i. unboXing

unpacking your printer

Because your printer contains precision moving parts, it was carefully prepared for shipping, and
requires final assembly by you. Please follow these instructions when assembling. You will need a
medium-small Phillips screwdriver and a good pair of scissors, plus the Allen keys supplied.
i
2
4
in the boX
Before assembly, check that you have all the items shown
below. Some of these you will find packaged within the
cardboard box taped to the printer gantry.
Find a suitable site, such as a
desk or benchtop, with a flat
surface. The V3 has a compact
footprint, but you will want
space nearby for a PC, plus
room for your projects.
Now remove the top tray from
the box and carefully take out
the printer. Ease your fingers
under the base; DO NOT lift
the printer by the top or sides
of the hood, or by the red
hood tabs.
Set the printer down and
check for stability. If it rocks at
all, gently lay it on its side and
adjust the height of the feet
until it is completely stable.
It is preferable, though not
essential, for the printer to be
level during operation. Check
by placing a spirit level on the
base platform, and adjust feet
as necessary.
Vector 3 printer (shown assembled)
Filament reel Scraper tool
Printer parts (shipping box)
2 x 100g PLA 1.75mm
filament in red & white
Power supply
USB cable
Allen keys
Calibration gauge
