- Page 1 Model DV6200 User Guide DVD Player...
-
Page 2: Introduction
PAGE 2 INTRODUCTION Safety Precautions CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN RISQUE DE CHOC ELECTRIQUE NE AVERTISSEMENT PAS OUVRIR CAUTION : TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. -
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS CAUTION: PLEASE READ AND OBSERVE ALL WARNINGS AND INSTRUCTIONS IN THIS OWNER’S MANUAL AND THOSE MARKED ON THE UNIT. RETAIN THIS BOOKLET FOR FUTURE REFERENCE. This set has been designed and manufactured to assure personal safety. Improper use can result in electric shock or fire hazard. - Page 4 PAGE 4 INTRODUCTION IMPORTANT SAFETY INSTRUCTIONS (Cont’d) 13. Accessories Do not place this product on an unstable cart, stand, tripod, bracket, or table. The product may fall, causing serious injury to a child or adult, and serious damage to the product.
-
Page 5: Table Of Contents
Table of Contents Introduction Safety Precautions......2 IMPORTANT SAFETY INSTRUCTIONS ..3-4 Table of Contents. -
Page 6: Precautions
When the DVD player is not in use, be sure to remove the disc and turn off the power. If you do not use the DVD player for a long period, the unit may not function properly in the future. Turn on and use the DVD player occasionally. -
Page 7: Notes On Discs
About This Owner’s Manual This owner’s manual explains the basic instructions of this DVD player. Some DVD video discs have functions that may not be explained in this owner’s manual. Therefore, some instructions may differ from this owner’s manual, and there may be extra... -
Page 8: Identification Of Controls
PAGE 8 INTRODUCTION Identification of Controls Front Panel POWER indicator POWER button DISPLAY WINDOW OFF Indicator Display Window MP3 indicator Video CD indicator CD indicator MP3 VCD Operating status indicator Angle icon indicator Disc tray PAUSE button OPEN/CLOSE button Display window Remote sensor DIMMER button DVD indicator... -
Page 9: Rear Panel
Dust protection cap *REMOTE CONTROL IN/OUT jacks By connecting this DVD player to another Marantz audio component using a supplied System Control cable, you can remotely operate the components as a single system. • When connecting to component with a remote sensor (such as the SR-14, SR-18, SR-19), be sure to connect the "REMOTE CONTROL IN"... -
Page 10: Remote Control
PAGE 10 INTRODUCTION Identification of Controls (Cont’d) REMOTE CONTROL You will find instructions for each of the remote control functions in the appropriate sections of this instruction manual. POWER button REPEAT button SETUP button SUBTITLE button AUDIO button ***TOP MENU button SELECT/ENTER button OSD button ZOOM button... -
Page 11: Identification Of Controls
Do not expose the remote sensor of the DVD player to a strong light source such as direct sunlight or illumination. If you do so, you may not be able to operate the DVD player with the remote control. Notes on the remote control Point the remote control at the remote sensor on the DVD player. -
Page 12: Connections
Notes Refer to the owner’s manual of your TV as well. Before you connect the DVD player to your TV, be sure to turn off the power and unplug both units from the wall outlet before making any connections. Connect the DVD player to your TV directly. If you connect the DVD player to a VCR, the playback picture will be distorted because DVD video discs are copy protected. -
Page 13: Connecting To A Tv Equipped With Component Video Inputs
Notes Refer to the owner’s manual of your TV as well. Before you connect the DVD player to your TV, be sure to turn off the power and unplug both units from the wall outlet before making any connections. Actual labels for component video inputs may vary depending on the TV manufacturer. (ex. Y, R-Y, B-Y or Y, C In some TVs or monitors, the color levels of the playback picture may be reduced slightly or the tint may change. -
Page 14: Connecting To An Audio System
Warning Do not set the Digital Audio Output of this DVD player to “Dolby Digital” unless you are connecting the DIGITAL OUT jack of this DVD player to an AV decoder that has the Dolby Digital decoding function. High volume sound may damage your hearing as well as the speakers (Refer to “Selecting Digital Audio Output”... -
Page 15: Connecting To Optional Audio System
Refer to the owner’s manual of your audio equipment as well. Before you connect the DVD player to other equipment, be sure to turn off the power and unplug all of the equipment from the wall outlet before making any connections. -
Page 16: Enjoying Dolby Pro Logic Surround Sound
Warning Do not set the Digital Audio Output of this DVD player to “Dolby Digital” unless you are connecting the DIGITAL OUT jack of this DVD player to an AV decoder that has the Dolby Digital decoding function. High volume sound may damage your hearing as well as the speakers (Refer to “Selecting Digital Audio Output”... -
Page 17: Enjoying 2 Channel Digital Stereo Sound
Refer to the owner’s manual of your receiver as well. Before you connect the DVD player to other equipment, be sure to turn off the power and unplug all of the equipment from the wall outlet before making any connections. -
Page 18: Basic Operation
If you insert an audio CD, the CD indicator lights up on the display. The title number does not appear. After playing back all of the chapters in the title, the DVD player automatically stops and returns to the menu screen. - Page 19 Use the OPEN/CLOSE button on the remote control or DVD player to open and close the disc tray. Do not push the disc tray while it is moving. Doing so may cause the DVD player to malfunction. Do not push up the disc tray or put any objects other than discs on the disc tray.
