Introduction
The Hot Stone SMD pedal power supply was designed to be a compact yet versatile solution for
smaller pedal setups. All outputs are completely isolated, filtered and regulated to provide clean,
ripple free DC voltage. Isolation and short circuit protection on each output ensures that there
will be no hum, noise, or pedal interaction.
The Hot Stone SMD provides:
Six isolated outputs with a total, ripple-free current of 1200mA.
Two high current, 400mA, 9 and/or 12V outputs capable of powering Eventide™ Factor,
Strymon™, Boss™ Twin, TC™ Nova, Line6™ modelers.
Four 9V outputs capable of 100mA each.
Custom magnetically shielded toroidal transformer
Short circuit protection on all outlets
Box Contents
Hot Stone SMD
AC power cord
(6) DC cables with 5.5x2.1mm black barrel connectors
(1) DC cables with 5.5x2.5mm blue barrel connectors
(1) DC cable with 3.5mm mini plug
Manual and Warranty
The Hot Stone is a linear power supply designed for low noise and high
output current. Higher currents require higher heat dissipation. The Hot
Stone is designed to radiate heat. This is normal to its operation. However,
care should be taken to keep the top cover clear and freely exposed to air.
Declaration of Conformity
Decibel Eleven declares that this product complies with the European Union Council Directives and Standards
requirements for the Low Voltage Directive (2006/95/EC) and the EMC Directive (2004/108/EC).
The European Union's (EU) WEEE (Waste Electrical and Electronic Equipment) directive is for waste management of
electronic equipment sold into EU countries.The symbol on our product (shown) indicates that this product must not
be disposed of with other waste. It is the user's responsibility to dispose of their waste electrical and electronic
equipment by handing it over to an approved reprocessor or recycler. For more information on proper recycling,
please contact your local city office or Decibel Eleven distributor.
DB-11 HOT STONE OPERATING TEMPERATURE
DECIBEL11.COM
Advertisement
Related Manuals for Decibel Eleven Hot Stone SMD
Summary of Contents for Decibel Eleven Hot Stone SMD
- Page 1 Introduction The Hot Stone SMD pedal power supply was designed to be a compact yet versatile solution for smaller pedal setups. All outputs are completely isolated, filtered and regulated to provide clean, ripple free DC voltage. Isolation and short circuit protection on each output ensures that there will be no hum, noise, or pedal interaction.
- Page 2 Overview Front Panel: 1 Power indicator LED is lit when Hot Stone is powered on. 5.5mm x 2.1mm DC output jacks Rear Panel: 3 AC Input Voltage Switch – set to proper voltage prior to plugging in the Hot Stone. AC Inlet - standard IEC connector.
- Page 3 Output Configuration The Hot Stone SMD has 6 isolated outputs. All outputs are standard barrel type connectors wired “center negative”, which means the outside barrel is +V. This is the standard wiring for most guitar effect pedals. However, there are exceptions. Always check the label on the pedal before connecting, and use a polarity reversal cable if needed (see DC Cables section).
- Page 4 Pedal Specifics BOSS™ pedals are generally powered by one of two types of voltage, identified on the label as “PSA” or “ACA”. Most all BOSS™ pedals are “PSA” type and require standard 9VDC. “ACA” pedals will operate correctly using any 12VDC output on the Hot Stone. BOSS™ Twin pedals require higher current and can be operated from output 1 or 2 at 9V.
