Dear Customer,
Thank you for choosing this quality product from ASKO. We hope it will meet your
expectations and fulfill your needs for many years to come. Scandinavian design
combines clean lines, everyday functionality, and high quality. These are key
characteristics of all our products and the reason they are greatly appreciated
throughout the world.
To ensure that you get the most out of your new machine, we recommend that
you read the operating instructions before using the machine. The operating
instructions also contain information on how to avoid damaging the environment.
Operating Instructions
Tumble dryer
ASKO T754C
Advertisement
Table of Contents
Related Manuals for Asko T754C
Summary of Contents for Asko T754C
-
Page 1: Operating Instructions
Dear Customer, Thank you for choosing this quality product from ASKO. We hope it will meet your expectations and fulfill your needs for many years to come. Scandinavian design combines clean lines, everyday functionality, and high quality. These are key characteristics of all our products and the reason they are greatly appreciated throughout the world. -
Page 2: Table Of Contents
Contents Before using your machine for the Care and cleaning first time Cleaning the lint filter Laundry labels Emptying the condensed water container 15 Safety instructions Cleaning the condenser Safety Cleaning the outside of the machine Installation Troubleshooting Transport/Winter storage The machine will not start Packing material The machine loses all power during a... -
Page 3: Before Using Your Machine For The First Time
Before using your machine for the first time Laundry labels Certain materials are not suitable for tumble- drying. Always check and follow the instructions on each item’s laundry label. You can find more information in the Advice and tips before you tumble-dry chapter. -
Page 4: Safety Instructions
Safety instructions Read the operating instructions and Safety keep them in a safe place! • The machine must not be used for drying items that have been dry-cleaned at home or fabrics that may contain residues of flammable liquids. • The tumble dryer is protected by an overheating cut-out. -
Page 5: Safety Instructions
Safety instructions To minimize the risk of fire in a the manufacturer of the fabric softener or tumble dryer, the following should be product. observed: • Undergarments that contain metal • Items that have been spotted or soaked reinforcements should not be placed in a with vegetable or cooking oil constitute a tumbledryer. -
Page 6: Child Safety
Child safety General WARNING! Do not allow children to play with the tumble dryer. • If the door is opened when a program is running the garments may be very hot, with a risk of burn injuries. • The tumble dryer does not start automatically when the door is closed (if a child pulls the door shut from the inside, for example). -
Page 7: Description Of The Tumble Dryer
Description of the tumble dryer Main power switch Lint filter Condensed water container Outer door Panel Condenser Serial Number... -
Page 8: Advice And Tips Before You Tumble-Dry
Advice and tips before you tumble-dry Static electricity Here are some tips that may help you before you begin tumble-drying. To reduce the risk of static electricity in the laundry after tumble drying you can: Have the clothes been spun? •... -
Page 9: Tumble Drying
Tumble drying Below are step-by-step instructions to help you achieve the best possible tumble-drying results. Sort your fabrics You will achieve the most uniform drying results if the items are made of the same type of material. Do up zips and buttons, fasten belts, sort the items and adjust the load and temperature. -
Page 10: Select The Program
Tumble drying Select the program Programme selector Start Stop Main power switch Options buttons Display window Select a programme by turning the programme selector. An LED lights next to the selected programme. Use the option buttons to select any options. Guidelines as to what specific programs to tumble-dry a load of mixed fabrics, some of can be used for:... -
Page 11: Program Chart
Tumble drying Program chart Here we present the energy and time consumption of a few different programs. The table shows the effect of using different spin speeds when washing the load. Consumption can vary depending on room temperature, humidity, load, variations in the power supply and selected options. For the consumption values given below, the requirements are as follows Temperature of intake air: 23 °C... -
Page 12: Selecting Options
