Marantz Reference Series SA-11S1 Specification Sheet

This is the ultimate music disc player. The SA-11S1 joins other products in Marantz's vaunted Reference Series to fulfill the dream of every music-con-
scious audiophile: A system that simply passes music from the artist's mind to the listener's ear. The heavy copper-plated chassis damps unwanted
mechanical resonances while it shields delicate internal circuits from destructive radio frequency and electromagnetic radiation. The resonance-free
FEATURES
Disc Capacity
Multi-ch Capability
SACD-Stereo, CD,
Playback Formats
CD-R/RW
HDAM
Power Transformer
Zero-Impedance Plate
Double Layered Bottom Plates
192kHz/24-Bit
Audio DAC
Display On/Off
Selectable Filters
SACD/CD Text
IN/OUTPUTS
AUDIO
1/1 (Balanced/Unbalanced)
Analog L&R Out
Analog 5.1ch Out
Digital Opt. Out
Digital Coax. Out
Headphone Out
OTHER
D-Bus Remote (RC-5) In/out
SPECIFICATIONS
SACD
1-Bit DSD
Format
2.8224MHz
Sampling Frequency
Dynamic Range
2Hz - 50kHz
Frequency Response (-3 dB)
0.0009%
THD
CD Audio
16-Bit Liner PCM
Format
44.1kHz
Sampling Frequency
Dynamic Range
2Hz - 20kHz
Frequency Response
0.0020%
THD
GENERAL
Color
Aluminum
Faceplate
Aluminum Top RC-11S1SA
Remote
AC 120V 60Hz
Power Requirement
Power Consumption
17 5 / " x 4
Dimensions W x H x D (Inches)
16
Weight (lbs.)
*All specifications, dimensions and weights are subject to change without notice. D&M Holdings, Marantz, Marantz America, Inc. or any of its subsidiaries will not assume any liability for errors within this document.
Marantz America, Inc. • 1100 Maplewood Drive • Itasca, IL 60143 • Phone 630-741-0300 • Fax 630-741-0301 • www.marantz.com ©2005 Marantz America, Inc.
SA-11S1 Super Audio CD Player
1
• New Precision Drive Mechanism with Vibration Free Stabilizing Plate
-
• Accurate Selectable Digital Filters
• Over-sized Troidal Transformer
•
• Triple HDAM
Troidal
• PEC (Phase Error Compensation) Circuit to Eliminate the Phase Delay Error
-
• • Gold Plated Solid Brass Terminals
• Zero Noise LCD Display
•
•
•
-
1
1
-
1/1
114 dB
100 dB
Gold
25W
13 / " x 16 7 / "
16 16
30.8
disc mechanism provides an ultra-stable platform for
both disc and laser optical system. In addition to
Marantz's proprietary HDAM-SA signal transfer mod-
ules, audio path circuits boast custom-selected and,
in some cases, custom-made internal components
chosen for their combined contribution to overall
signal quality. Output filters, long the downfall of
other supposedly "top shelf" players, are custom-
configured and individually selectable for both
SACD and conventional CD playback. The result?
Sound from your treasured CDs approaches that of
today's most advanced SACDs!
® /Channel Construction
