Dear Customer,
Thank you for choosing this quality product from ASKO. We hope it will
meet your expectations and fulfill your needs for many years to come.
Scandinavian design combines clean lines, everyday functionality, and
high quality. These are key characteristics of all our products and the
reason they are greatly appreciated throughout the world.
To ensure that you get the most out of your new machine, we recommend
that you read the operating instructions before using the machine. The
operating instructions also contain information on how to avoid damaging
the environment.
Operating Instructions
Tumble dryer
ASKO T754C W
WARNING: Read the instructions before using the machine.
Advertisement
Table of Contents
Related Manuals for Asko T754CT
Summary of Contents for Asko T754CT
- Page 1 Dear Customer, Thank you for choosing this quality product from ASKO. We hope it will meet your expectations and fulfill your needs for many years to come. Scandinavian design combines clean lines, everyday functionality, and high quality. These are key characteristics of all our products and the reason they are greatly appreciated throughout the world.
-
Page 2: Table Of Contents
Contents Before using your machine Care and maintenance instructions for the first time Cleaning the lint filter Important safety instructions Cleaning the outside of the machine Grounding instructions Cleaning the condenser Packing material Troubleshooting Disposal The machine will not start Child safety The machine loses all power during a program... -
Page 3: Before Using Your Machine For The First Time
Before using your machine for the first time Do you need this Use&Care Guide in Spanish? Log on to www.askona.com/customer-care to download. ¿Necesita esta Instrucciones de uso y cuidado en español? Entre en www.askona.com/ customer-care. y descárguesela. Laundry labels Certain materials are not suitable for tumble drying. -
Page 4: Important Safety Instructions
Important safety instructions • The interior of the machine should be SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE cleaned periodically by an authorized ASKO service agent. WARNING! • Do not place items exposed to cooking oils in your dryer. Items contaminated with cooking... -
Page 5: Grounding Instructions
Important safety instructions Grounding instructions Installation A) Grounding instructions for a grounded, See the section Installation instructions. cord-connected appliance Packing material In the event of malfunction or breakdown, grounding will reduce the risk of electric shock Please sort waste materials in accordance with by providing a path of least resistance for local guidelines. -
Page 6: Child Safety
Child safety General WARNING! Do not allow children to play with the tumble dryer. • If the door is opened when a program is running, the garments may be very hot, with a risk of burn injuries. • The tumble dryer does not start automatically when the door is closed (if a child pulls the door shut from the inside, for example). -
Page 7: Description Of The Tumble Dryer
Description of the tumble dryer Main power switch Lint filter Panel Outer door Serial number tag and rating plate Condenser Customer Care Center 1-800-898-1879 www.askona.com... -
Page 8: Advice And Tips Before You Tumble Dry
Advice and tips before you tumble dry Static electricity Here are some tips that may help you before you begin tumble drying. To reduce the risk of static electricity in the laundry after tumble drying, you can: Have the clothes been spun? •... -
Page 9: Operating Instructions
Operating instructions WARNING! To reduce the risk of electric shock or injury to persons, read the "Important Safety Instructions" section before operating this appliance. Below are step-by-step instructions to help you achieve the best possible tumble drying results. Sort your fabrics You will achieve the most uniform drying results if the items are made of the same type of material. -
Page 10: Select The Program
Operating instructions Select the program Program selector Start Stop Main power switch Options buttons Display window Select a program by turning the program selector. An LED lights next to the selected program. Use the option buttons to select any options. Guidelines as to what specific out what works best. - Page 11 Operating instructions Program chart Here we present the energy and time consumption of a few different programs. The table shows the effect of using different spin speeds when washing the load. Consumption can vary depending on room temperature, humidity, load, variations in the power supply, and selected options. For the consumption values given below, the requirements are as follows: Temperature of intake air: 73 °F (23 °C)
-
Page 12: Selecting Options
Operating instructions Selecting Options By selecting options, you can Delayed Start tailor a drying program to suit your Select a program and then press Delayed requirements. The available options depend on Start. Press the button to select a delayed start the selected program. -
Page 13: Press The Start Button
