Sony DVP-S530D Service Manual page 110

Ref. No. Part No. Description
IC401 8-752-388-68 IC CXD1930Q
IC402 8-759-567-34 IC KM416S1020CT-G10T
IC403 8-759-567-34 IC KM416S1020CT-G10T
IC404 8-759-486-55 IC NJM2370U33-TE2
IC501 8-752-392-50 IC CXD1901R (S530D/S550D/S705D)
IC502 8-752-390-12 IC CXD1857Q (S550D/S705D)
IC601 8-759-567-30 IC CXD8788Q
IC602 8-759-567-55 IC KM29V16000AT-T (S550D/S705D)
IC701 8-759-567-25 IC CXD8791Q
IC702 8-759-337-40 IC NJM2904V(TE2)
IC801 8-759-522-13 IC BA5981FP-E2
IC802 8-759-567-26 IC BA5983FP-E2
IC803 8-759-338-78 IC BA10324AFV-E2
IC902 8-759-572-26 IC CXD8799N-T2
IC904 8-759-052-52 IC L78M05T-FA
IC905 8-759-572-26 IC CXD8799N-T2 (S530D/S550D/S705D)
IC906 8-759-572-26 IC CXD8799N-T2 (S530D/S550D/S705D)
IC907 8-759-572-26 IC CXD8799N-T2 (S530D/S550D/S705D)
< COIL >
L001 1-414-754-11 INDUCTOR
L402 1-414-754-11 INDUCTOR
< TRANSISTOR >
Q801 8-729-015-74 TRANSISTOR UN5111-TX
Q802 8-729-905-35 TRANSISTOR 2SC4081-R
Q803 8-729-905-35 TRANSISTOR 2SC4081-R
< RESISTOR >
R001 1-216-833-11 METAL CHIP
R002 1-216-833-11 METAL CHIP
R003 1-216-833-11 METAL CHIP
R004 1-216-821-11 METAL CHIP
R005 1-216-821-11 METAL CHIP
R006 1-216-821-11 METAL CHIP
R007 1-216-864-11 METAL CHIP
R009 1-216-864-11 METAL CHIP
R010 1-216-801-11 METAL CHIP
R014 1-216-801-11 METAL CHIP
R036 1-216-821-11 METAL CHIP
R037 1-216-825-11 METAL CHIP
R040 1-216-864-11 METAL CHIP
R044 1-216-829-11 METAL CHIP
R045 1-216-833-11 METAL CHIP
R053 1-216-833-11 METAL CHIP
R202 1-216-801-11 METAL CHIP
R203 1-216-833-11 METAL CHIP
R204 1-216-833-11 METAL CHIP
R205 1-216-845-11 METAL CHIP
R206 1-216-845-11 METAL CHIP
R207 1-216-833-11 METAL CHIP
R212 1-216-813-11 METAL CHIP
R212 1-216-809-11 METAL CHIP
R213 1-216-801-11 METAL CHIP
R217 1-216-833-11 METAL CHIP
R222 1-216-833-11 METAL CHIP
R223 1-216-833-11 METAL CHIP
R225 1-216-833-11 METAL CHIP
Remark
10uH
10uH
10K 5% 1/16W
10K 5% 1/16W
10K 5% 1/16W
1K 5% 1/16W
1K 5% 1/16W
1K 5% 1/16W
0 5% 1/16W
0 5% 1/16W
22 5% 1/16W
22 5% 1/16W
1K 5% 1/16W
2.2K 5% 1/16W
0 5% 1/16W
(S530D/S550D/S705D)
4.7K 5% 1/16W
10K 5% 1/16W
10K 5% 1/16W
22 5% 1/16W
10K 5% 1/16W
10K 5% 1/16W
100K 5% 1/16W
100K 5% 1/16W
10K 5% 1/16W
220 5% 1/16W
(S530D/S550D/S705D)
100 5% 1/16W
(S330)
22 5% 1/16W
10K 5% 1/16W
10K 5% 1/16W
10K 5% 1/16W
10K 5% 1/16W
