Page 1: Installation Instructions
Installation instructions User guide Warming drawer OD30WDX1 models Instructions d’installation Guide d’utilisation Le tiroir chau ant Modèles OD30WDX1 US CA... - Page 3 US CA WARNING! The warming drawer is not intended to be used in conjunction with water. DO NOT fill the drawer or warming cavity with water. Doing so could create a shock hazard, resulting in a possible injury. DO NOT use water on grease fires. Turn OFF the warming drawer, then smother the fire with baking soda or use a dry chemical or foam-type fire extinguisher.
-
Page 4: Table Of Contents
Contents US CA SAFETY PRACTICES & PRECAUTIONS FEATURES INSTALLATION INSTRUCTIONS Specifications Base Cabinet Installation Wall Cabinet Installation Step 1 - Removing the Drawer Step 2 - Mounting Installation of Chassis 9-10 Step 3 - Replacing the Drawer OPERATING INSTRUCTIONS Operational Guide Preheat Time and Temperature Selector Proofing Yeast Dough CARE AND MAINTENANCE... -
Page 5: Safety Practices And Precautions
Safety practices and precautions US CA Read and Understand these Precautions Read this Installation Guide thoroughly before installation. This will help to reduce the risk of fire, electric shock, or injury to persons. Remove all packaging materials from your appliance. Install according to instructions. -
Page 6: Safety Practices & Precautions 3
Safety practices and precautions US CA WARNING: This appliance is designed for warming food. Based on safety considerations, never use the warming drawer to warm or heat a room. As with any cooking or heating appliance, never leave the warming drawer unattended when warming food, this could be a fire hazard. -
Page 7: Features
Features US CA Vent Holes Thermostat Control Knob Moist/ Crisp Knob Removable Stainless Steel Tray Power Indicator Power Lens Indicator Light Model and Serial tag location on inside panel Stainless Steel Drawer Fig. 01... -
Page 8: Specifications
Installation US CA Specifications DIMENSIONS (FRONT VIEW) DIMENSIONS (SIDE VIEW) 28-3/16 " 25-1/16 " POWER 23-1/2 " CORD " 10-1/2" 9-3/4 " 29-11/16" " Fig. 02 Fig. 03 Base Cabinet Installation The cabinet depth from the outer edge of the face frame to the inside back of the cabinet or wall should be at least 24”... -
Page 9: Wall Cabinet Installation
Installation US CA Wall Cabinet Installation DOUBLE Wall Oven and Warming SINGLE Wall Oven and Microwave and Drawer Installation Warming Drawer Installation microwave double cut-out wall oven cutout single wall oven cutout + – 10 1/16" 11-3/16" + – 10 1/16" 11-3/16"... -
Page 10: Step 1 Removing The Drawer
Installation US CA STEP 1 Removing the drawer Turn the unit off. Be sure the drawer is cool and no food items or trays are in the drawer. Never attempt to remove the drawer while the unit is on or warm. To remove the drawer, first remove plates, trays, etc., from the drawer. -
Page 11: Step 2 Mounting Installation Of Chassis
Installation US CA STEP 2 Mounting Installation of Chassis The lower rear corners of the cabinet need to provide proper support to the back of the Warming Drawer and the anti-tip mounting clips. A 120 volt AC outlet should be located no further than 36 inches from the back right corner of the Warming Drawer. - Page 12 Installation US CA Slot Slot 20" Center line to Center line for mounting clips Power cord Fig. 12 1-1/2” mounting screws Fig. 13...
-
Page 13: Step 3 Replacing The Drawer
Installation US CA STEP 3 Replacing the drawer WARNING! With the drawer removed, the heating element is exposed. Never turn the unit on while the drawer is removed. Never let children play near or touch the warming drawer while it is not safely installed. Push the slides back into the cabinet while the drawer is removed to prevent accidents. -
Page 14: Operating Instructions
Operating Instructions US CA Operational guide The Warming Drawer is designed to keep previously cooked foods at a safe, warm temperature, for extended periods of time, when operated correctly. It is not designed to cook or reheat food. The Warming Drawer should be pre-heated according to the chart below prior to inserting the food to be warmed. -
Page 15: Care And Maintenance
Care and maintenance US CA Cleaning the warming drawer Be careful cleaning any part of this appliance, particularly the drawer box and back of the drawer face. All parts of the drawer can be cleaned with a hot soapy damp cloth, rinsed, dried and buffed with a heavy pile cloth. -
Page 16: Temperature Settings
Temperature settings US CA Suggested temperatures to keep foods hot FOOD TEMPERATURE SLIDE KNOB COVERED/ POSITION UNCOVERED Beef** Rare Moist Covered Medium Moist Covered Well Done Moist Covered Bacon High Crisp Uncovered Bread Dough Proofing Moist Covered Casseroles Moist Covered Chips High Crisp... -
Page 17: Service
Service US CA How To Obtain Service: Before you call for service: Is the circuit breaker tripped or the fuse blown? Is there a power outage in the area? For warranty service, please contact your local service provider or Fisher & Paykel Customer Care Representative at (888) 936.7872 or go to our website at www.dcsappliances.com and choose “customer care”... -
Page 18: Warranty 16
Warranty US CA Limited warranty When you purchase any new Fisher & Paykel whiteware product for personal or consumer use you automatically receive a one year limited warranty covering parts and labor for servicing within the 48 mainland United States, Hawaii, Washington DC and Canada. In Alaska the limited warranty is the same except that you must pay to ship the product to the service shop or the service technician’s travel to your home. - Page 19 Warranty US CA This warranty does not cover: A. Service calls that are not related to any defect in the product. The cost of a service call will be charged if the problem is not found to be a defect of the product. For example: Correct faulty installation of the product.
- Page 20 Warranty US CA Commercial use If you are using the product in a commercial setting (any use other than a single family dwelling), we agree to repair or replace, without cost to you for parts only, any defective parts, the serial number of which appears on the product.
- Page 21 US CA AVERTISSEMENT! (FR) Le tiroir chauffant n’est pas prévu pour être utilisé avec de l’eau. NE PAS remplir le tiroir ou la cavité chauffante d’eau et ce, pour prévenir tout risque choc, entraînant des blessures éventuelles. NE PAS utiliser d’eau sur les incendies de graisse.
- Page 22 Contenu US CA (FR) MESURES DE SECURITE ET DE PRECAUTION 21-23 CARACTERISTIQUES INSTRUCTIONS RELATIVES A L’INSTALLATION Spécifications Installation de l’élément de base Installation de l’élément mural Étape 1 – Dépose du tiroir Étape 2 – Installation de montage du châssis 28-29 Étape 3 –...
- Page 23 Mesures de sécurité et de précaution US CA (FR) Veuillez lire et bien assimiler ces consignes Veuillez lire attentivement ce manuel d’utilisation et d’entretien avant d’utiliser votre nouvel appareil. Ceci vous permettra de réduire les risques d’incendie, de chocs électriques ou de blessures.
- Page 24 Mesures de sécurité et de précaution US CA (FR) vêtements ou de manches lâches lorsque vous utilisez l’appareil. Certains tissus synthétiques sont extrêmement inflammables et ne doivent pas être portés pendant l’utilisation de l’appareil. Ne recouvrez aucune partie du chauffe-plats avec du papier aluminium. L’utilisation de papier aluminium peut créer un risque d’incendie ou empêcher la circulation de la chaleur et de l’air de ventilation.
