLANKING OUT 0.52V V-BLK V-BLANKING OUT -5.4V -5.4V -5.4V 4-50 Samsung Electronics...
Page 95 Alignment and Adjustments PIN NO. ITEM FUNCTION OUT VOLT 5.4V 5.4V 5.4V Samsung Electronics 4-51...
Page 96 Alignment and Adjustments MENO 4-52 Samsung Electronics...
Page 97 Block Diagrams 8. Block Diagram 8-1 Main Signal(Progressive) Samsung Electronics...
Page 98 Block Diagrams 8-2 Video Signal Samsung Electronics...
Page 99 Block Diagrams 8-3 Sound Signal Samsung Electronics...
Page 100 Block Diagrams 8-4 Power Supply Samsung Electronics...
Page 101 Block Diagrams 8-5 In/Out by Block 8-6 Signal Connection by Block Samsung Electronics...
Page 102 Wiring Diagrams 9. Wiring Diagram 9-1 Pcb Connection(Progressive) Samsung Electronics...
Page 103 Schematic Diagrams 5. Schematic Diagrams 5-1 MAIN 1 TP02 TP01 TP01 TP02 Samsung Electronics...
Page 104 Schematic Diagrams 5-2 MAIN 2 TP03 TP04 TP03 TP05 TP04 TP05 Samsung Electronics...
Page 105 Schematic Diagrams 5-3 MAIN 3 TP06 TP07 TP06 TP07 Samsung Electronics...
Page 106 Schematic Diagrams 5-4 MAIN 4 TP20 TP14 TP08 TP12 TP11 TP14 TP13 TP10 TP09 TP08 TP15 TP09 TP15 TP16 TP10 TP16 TP17 TP18 TP19 TP17 TP11 TP20 TP18 TP12 TP19 TP13 Samsung Electronics...
Page 107 Schematic Diagrams 5-5 T_CM2906_002 MICOM Samsung Electronics...
Page 108 Schematic Diagrams 5-6 T_CMDEAC_XXX MICOM Samsung Electronics...
Page 109 Schematic Diagrams 5-7 CRT Samsung Electronics...
Page 110 Schematic Diagrams 5-8 SUB 1 TP21 TP21 Samsung Electronics...
Page 111 Schematic Diagrams 5-9 SUB 2 TP22 TP23 TP23 TP22 Samsung Electronics...
Page 112 Schematic Diagrams 5-10 CONVERGENCE ( SDC12 - 1 ) 5-10 Samsung Electronics...
Page 113 Schematic Diagrams 5-11 CONVERGENCE ( SDC12 - 2 ) Samsung Electronics 5-11...
Page 114 Schematic Diagrams 5-12 PRO SCAN 1 5-12 Samsung Electronics...
Page 115 Schematic Diagrams 5-13 PRO SCAN 2 Samsung Electronics 5-13...
Page 116 Schematic Diagrams 5-14 AV FRONT 5-14 Samsung Electronics...
Page 117 Schematic Diagrams 5-15 VM Samsung Electronics 5-15...
Page 118 Schematic Diagrams 5-16 CONTROL 5-16 Samsung Electronics...
Page 119 Schematic Diagrams 5-17 DY JACK, SENSOR DY JACK SENSOR Samsung Electronics 5-17...
Page 120 Schematic Diagrams 5-18 CG AMP 5-18 Samsung Electronics...
Page 121 Schematic Diagrams 5-19 SUB AMP Samsung Electronics 5-19...
