Hy-Security HTG 320 Operator's Handbook Manual

Barrier arm gate opener
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Hy-Security Gate Operators
HTG 320 BARRIER ARM GATE OPERATOR
HANDBOOK
Manufacturers and Designers of Hydraulic Systems
HT12

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HTG 320 and is the answer not in the manual?

Questions and answers

Related Manuals for Hy-Security HTG 320

Summary of Contents for Hy-Security HTG 320

  • Page 1 Hy-Security Gate Operators HTG 320 BARRIER ARM GATE OPERATOR HANDBOOK Manufacturers and Designers of Hydraulic Systems HT12...
  • Page 8 Installation Instructions Installation Instructions Installation Instructions Installation Instructions Installation Instructions HTG 320 Barrier Arm Operator HTG 320 Barrier Arm Operator HTG 320 Barrier Arm Operator HTG 320 Barrier Arm Operator HTG 320 Barrier Arm Operator Be certain to observe the following requirements Use conductors with a rating of at least 75 C.
  • Page 9 8. Test the operator for smooth control of the barrier arm. The arm should stop smoothly at each end of travel. If any adjustments are necessary, follow the HTG 320 adjustments document # HT 45. Also check the reverse delay timer by opening the gate as it is closing. The arm should stop then reverse in a smooth manner.

  • Page 10: Htg 320 Adjustments

    HTG 320 Adjustments The HTG 320 gate operator is pre-adjusted at the factory to perform correctly with the barrier arm shipped. If the arm length, or weight is changed, it will be necessary to re-adjust the gate operator to perform correctly.
  • Page 11 Wire Size Schedules Wire Size Schedules Wire Size Schedules Wire Size Schedules Wire Size Schedules -hp through 5-hp motors Supplying a gate operator with the right electrical service is crucial to the way the performance of the operator the life of its electrical components. If the wire size used is too small, the voltage loss— especially during motor starting—will prevent the motor from attaining its rated horsepower.
  • Page 12 Wire Sizes for Power Wiring, Single Phase Distances are shown in the unshaded boxes 115 V, SINGLE PHASE 208 V, SINGLE PHASE 230 V, SINGLE PHASE Amps 10.0 11.06 14.4 27.2 14.2 16.2 13.6 14.8 27.0 Horse 1/2hp 3/4hp 1hp 1/2hp 3/4hp 1hp 5hp 1/2hp 3/4hp 1hp Power...

  • Page 19: Terminal Strip

    HTG 320 Arm Gate HTG 320 Arm Gate HTG 320 Arm Gate HTG 320 Arm Gate HTG 320 Arm Gate Accessory Connection Accessory Connection Accessory Connection Accessory Connection Accessory Connection In General: : : : : Gate Edge Gate Edge...

  • Page 20: Connection Diagram

    LONG RANGE PUSHBUTTON CONTROL LONG RANGE PUSHBUTTON CONTROL LONG RANGE PUSHBUTTON CONTROL LONG RANGE PUSHBUTTON CONTROL LONG RANGE PUSHBUTTON CONTROL (FOR HTG 320 ONLY) (FOR HTG 320 ONLY) (FOR HTG 320 ONLY) (FOR HTG 320 ONLY) (FOR HTG 320 ONLY)

  • Page 21: Master/Slave Interconnection

    The slave operator will close when the master is signalled to close, unless the slave operator is not yet fully open. The control circuit of the HTG 320 is not compatible with the use of a stop button when the master and slave interconnection is used.
  • Page 22 Detector Installation Guide Detector Installation Guide Detector Installation Guide Detector Installation Guide Detector Installation Guide Loop Basics The vehicle detector passes a small current flow through the “loop” which then becomes an inductive coil. When a vehicle passes over a loop the detector senses the resultant drop in the inductance, and actuates it’s output relay.
  • Page 23 OR This Detector Logic Hy-Security Gate Operators recommends that vehicle detectors be used for free open and obstruction sensing logic only. The exception is in parking applications with our HTG320 operator where detectors may be also used to close the gate. In applications employing our swing , vertical lift, or sliding gate operators, closing logic cannot be used.
  • Page 26 HTG 320 Maintenance 1. Mechanical: The shaft bearings used in the HTG 320 are fully sealed. Very little lubrication is required. Even in heavy use, a single pump of grease once a year is adequate. The crank arm bearing does require lubrication at six month intervals.

  • Page 27: Side View

    444 Series 1300 psi HRG Series 1300 psi HVG Series 2000 psi HTG 360 1000 psi HTG 320-6 1000 psi HTG 320-3 1000 psi Side View Front View HTG 320-2 700 psi The relief valve can be found on the back side (gate side) of the hydraulic power unit. It is the only compo- nent located here and has a hex adjusting head and lock nut.
  • Page 28 We recommend our UNIFLOW hydraulic oil. Part number H 004, as sold in one gallon units by Hy-Security Gate. Automatic transmission fluid may be used, although its performance will be sluggish in freezing weather, unless the operator is well heated. Other hydraulic oils, although technically compatible, tend to be too viscous for proper performance, even in modestly cool weather.

  • Page 29: Troubleshooting

    If the speed of a gate must be changed, contact your Hy-security distributor, or the factory. It is possible that extremely cold weather could affect the speed of the gate, due to the increase in load placed on the system by very thick hydraulic oil and stiff gate hardware.

  • Page 35: Limited Warranty

    (that are a design component of the gate operator) are warranted for one year from the date of shipment. Even though included as part of a Hy-Security gate operator, accessories carrying another manufacturers name plate, (unless a design component of the gate operator) shall carry only the warranty of the specific manufacturer.