-
Page 20: Basic Playback
5 minutes. Automatic power off function After the Screen Saver has been engaged for about 5 minutes, the DVD player will automatically turn itself off. Dimmer Function You can control the Display Window's light in 3 steps. -
Page 21: Special Playback
Special Playback POWER OPEN/CLOSE SETUP REPEAT RANDOM AUDIO SUBTITLE ANGLE SURR. TOP MENU MENU SELECT /ENTER RETURN ZOOM MARKER — SEARCH SCAN SKIP PLAY PLAY STOP STOP PAUSE SLOW PAUSE CLEAR PROGRAM BASIC OPERATION Still Picture (Pause) Press PAUSE during playback. DVD/Video CD The player will be placed in the still picture mode. -
Page 22: Special Playback
To return to normal playback, press PLAY. Notes The sound is muted during slow-motion playback. The DVD player can not play back Video CDs in reverse slow motion. The DVD player can not play back Audio CDs in slow motion. -
Page 23: Operation Using Gui Menu Icons
General Information about GUI Menu Icons This unit features GUI Menu Icons showing disc information (title/chapter/track number, elapsed playing time, audio/subtitle language, angle, and sound) and player information (repeat play, play mode, marker, etc.). Some icons only show the indicated information. Other icons allow the settings to be changed. -
Page 24: Detailed Description Of Each Gui Menu Icon
PAGE 24 OPERATION USING GUI MENU ICONS Detailed Description of each GUI Menu Icon You can view information about a disc and its operational status on the TV screen. Press OSD during playback. [TV screen] DVD GUI To show the current title number and to jump to the desired title number To show the current chapter number and to jump to the desired chapter number... -
Page 25: Advanced Operation
Using a Title Menu Some movie discs may contain two or more titles. If the disc has a title menu recorded on it, the TOP MENU button can be used to select the movie title. (The details of operation differ depending on the disc used.) Selecting a title may not be possible on certain DVD discs. -
Page 26: Changing Subtitle Language
PAGE 26 ADVANCED OPERATION Changing Subtitle Language It is possible to change the subtitle language to a different language from the one selected at the initial settings. (See page 35 for further info.) This operation works only with discs on which multiple subtitle languages are recorded. -
Page 27: Viewing From Another Angle
Viewing from another Angle Some DVDs may contain scenes which have been shot simultaneously from a number of different angles. For these discs, the same scene can be viewed from each of these different angles using the ANGLE button. (The recorded angles differ depending on the disc used.) POWER OPEN/CLOSE... -
Page 28: Repeat Play
PAGE 28 ADVANCED OPERATION Repeat Play Repeating viewing (listening) Press REPEAT during playback. Each time this button is pressed, the TV screen changes as shown below and the disc will repeat a chapter or title (DVD) or a track (CD/Video CD). •... -
Page 29: Storing Markers In Memory To Be Viewed (Listened To) Again
Storing Markers in Memory to be Viewed (Listened to) again Storing a MARKER in the DVD memory is similar to marking your page in a book. It allows you to quickly return to any point on the disc. POWER OPEN/CLOSE SETUP REPEAT RANDOM... -
Page 30: Zoom Feature
Audio CD and Video CD. Random does not work with DVD movie discs. You can playback titles or tracks in random order. (Random playback) The DVD player automatically selects the titles on a DVD video karaoke disc only and plays them back randomly. POWER... -
Page 31: Program Play
Program Play The player plays the tracks on the disc in the order you specify. Note: Program play function is possible only with audio CDs. It does not work with DVD movie discs and Video CDs (Version 2.0). POWER OPEN/CLOSE SETUP REPEAT RANDOM... -
Page 32: Playback With Mp3
PAGE 32 ADVANCED OPERATION Playback with MP3 TOP MENU SELECT /ENTER ZOOM MARKER — SEARCH SCAN PLAY STOP To play an MP3 file repeatedly If you press REPEAT once during play, the current MP3 file will play repeatedly. If you press REPEAT twice during play, the all MP3 files on the disc will play repeatedly. - Page 33 Playback with MP3 (Cont’d) TOP MENU MENU SELECT /ENTER RETURN ZOOM MARKER — SEARCH SCAN SKIP PLAY STOP PAUSE SLOW CLEAR PROGRAM To play an MP3 file repeatedly If you press REPEAT button once during play, the current MP3 file will play repeatedly. If you press REPEAT button twice during play, the all MP3 files on the program list will play repeatedly.
