Programmable Logic - STMicroelectronics switch/hub Brochure

• Built-in 16 MacroCell PLD for General Purpose Logic
• Similar to standard 22V10 architecture
• Eliminate small PLDs, PALs, 74XXX series discrete logic
• Easy Point-and-Click PLD configuration with PSDsoft Express
• Build:
– Glue logic
– State-machines
– Shifters
– Counters
– Chip-selects for external devices
– Keypad interfaces
– Delay generators
– Clock dividers
– Decoders
– Multiplexers
www.st.com/micropsd

Programmable Logic

Programmable Logic
Easy interface to external devices
State 0
State 3 State 1
State 2
PLD
PAL
74XXX
10
