2.5 Stop (STOP Mode)

■Switching to STOP Mode
Press the STOP
The MEMRECAM GX-5 normally starts up in the STOP mode. If operating in any modes other than STOP
press the STOP
Recording, playback and storage settings are configured while in STOP mode. Refer to【3 Recording
and Playback Settings】and【4 Save Settings】for additional details.
By pressing the right and left keys
cameras are connected.
■Image Display
When the MEMRECAM GX-5 is first turned on the
DRP enters STOP mode automatically after the
startup sequence is complete. Nine information
areas are superimposed at the top and bottom of
the screen. The [Status] information box shows
that the DRP is in STOP
The superimposed information displayed in blue is
information related to the image saved in the
memory or playback information. "＊" are shown
when the memory is empty.
The memory segment number [SEG] and the
playback speed [Play] are shown whether or not
there is an image recorded in memory.
If there is an image in memory being protected by the Memory Backup unit during startup, the
previously recorded image is displayed after start up.
Important
■JPAD3 Display
In the JPAD 3 <STATUS> display, <MODE> shows
that the DRP is in STOP mode as in Figure 2-12.
After startup, if the memory is empty, the factory
default settings are shown on the <STATUS>
screen. Since [TIME] information cannot be
determined until recording has ended " ＊ " are
shown. In addition the range bar is empty because
there because there is no image in memory.
■Front Panel LED Display
During the STOP mode, the CM LED lights up blue.
button.
button to stop operation and return to STOP mode.
mode.
it is possible to switch between cameras when two or more
Figure 2-11 Image Display [STOP] mode
Figure 2-12 JPAD3 Display <STOP> mode
