Summary of Contents for Brivis HX15IN
- Page 1 H E A T I N G Installer’s Manual PLEASE READ THESE INSTRUCTIONS CAREFULLY BEFORE INSTALLING THIS PRODUCT...
- Page 2 Scope This Installer’s Manual is intended to be used as a guideline for the installation of Brivis Gas Fired Central Heaters. It covers only the installation and commissioning of the heater and the allowable flueing configurations. Although recommended return air grilles and allowable duct outlet quantities are specified, it does not cover the actual ducting design required to suit the installation.
-
Page 3: Table Of Contents
13. Thermostat Installation ....15 3.8 Flue Terminal Clearances ....7 13.1 Brivis Networker Installation ...16 13.2 Brivis Programmable and Brivis Manual 4. -
Page 4: General Guidelines
Upon receipt, inspect the exterior for evidence of rough handling in shipment. Ensure that the appliance is labeled correctly for the gas it is intended to be connected to. Immediately report to Brivis any discrepancies or damage. -
Page 5: Installation Of Duct Connection Pops
20mm per metre of lateral run. • The flue must be terminated outside the building in accordance with AS 5601. For StarPro Heaters, termination can be performed using a Brivis Remote Terminal. Refer to Internal Model Fluing instructions - Starpro series on page 5. -
Page 6: Heater Dimensions
2. StarPro Max/Plus Internal Model Guidelines 2.1 Heater Dimensions HX30I, HX35I, MX30I and MX35I HX15I, HX23I and MX21I 2.2 Service Clearances There are 3 methods of installing internal model heaters. The platform and clearance requirements are shown below under each method with accompanying diagrams. Method 1 (Preferred Option) •... -
Page 7: Splitting Internal Model Heaters
In addition, all StarPro internal units can be installed with an option to lay the unit on its side. The unit must be installed with the lay down kit provided by Brivis. When the kit is purchased it will include all components needed to lay the unit on its side as well as complete detailed instructions. -
Page 8: Changing The Return Air Pop Orientation
In specific installations, for example under the floor, it is recommended that a remote terminal be used to terminate the flue on the outside wall of the building. Please refer to instructions supplied with a Brivis Remote Flue Terminal. Figure below depicts typical StarPro PLUS underfloor configuration. -
Page 9: Guidelines
3. StarPro Max/Plus External Model Guidelines 3.1 Heater Dimensions HX30E and MX30E (MX Illustrated) 810 HX HX23E and MX21E (MX Illustrated) 750 HX 3.2 Service Clearances Side A minimum clearance of 500mm must be provided at the side facing away from the house. Front/Back A minimum clearance of 300mm must be provided at each end of the heater. -
Page 10: Installation Of Flashing
3.5 Installation of Flashing The 75 mm flashing must be fitted to ensure the ductwork is adequately weather protected. • Clip flashing into position by placing the lugs of the flashing firmly into the slots either side of cabinet wrap flanges at rear of appliance. -
Page 11: Starpro B-Max Model Guidelines
300mm • From a flue terminal, cowl or combustion air intake. • Below eaves, balconies or other projections. • From the ground, above a balcony or other surface. • To a return wall or external corner. • Measured horizontally, from an opening window, door, non-mechanical air inlet or any other opening into the building (except sub floor ventilation) or 1500mm in direction of discharge. -
Page 12: Flue Terminal Clearances
4.4 Flue Terminal Clearances Heaters should be positioned so that when measured from the edges of the flue the following minimum clearances exist. 75mm • From the wall against which the heater is mounted. • From a drain or soil pipe. 300mm •... -
Page 13: Starpro Max & B-Max Condensate Removal (Hx Models Only)
‘Brivis Network 516 module’ (Part No. B023178) is required, which can then allow for control of up to four zone dampers and a refrigeration relay. Brivis ICE Add-on Cooling sizing information is provided on page 24. -
Page 14: Wiring A Damper Motor To The Heater's Control Module
7.1 Wiring a Damper Motor to the Heater’s Control Module 24 Vac Power Open / Power Close 24 Vac Power Open / Spring Return Damper Motor Damper Motor 240 Vac Power Open / Power Close Damper Motor 8. Classic 2P Wombat Model Guidelines 8.1 Heater Dimensions FLUE OUTLET 2PW 26 and 26XA... -
Page 15: Splitting 2P Wombat Heaters
