USERS GUIDE
LOGIC Combi ES
ES24, ES30, ES35
For installation guide see reverse of book
When replacing any part on this appliance, use only spare parts that you can be
assured conform to the safety and performance specification that we require.
Do not use reconditioned or copy parts that have not been clearly authorised by Ideal.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Ideal Boilers LOGIC Combi ES24
Summary of Contents for Ideal Boilers LOGIC Combi ES24
-
Page 1: Users Guide
USERS GUIDE LOGIC Combi ES ES24, ES30, ES35 For installation guide see reverse of book When replacing any part on this appliance, use only spare parts that you can be assured conform to the safety and performance specification that we require. Do not use reconditioned or copy parts that have not been clearly authorised by Ideal. -
Page 2: Electricity Supply
FOR aNy qUERIEs pLEasE RINg ThE IDEaL CONsUMER hELpLINE : 01482 498660 NOTE. BOILER REsET pROCEDURE - To reset boiler, turn mode control knob to reset position and immediately turn knob back to required setting. minimum Clearances Introduction Clearances of 165mm (6 ”) above, 100mm (4”) below, The Logic Combi Es is a wall mounted, room sealed, condensing 2.5mm (1/8”) at the sides and 450mm (17 3/4”) at the front of... -
Page 3: Operation
Central heating operation Winter conditions - i.e. Ch and DhW required. The boiler controls the central heating radiator temperature to a maximum of 80 C, adjustable via the CH temperature control (C). Ensure the mode knob control (D) is set to winter ( The Logic Combi ES is a high efficiency combination boiler which The boiler will fire and supply heat to the radiators but will give is most efficient when operating in condensing mode. -
Page 4: Loss Of System Water Pressure
Loss of system water pressure Condensate Drain The gauge (G) indicates the central heating system pressure. This appliance is fitted with a siphonic condensate trap If the pressure is seen to fall below the original installation system that reduces the risk of the appliance condensate pressure of 1-2 bar over a period of time then a water leak may from freezing. -
Page 5: Troubleshooting
pOINTs FOR ThE BOILER UsER Note. In line with our current warranty policy we would ask that you check through the following guide to identify any problems external to the boiler prior to requesting a service engineers visit. Should the problem be found to be other than with the appliance we reserve the right to levy a charge for the visit, or for any pre-arranged visit where access is not gained by the engineer. -
Page 6: Operation Modes
OpERaTION MODEs DEsCRIpTION DIspLay CODE ON BOILER The boiler is in standby mode awaiting either a central heating call or hot water demand. The boiler has a call for central heating but the appliance has reached the desired temperature set on the boiler. The boiler has a call for hot water but the appliance has reached the desired temperature set on the boiler. -
Page 7: Fault Codes
FaULT CODEs DEsCRIpTION aCTION DIspLay CODE ON BOILER Outside Sensor Failure Reset the appliance - if the boiler fails to operate then please contact Ideal (if under warranty) or alternatively a Gas Safe Registered Engineer if outside of the warranty period. In IE contact a Registered Gas Installer (RGII). - Page 8 Ideal Consumer Helpline Ideal stelrad group pursues a policy of continuing improvement in the design and performance of its products. The right is therefore reserved to vary specification without notice. Tel: 01482 498660 Ideal, P.O. Box 103, National Ave, Kingston Upon Hull, HU5 4JN. www.idealheating.com Tel.
