IC802 VHiTC9457F0-1: Servo/Signal Control (TC9457F0) (1/4)
Pin No. Port Name
1* (OT5)S1 SEG1
2 (OT6)S2 SEG2
3 (OT7)S3 SEG3
4 (OT8)S4 SEG4
5 (OT9)S5 SEG5
6* (OT10)S6 SEG6
7* (OT11)S7 SEG7
8* (OT12)S8 SEG8
9* (OT13)S9 SEG9
10* (OT14)S10 SEG10
11* (CLCK/OT15) SEG11
S11
12* (DATA/OT16) SEG12
S12
13* (SFSY/OT17) SEG13
S13
14* (LRCK/OT18) SEG14
S14
15 (BCK/S15) CDSEL0
P8-0
16 (AOUT/S16) CDSEL1
P8-1
17 (MBOV/S17) DOOR IN
P8-2
18 (IPF/S18) DOOR OUT
P8-3
19 MVDD MVDD1
20 MVSS MVSS1
21* (K0)P1-0 TRAY CLOSE
22* (K1)P1-1 TRAY OPEN
23 (K2)P1-2 PUSEL0
24 (K3)P1-3 PUSEL1
25 (DCREF)P3-0 DISPLAY
26 (ADin1)P3-1 ADIN1
27 (ADin2)P3-2 ADIN2
28* (ADin3)P3-3 MUTE
29 (BUZR/ PU IN
ADin4)P4-0
In this unit, the terminal with asterisk mark (*) is (open) terminal which is not connected to the outside.

FUNCTION TABLE OF IC

Terminal Name Input/Output
Output
Output
Output
Output
Output
Output
Output
Output
Output
Output
Output
Output
Output
Output
Output
Output
Output
Output
Input
Input
Input
Input
Input
Input
Input
Input
Input
Input
Input
Segment signal output to the LCD panel.
Up to 72 segments in a matrix with COM1 to COM4 can be displayed.
All of the S1 to S18 pins can be switched for output ports by a program.
Also, the S15 to S18 pins each can be switched for I/O ports individually.
When set for I/O ports, these pins become Nch open-drain output.
Furthermore, the S11 to S14 and the P8-0 to P8-3 pins can be switched for
use as CD signal (CLCK to IPF) input/output pins by a program.
• CLCK: Subcodes P thru W data readout clock input/output.
Selected between input and output by a command.
• DATA: Subcodes P thru W data output.
• SFSY: Playback system frame sync signal output.
• LRCK: Channel clock (44.1kHz) output.
It outputs a low for L channel and a high for R channel.
Polarity can be inverted by a command.
• BCK : Bit clock (1.4122MHz) output.
• AOUT: Audio data output.
• MBOV: Buffer memory-over signal output.
It outputs a high when buffer overflows.
• IPF : Correction flag output. When AOUT is C2 correction output, it
outputs a high indicating that correction is impossible.
Power supply pins.
Normally, apply a voltage of 4.5 to 5.5V to VDD.
In a backup state (when the CKSTP instruction executed), the device's
current consumption is reduced to 1µA or less, allowing for the supply
voltage to be lowered to 2.0V.
The device is reset and the program starts from address 0 when a voltage
of 2.7V or more is applied to this pin when it is at 0V (power-on reset).
4-bit CMOS I/O ports.
These ports can be set for input or output bit for bit by a program.
These pins can be pulled up to VDD or down to GND by program.
Therefore, they can be used as key input pins. Also, when they are set for
I/O port, a change of state in this input can be used to clear the clock stop
or wait mode.
5-bit CMOS I/O ports.
These ports can be set for input or output bit for bit by a program.
The P3-0 to P4-0 pins serve dual purposes as analog inputs for the internal
6-bit 4-channel A/D converters.
The internal A/D converters can complete conversion in 6 instruction cycles
using a successive approximation method. The required pins can be set for
A/D analog input bit for bit by a program. P3-0 can be set for reference
voltage input, and the internal power supply (MVDD) can be used for this
reference voltage.
The P4-0 pin serves dual purposes as a buzzer output pin.
The buzzer output can be selected from 8 frequencies, 0.625 to 3kHz.
Each selected frequency can be output in one of four modes: continuous,
single, 10Hz intermittent, and 10Hz intermittent at 1Hz interval.
Whether or not to use and how to control the A/D converter and buzzer all
can be set by a program.