8-21
Ref. No. Part No. Description
R226 1-216-833-11 METAL CHIP
R227 1-216-813-11 METAL CHIP
R228 1-216-813-11 METAL CHIP
R229 1-216-813-11 METAL CHIP
R230 1-216-813-11 METAL CHIP
R231 1-216-813-11 METAL CHIP
R232 1-216-813-11 METAL CHIP
R235 1-216-864-11 METAL CHIP
R237 1-216-238-91 RES,CHIP
R238 1-216-238-91 RES,CHIP
R238 1-216-230-00 RES,CHIP
R238 1-216-224-91 RES,CHIP
R239 1-216-238-91 RES,CHIP
R239 1-216-230-00 RES,CHIP
R240 1-216-238-91 RES,CHIP
R241 1-216-238-91 RES,CHIP
R241 1-216-230-00 RES,CHIP
R241 1-216-224-91 RES,CHIP
R305 1-218-871-11 RES,CHIP
R306 1-218-831-11 RES,CHIP
R307 1-218-875-11 RES,CHIP
R308 1-216-825-11 METAL CHIP
R309 1-216-838-11 METAL CHIP
R310 1-216-825-11 METAL CHIP
R311 1-216-821-11 METAL CHIP
R313 1-216-833-11 METAL CHIP
R314 1-216-833-11 METAL CHIP
R315 1-216-833-11 METAL CHIP
R316 1-218-855-11 RES,CHIP
R317 1-218-871-11 RES,CHIP
R318 1-216-849-11 METAL CHIP
R319 1-216-831-11 METAL CHIP
R320 1-218-853-11 RES,CHIP
R321 1-218-847-11 RES,CHIP
R322 1-218-871-11 RES,CHIP
R323 1-216-833-11 METAL CHIP
R324 1-216-833-11 METAL CHIP
R325 1-216-833-11 METAL CHIP
R326 1-216-833-11 METAL CHIP
R327 1-216-833-11 METAL CHIP
R328 1-216-833-11 METAL CHIP
R329 1-216-833-11 METAL CHIP
R330 1-216-833-11 METAL CHIP
R331 1-216-833-11 METAL CHIP
R332 1-216-833-11 METAL CHIP
R337 1-216-809-11 METAL CHIP
R338 1-216-833-11 METAL CHIP
R339 1-216-833-11 METAL CHIP
R340 1-216-833-11 METAL CHIP
R341 1-216-809-11 METAL CHIP
R403 1-216-833-11 METAL CHIP
MB-82 MB-85
Remark
10K 5% 1/16W
220 5% 1/16W
220 5% 1/16W
220 5% 1/16W
220 5% 1/16W
220 5% 1/16W
220 5% 1/16W
0 5% 1/16W
47K 5% 1/8W
(S530D: E/S705D)
47K 5% 1/8W
(S530D)
22K 5% 1/8W
(S550D)
12K 5% 1/8W
(S705D)
47K 5% 1/8W
(S705D)
22K 5% 1/8W
(S530D: E)
47K 5% 1/8W
(S530D: E/S705D)
47K 5% 1/8W
(S530D)
22K 5% 1/8W
(S550D)
12K 5% 1/8W
(S705D)
10K 0.50% 1/16W
220 0.50% 1/16W
15K 0.50% 1/16W
2.2K 5% 1/16W
27K 5% 1/16W
2.2K 5% 1/16W
1K 5% 1/16W
10K 5% 1/16W
10K 5% 1/16W
10K 5% 1/16W
2.2K 0.50% 1/16W
10K 0.50% 1/16W
220K 5% 1/16W
6.8K 5% 1/16W
1.8K 0.50% 1/16W
1K 0.50% 1/16W
10K 0.50% 1/16W
10K 5% 1/16W
10K 5% 1/16W
10K 5% 1/16W
10K 5% 1/16W
10K 5% 1/16W
10K 5% 1/16W
10K 5% 1/16W
10K 5% 1/16W
10K 5% 1/16W
10K 5% 1/16W
100 5% 1/16W
10K 5% 1/16W
10K 5% 1/16W
10K 5% 1/16W
100 5% 1/16W
10K 5% 1/16W