Tumble drying Selecting Options By selecting options, you can Delayed Start tailor a drying program to suit your Select a program and then press Delayed Start. requirements. The available options depend on Press the button to select a delayed start of 1 the selected program. -
Page 13: Drying Programme Finished
Tumble drying Drying programme finished The text "End" is shown on the display for 2 minutes. The machine then turns off. Condensed water The condensed water container must be emptied after each load. Remove the condensed water container, empty out the water and replace the container. -
Page 14: Care And Cleaning
Care and cleaning Cleaning the lint filter 3. Use your hand or a soft cloth to remove the The lint filter must be cleaned after each load. lint from all sides of the filter. If necessary, 1. Lift the filter from the holder in the door. use a damp sponge and a small amount of washing-up liquid to remove any deposits. -
Page 15: Emptying The Condensed Water Container
Care and cleaning Emptying the condensed water container If you have not connected the machine to a separate drain the condensed water container must be emptied after each load. Remove the condensed water container, empty out the water and replace the container. If the condensed water container becomes too full, the program is interrupted and F10 is shown in the display. -
Page 16: Cleaning The Condenser
Care and cleaning Cleaning the condenser The condenser should be cleaned at least three NOTE! times a year. If you have pets, the condenser must be cleaned more frequently. Do not clean the condenser in a dishwasher. 1. Turn off the tumble dryer with the main power 5. -
Page 17: Cleaning The Outside Of The Machine
Care and cleaning Cleaning the outside of the machine NOTE! Clean the outside of the machine and the program panel with a mild cleaner. Do not use The dryer should never be operated without solvents, as these can damage the machine. Do the filters in place, or with damaged filters as not hose down or spray the machine with water. -
Page 18: Troubleshooting
Troubleshooting The machine will not start Drying takes too long • Check that the lint filter is not blocked. See Check the Care and cleaning chapter. • that the door is properly closed. • Empty the condensed water container and •... -
Page 19: Technical Information
Technical information Technical data Height: 850 mm Width: 595 mm Depth: 585 mm Weight (net): 44 kg Cylinder volume: 112 l Max. drying capacity: 6.5 kg Speed: 50-55 rpm Rated power: See type plate. Drum material: Stainless steel Outer casing material: Powder-coated and hot-galvanized sheet steel or stainless steel. -
Page 20: Service
Service Before contacting the service division See the Troubleshooting and Care and cleaning chapters to see whether you can rectify the problem. If you need to contact the service division, make sure that you know the model designation, type designation and serial number. -
Page 21: Installation
The tumble dryer can be placed on top of a 4. Attach the plastic cups for fixing the tumble ASKO washing machine. Use the two foot cups dryer’s front feet to the washing machine’s found in the document bag included with the top cover. -
Page 22: Adjusting The Feet
Installation hand side and tag B on the cup fitted on the 7. Lower the tumble dryer’s front feet into the left-hand side. Then remove the paper from plastic cups and adjust the tumble dryer to the self-adhesive surface under the plastic ensure it is level. -
Page 23: Condensed Water
Installation Condensed water Electrical installation The machine is supplied as shown in Option 1 Connect the machine by plugging it into an (inset). This means that the condensed water earthed wall socket. The electrical wall socket is pumped into the condensed water container, must be placed outside of the installation area which must be removed and emptied by hand. -
Page 24: Door Hanging
Door hanging 1. Hinge pins (top and bottom) 4. Locking hook 2. Cover plate 5. Hinges (left + right side) 3. Plastic plugs (on the upper and lower edges) 6. Plinth... -
Page 25: Follow These Instructions
Door hanging You can choose whether the door is hung on the 6. Move the plastic plugs on the upper and right or the left. lower edges of the door. Use a flat-bladed screwdriver to remove the plugs. Follow these instructions: 7. - Page 26 Your notes...
- Page 27 Your notes...
-
Page 28: Quick Guide
The text ”End” is shown on the display for 2 minutes. The machine then turns off. Clean the lint filter after each load. Close the door. We reserve the right to make changes. www.asko.com TD70.1 T754C W AU/NZ en (04-15)
