MagicQ User Manual
Chapter 30

ChamSys Remote Protocol Commands

ChamSys remote protocol consists of simple commands consisting of a list parameter values separated by commas ',' and ending
in a character A to Z (or a to z). Commands can contain spaces, tabs, and carriage returns; they are all ignored.
The remote protocol is split into remote playback commands and remote programming commands.

30.1 Remote Playback Commands

The commands are:
<playback number> A
<playback number> R
<playback number> T
<playback number> U
<playback number> G
<playback number> S
<playback number> B
<playback number> F
<playback number> , <level> L
<playback number> , <cue id> , <cue id dec>J
<page number> P
<channel number> , <level> I
<program command number> H
The following parameter values are supported
<playback number>
<level>
<page number>
<channel number>
<cue id>
<cue id dec>
So for example, to set dimmer channel 4 to 50% you would use:
4,50I
To jump to Cue id 2.5 on playback 8 you would use:
8,2,50J
Activate playback
Release playback
Test playback (activate with level 100%)
Un-test playback (release with level 0%)
Go on playback
Stop (go back) on playback
Fast back on playback (no fade)
Fast forward on playback (no fade)
Set playback fader level
Jump to Cue Id on playback
Change page
Set intensity channel to level
Remote programming command
a number between 1 and 10
an integer between 0 and 100.
an integer between 0 and 100
an integer between 1 and 32769 DMX channel number
an integer between 1 and 65536
an integer between 0 and 99. Note that for Cue ID 1.5 use
50