8.4 Splitting 2P Wombat Heaters The Classic 2P Wombat model heaters can be split in half to allow for ease of installation. To split the heater, follow these simple instructions: • Remove the main fan motor loom access plate located on top of the fan cabinet compartment by removing the single screw. -
Page 16: Guidelines
• All flues must have a bolted flue sleeve connection. 11. Ducting Information Good duct design and sizing are essential to every Brivis Central Heating system. Use the Brivis “SuperSizeGuide” and technical data within this manual for the best results and follow these guidelines: •... -
Page 17: Outlet Guide
. This grille would be suitable for a StarPro Plus MX21 heater provided the grille does not have a filter fitted. 12. Outlet Guide The outlet chart provides recommendations based on using the Brivis “SuperSizeGuide” or a system designed using accepted design principles. These figures also relate to typical size registers and diffusers used on domestic heating systems i.e. -
Page 18: Outlet Register Chart
1 outlet fully open, and another outlet half closed (such as a bathroom). Refer to Section 13 for balancing guidelines. *Note: Column D only applies to StarPro Max/Plus heaters and should not be used unless the Brivis Networker has been configured for Adaptive Zoning only. If not refer to column C instead. -
Page 19: Brivis Networker Installation
Wiring the Brivis Networker to a Classic Heater The Brivis Networker can be used with Classic heaters as a Thermostat option, but requires the fitment of a Brivis 519 Classic Interface before this is possible. Please follow the installation instructions supplied with a Brivis 519 Classic... - Page 20 Setting up Dual Brivis Networkers on a System It is possible to install two Brivis Networkers on a single StarPro Max, StarPro Plus & B-Max heater to allow for dual control. This is particularly useful where adaptive zoning is present, to allow for independent zone control from each Brivis Networker.
-
Page 21: Brivis Programmable And Brivis Manual Thermostat Installation
• Remove the Brivis Networker off the backing plate so that the controller is powered down. • Press and hold keys 3 & 5, then place the Brivis Networker on the backing plate ensuring keys 3 & 5 are still depressed. -
Page 22: Add-On Refrigerative Air-Conditioning On Classic Heaters
• All these steps must be carried out by a qualified tradesperson. • If the heater cannot be adjusted to operate in accordance with these instructions, then contact the Brivis Customer Service Centre (contact details are on the back cover of this manual). - Page 23 Starpro Max/Plus, B-Max & Compact Plus Control LCD Display Settings Note All settings are saved automatically as you leave the set up mode. To leave the set up mode and return to normal operation, either leave the control untouched for 20 seconds, or keep pressing the SET button until the normal operation screen resumes, or press and hold the SET button for 3 seconds.
-
Page 24: Starpro Max/Plus & B-Max Commissioning Instructions
14.2 StarPro Max/Plus & B-Max Commissioning Instructions With a correctly designed and installed ducted system, generally, the balancing damper in an outlet should be initially set as follows: • Living areas 100% open • Bedrooms 50% open • Bathrooms, ensuite & Laundry: 25% open Initial Ignition and Gas Inlet Pressure Check •... -
Page 25: Fan Speed/Temperature Settings
Adaptive Zoning functions within the heater. To do this: • Go to the Brivis Networker and close all but one zone. If the system does not have a common zone, leave only the zone key that operates the least number of outlets turned ON (ensure this zone does not have less than the minimum number of outlets required for the heater size). -
Page 26: Final Checks (Classic Heaters)
14.3 Classic Commissioning Instructions With a correctly designed and installed ducted system, generally, the balancing damper in an outlet should be initially set as follows: Living areas: 100% open. Bedrooms: 50% open. Bathrooms, ensuite & Laundry: 25% open. • Locate the brass burner pressure test point fitting on the burner manifold, remove the test point screw, then attach a manometer to the burner pressure test point. -
Page 27: Technical Specifications
20.5 18.5 0.18 0.27 Upflow 20 XA 20.5 18.5 Upflow 26 117.5 25.5 0.35 0.53 1140 1105 1075 1050 Upflow 26 XA 117.5 25.5 0.39 0.59 1290 1250 1210 1170 Note Brivis reserves the right to change specifications without notice. - Page 28 Copyright – Brivis Climate Systems Pty Ltd All rights reserved. No part of these documents may be used in any way or form without prior written consent from Brivis Climate Systems Pty Ltd. Part Number: B021918 October 2013...
