MagicQ User Manual
This is a Window select button. Pressing this button makes the Intensity Window the active window. If the window was not open,
then the window is opened.
The Intensity Window is used to set the level of dimmer channels and the intensity attributes of intelligent heads. The Window
supports two views, Programmer and
Pressing and holding the Intensity button causes the Intensity Window to be temporarily made the active window until the button
is released.
FX
This is a Window select button. Pressing this button makes the FX window the active window. If the window was not open, then
the window is opened.
The FX window enables users to store their favourite FX into a window for quick recall.
FX can also be applied directly from the Group window using the Add FX button.
If no heads are currently selected then the Group Window is opened to enable selection of heads.
Pressing and holding the FX button causes the FX Window to be temporarily made the active window until the button is released.
Pos
This is a Window select button. Pressing this button makes the Pos Window the active window. If the window was not open, then
the window is opened.
The Pos Window is used to set and
selection of Palette entries from the
It also supports the Flip function for moving heads.
Pressing and holding the Pos button causes the Pos Window to be temporarily made the active window until the button is released.
Colour
This is a Window select button. Pressing this button makes the Colour Window the active window. If the window was not open,
then the window is opened.
The Colour Window is used to set and
allows selection of Palette entries from the
Pressing and holding the Colour button causes the Colour Window to be temporarily made the active window until the button is
released.
Pressing the colour button repeatedly cycles through the different colour views.
Beam
This is a Window select button. Pressing this button makes the Beam Window the active window. If the window was not open,
then the window is opened.
The Beam Window is used to set and
allows selection of Palette entries from the
Pressing and holding the Beam button causes the Beam Window to be temporarily made the active window until the button is
released.
Pressing the beam button repeatedly cycles through the different beam pages.
Next Head
Used to select the next head from the currently selected heads. See
Prev Head
Used to select the previous head from the currently selected heads. See
Locate
Pressing LOCATE, locates
Fan
Preset.
modify the position attributes of intelligent heads. The Pos Window also displays and allows
Position Palette.
modify the colour attributes of intelligent heads. The Colour Window also displays and
Colour Palette.
modify the beam attributes of intelligent heads. The Beam Window also displays and
Beam Palette.
all the selected heads.
FX are applied to the currently selected heads.
selecting individual heads.
selecting individual heads.
339 / 348
