Printer Features - SebastianConran Vector 3 Quick Start Manual

enjoy tomorrow's technology today with Vector 3
thank you for buying
the Vector 3 printer.
Exclusively designed by Sebastian Conran Associates,
the VECTOR 3 printer is a sleek, easy-to-use 3D printer
that will add a whole new dimension to your creativity.
Virtually anything that fits the print area can be
designed and printed as a physical 3D object.
The Vector 3 has been created with complete novices
to 3D printing in mind. Aside from normal home
computer skills, no prior special knowledge is required
to operate the printer or to use the printer software.
now, the only limit is your imagination!

printer features

Single jet nozzle 0.4mm
Filament
Can print with biodegradable PLA or strong, recyclable ABS
Layer thickness 0.1~0.4mm
Prints one layer at a time using only the amount of material required
Zero waste
for each object
Prints any object up to
140mm x 140mm x 135mm
Print speed
10–100cm 3 per hour
Printer weight 9kg
Printer dimensions 400mm x 295mm x 356mm
Power requirements 220~240V 50–60 Hz (UK / EU / AUS) • 100~110V 50–60 Hz (JPN / USA)
stl (stl is the acronym for Standard Tessellation Language – the software file
Input format
format used to produce 3D models on 3D printers)
Computer compatibility Windows Vista and above, Mac OS X 10.7 and above
Printer interface software
3D Create & Print (licensed under the Apache licence, v2.0.)
2
Vector 3's top i0 functions
1 3D printing using fused filament technology
Compatible with eco-friendly, plant-based PLA filament
2
(available in a multitude of colours and finishes)
3 Prints at a range of resolutions and rates
4 Able to print objects up to 140 x 140 x 135mm
5 Creates objects with zero waste
6 Uses coloured LEDs to show its status
Prints straight from stl files
7
Compatible with specially created 3D Create & Print printer interface software
8
(based on Repetier-Host)
9 Compatible with both Mac (OS X 10.7 and above) and Windows (Vista and above)
Vector 3's sleek look was designed by internationally acclaimed product designer
10
Sebastian Conran
• This printer must only be used at the specified voltage, or it may be damaged,
with a risk of fire
• Do not touch the nozzle or the platform with any part of the body while the
printer is working, or immediately after it has finished printing
• If printing with ABS, operate in a well-ventilated but draught-free room, and keep
away from other heat sources. ABS can catch fire and, when burnt, produces a
thick black smoke that is toxic if inhaled
• Always have adult supervision when children are present. Store all small
3D printed parts at a suitable height and away from young children, as they
represent choking hazards
• Tie back long hair and avoid loose clothing when operating the printer
• Protect the printer from exposure to rain or any other water source
• To ensure fault-free operation, store the printer at an ambient temperature in the
range of 15–30°C.
• Store the printer in a location with humidity in the range of 20–50%.
