USER GUIDE
LOGIC+ HEAT
H12 H15 H18 H24 H30
When replacing any part on this appliance, use only spare parts that you can be assured conform to the safety and performance
specification that we require. Do not use reconditioned or copy parts that have not been clearly authorised by Ideal Boilers.
For the very latest copy of literature for specification and maintenance practices visit our website www.idealboilers.com
where you can download the relevant information in PDF format.
February 2019
UIN 215355 A10

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LOGIC+ HEAT H12 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Ideal Boilers LOGIC+ HEAT H12

  • Page 1 When replacing any part on this appliance, use only spare parts that you can be assured conform to the safety and performance specification that we require. Do not use reconditioned or copy parts that have not been clearly authorised by Ideal Boilers.
  • Page 2: Table Of Contents

    Benchmark Commissioning Checklist. You can check your installer by calling Gas Safe Register direct on 0800 4085500. Ideal Boilers is a member of the Benchmark scheme and fully supports the aims of the programme. Benchmark has been introduced to improve the standards of installation and commissioning of central heating systems in the UK and to encourage the regular servicing of all central heating systems to ensure safety and efficiency.
  • Page 3: Boiler Operation

    BOILER OPERATION Legend A. Central Heating Temperature Knob E. Central Heating Economy Setting B. Mode Knob RESTART Button C. Boiler Status G. Function Button D. Burner ‘on’ Indicator BOILER BOILER ºC RESTART TO START THE BOILER EFFICIENT HEATING SYSTEM OPERATION If a programmer is fitted refer to separate instructions for the The boiler is a high efficiency, condensing appliance which will programmer before continuing.
  • Page 4: Condensate Drain

    CONDENSATE DRAIN GENERAL INFORMATION This appliance is fitted with a siphonic condensate trap system MINIMUM CLEARANCES that reduces the risk of the appliance condensate from freezing. Clearance of 165mm above, 100mm below, 2.5mm at the sides However should the condensate pipe to this appliance freeze, and 450mm at the front of the boiler casing must be allowed for please follow these instructions: servicing.
  • Page 5: Points For The Boiler User

    POINTS FOR THE BOILER USER Note. In line with our current warranty policy we would ask that you check through the following guide to identify any problems external to the boiler prior to requesting a service engineers visit. Should the problem be found to be other than with the appliance we reserve the right to levy a charge for the visit, or for any pre-arranged visit where access is not gained by the engineer.
  • Page 6 NORMAL OPERATION DISPLAY CODES DESCRIPTION DISPLAY CODE ON BOILER The boiler is in standby operation awaiting either a central heating call or hot water demand. The boiler has a call for central heating but the appliance has reached the desired temperature set on the boiler.
  • Page 7: Fault Codes

    FAULT CODES DESCRIPTION ACTION DISPLAY CODE ON BOILER Flame Loss 1. Check other gas appliances in the house are working to confirm a supply is present in the property. 2. If other appliances do not work or there are no other appliances, check the gas supply is on at the meter and/or pre payment meter has credit.
  • Page 8 NOTES User’s...
  • Page 9 NOTES User’s...