Operating instructions Press the Start button Drying program finished Remaining drying time The text "End" is shown on the display An estimate of the remaining drying time for 2 minutes. The machine then turns will be shown on the display a few minutes after off. -
Page 14: Care And Maintenance Instructions
Care and maintenance instructions Cleaning the lint filter 3. Use your hand or a soft cloth to remove the The lint filter must be cleaned after each load. lint from all sides of the filter. If necessary, 1. Lift the filter from the holder in the door. use a damp sponge and a small amount of washing-up liquid dish soap to remove any deposits. -
Page 15: Cleaning The Condenser
Care and maintenance instructions Cleaning the condenser The condenser should be cleaned at least three NOTE! times a year. If you have pets, the condenser must be cleaned more frequently. Do not clean the condenser in a dishwasher. 1. Turn off the tumble dryer with the main power 5. -
Page 16: Troubleshooting
Troubleshooting The machine will not start Drying takes too long • Check that the lint filter is not blocked. See Check: the Care and maintenance instructions • that the door is properly closed. chapter. • that the main power switch is on. •... -
Page 17: Technical Information
Technical information Technical data Height: 33 1/2'' (850 mm) Width: 23 1/2'' (597 mm) Depth: 23 7/8" (606 mm) Weight (net): 97 lb (44 kg) Cylinder volume: 29,6 gal (112 l) Max. drying capacity: 15 lb (7 kg) Speed: 50-55 rpm Rated power: See serial number tag and rating plate. -
Page 18: Service And Guarantee
ASKO Distribution North America, LLC. 1. Replacement parts or repair labor if the (“ASKO”) warrants to the original purchaser ASKO Product is used in a manner that is (the “ASKO Customer”) of the ASKO product inconsistent with published user or operator (the “ASKO Product”), who purchased the... - Page 19 ASKO OR THE MANUFACTURER AND THEIR problem after checking “Troubleshooting,” then RESPECTIVE PARENTS, SUBSIDIARIES additional help can be obtained by calling ASKO AND AFFILIATES BE LIABLE FOR DAMAGES Customer Care at 1-800-898-1879. Read the OTHER THAN ACTUAL DAMAGES AND IN “Troubleshooting”...
- Page 20 Limited Warranty, please contact ASKO Customer Care at 1-800-898-1879. After your purchase and prior to first use of the ASKO Product, register your ASKO Product with ASKO by utilizing the address information below. Should you need...
-
Page 21: Installation Instructions
The tumble dryer can be placed on top of an To reduce the risk of of severe injury or death, ASKO washing machine. Use the two foot cups follow all installation instructions. found in the document bag included with the... - Page 22 Installation instructions 3. Secure the anti-tip device using the screws as shown in the picture. 7. Push the tumble dryer in under the metal 4. Attach the plastic cups for mounting the brackets. At the same time keep the front tumble dryer’s front feet to the washing edge raised by 7/16"...
-
Page 23: Built-In
ASKO dryers can be installed beneath a cabinet or worktop with a minimum height of 34” (864 mm). There must be a gap of about 1/2” (12 mm) all around the machine and a minimum gap of 1"... -
Page 24: Condensed Water
Installation instructions Install in a closet Condensed water ASKO's front panel controls make it possible Install the dryer so the condensed water will to install the washers and dryers in a closet. continuously flow into a drain or sink. To do this, Make sure there is a ½”... -
Page 25: Electrical Installation
Electric models of the dryer are manufactured the washing machine or an equivalent. for a 3-wire connection system. The dryer frame ASKO washers rated 208–240 V have two is grounded by a link to the neutral conductor internal fuses of 15 A each. - Page 26 Installation instructions 5. Connect ground (center) wire of power Connecting a 3-wire Power Cord supply cord to the center, silver-colored WARNING! terminal screw. Tighten screw. 6. Connect the other wires to outer screws. Before starting this procedure, be sure the 7.
- Page 27 Installation instructions terminal block opening. 4. Remove center terminal block screw. 5. Remove ground wire (green with yellow stripes) from external ground connector screw and remove from center terminal block. 6. Connect ground (green) wire of cord to external ground conductor screw. 7.
-
Page 28: Reversing The Door
Reversing the door 1. Hinge pins (top and bottom) 4. Lock hook 2. Cover plate 5. Hinges (left + right side) 3. Plastic plugs (on the upper and lower edges) 6. Toe kick Customer Care Center 1-800-898-1879 www.askona.com... -
Page 29: Follow These Instructions
Reversing the door You can choose whether the door is hung on the 6. Move the plastic plugs on the upper right or the left. and lower edges of the door. Use a flat screwdriver to remove the plugs. Follow these instructions: 1. - Page 30 Notes Customer Care Center 1-800-898-1879 www.askona.com...
- Page 31 Notes Customer Care Center 1-800-898-1879 www.askona.com...
-
Page 32: Quick Guide
QUICK GUIDE TURN ON THE MAIN POWER SWITCH Load the garments. Close the door. SELECT A PROGRAM AND ANY OPTIONS Turn the program selector to the desired program. PRESS THE START BUTTON DRYING PROGRAM FINISHED The text ”End” is shown on the display for 2 minutes. The machine then turns off.