-
Page 34: Initial Settings
PAGE 34 INITIAL SETTINGS Selection of Initial Settings Once the initial settings have been completed, the player can always be operated under the same conditions (especially with DVD discs). The settings will be retained in the memory until they are changed, even if the power is switched off. -
Page 35: Selecting Disc Languages
Selecting Disc Languages This is to select the audio soundtrack language, subtitle language and the language used in title menus or DVD menus which will always be used for every disc to be played back. When you play back a DVD video disc, the DVD player automatically displays the pre-selected subtitle language if it is included on the disc. -
Page 36: Selecting Rating Level And Password
DVDs with ratings higher than your selection will be blocked, unless the correct password is entered again. For example: if you change the level to “5”, the DVD player will not play discs with ratings of “6”, “7” or “8” unless the correct password is entered on the remote control. - Page 37 Selecting Rating Level and Password (Cont’d) POWER OPEN/CLOSE SETUP REPEAT RANDOM AUDIO SUBTITLE ANGLE SURR. TOP MENU MENU 1, 2 SELECT /ENTER RETURN ZOOM MARKER — SEARCH SCAN SKIP PLAY STOP PAUSE SLOW CLEAR PROGRAM To clear your 4-digit password If you forget your password, to clear the current password, follow the procedure below.
-
Page 38: Selecting Tv Aspect
PAGE 38 INITIAL SETTINGS Selecting TV Aspect Select the appropriate screen type according to your TV set; conventional size screen (4:3) or wide-screen (16:9). POWER OPEN/CLOSE SETUP REPEAT RANDOM AUDIO SUBTITLE ANGLE SURR. TOP MENU MENU 1, 2 SELECT /ENTER RETURN ZOOM MARKER —... -
Page 39: Selecting Menu Language
Progressive Scan Digital Audio Output 5.1 Speaker Setup Others • This DVD player support two remote control codes : C1 and C2. • When the unit is shipped from the factory, the remote code is set to C1. • To change the remote control cods, press and hold CLEAR button for at least five seconds. -
Page 40: Selecting Progressive Scan
Otros Off: If you are using the COMPONENT VIDEO OUT jacks, but are connecting the DVD player to a standard (analog) television, set the Progressive mode to “Off”. If you are using the COMPONENT VIDEO OUT jacks for connection to a TV that is compatible with a pro- gressive scan signal, set the Progressive mode to “On”. -
Page 41: Selecting Digital Audio Output
Selecting Digital Audio Output Each DVD disc has a variety of audio output options. Set the player’s Digital Audio Output according to the type of audio system you use. POWER OPEN/CLOSE SETUP REPEAT RANDOM AUDIO SUBTITLE ANGLE SURR. TOP MENU MENU 1, 2 SELECT... -
Page 42: Others
PAGE 42 INITIAL SETTINGS Others The DRC, Vocal, PBC and Video settings can be changed. POWER OPEN/CLOSE SETUP REPEAT RANDOM AUDIO SUBTITLE ANGLE SURR. TOP MENU MENU 1, 2 SELECT /ENTER RETURN ZOOM MARKER — SEARCH SCAN SKIP PLAY STOP PAUSE SLOW CLEAR... -
Page 43: Table Of Languages And Their Abbreviations
Table of Language and Their Abbreviations Enter the appropriate code number for the initial settings “Audio”, “Subtitle” and/or “Menu” (See page 35). Code Language Code 6565 Afar 7079 6566 Abkhazian 7082 6570 Afrikaans 7089 6577 Ameharic 7165 6582 Arabic 7168 6583 Assamese 7176... -
Page 44: Reference
Management Information that is recorded on a DVD disc. If the Region number described on the DVD disc does not correspond to the Region number of this DVD player, this DVD player cannot play that disc. The Region number of this DVD player is 1. -
Page 45: Before Calling Service Personnel
• Turn on the equipment connected with the audio cable. • Set the Digital Audio Output to the correct position, then turn on the DVD player again by pressing the POWER button. • Clean the disc. • Insert a disc. (Check that the DVD, or audio CD indicator in the DVD display is lit.) -
Page 46: Specifications
PAGE 46 REFERENCE Specifications DVD player/Outputs/Supplied Accessories Power supply Power consumption Weight External dimensions (W X H X D) Signal system Laser Frequency range (audio) Signal-to-noise ratio (audio) Dynamic range (audio) Harmonic distortion (audio) Wow and flutter Operating conditions Video output... - Page 47 P.O. Box 685, Bell Village, Port Louis, Mauritius PO BOX 1280, Sandhausen 69200, Germany A division of Marantz Europe B.V., Building SFF2, P.O. Box 80002, 5600 JB Eindhoven, The Netherlands 14 Malvern Road, Mt. Albert, Auckland, New Zealand Sandkerveien 64, Oslo 0483, Norway P.O.
