- Page 1 WARMING DRAWER MINIMAL WB60SDEB2 & WB60SDTEB1 CONTEMPORARY WB60SDEX2 INSTALLATION GUIDE NZ AU UK IE SG...
-
Page 3: Table Of Contents
CONTENTS Safety and warnings Warming drawer models Unpack your product Electrical specifications Parts supplied Tools required Product dimensions - 600mm minimal & contemporary models Product dimensions - 600mm minimal (tall) model Cabinetry dimensions - 600mm minimal & contemporary models Cabinetry dimensions - 600mm minimal (tall) model Installation options Installing the drawer Adjusting the depth... -
Page 4: Safety And Warnings
SAFETY AND WARNINGS WARNING! WARNING! Electric Shock Hazard Tip Hazard Failure to follow this advice may result in This product may tip. Keep children away and electrical shock or death. take care. Failure to follow this advice may result in injury. •... -
Page 5: Warming Drawer Models
SAFETY AND WARNINGS WARMING DRAWER MODELS READ AND SAVE THIS GUIDE WARNING! To reduce the risk of fire, injury to persons or damage when using the appliance, follow the important safety guides listed below. Read all the instructions before using the appliance. Installation Please make this information available to the person installing the product. -
Page 6: Unpack Your Product
UNPACK YOUR PRODUCT ELECTRICAL SPECIFICATIONS Remove the warming drawer and accessories box from the packaging. Recycle the materials All electrical work must be done by a qualified electrician, or a Fisher & Paykel trained and that can be reused. Dispose packaging materials in accordance with local regulations on waste supported service technician. -
Page 7: Parts Supplied
PARTS SUPPLIED TOOLS REQUIRED WARMING DRAWER WARMING DRAWER MINIMAL WB60SDEB2 & WB60SDTEB1 CONTEMPORARY WB60SDEX2 MINIMAL WB60SDEB2 & WB60SDTEB1 CONTEMPORARY WB60SDEX2 SERVICE & WARRANTY SERVICE ET GARANTIE ΣΈΡΒΙΣ ΚΑΙ ΕΓΓΎΗΣΗ SERVIZIO E GARANZIA SERVICE & GARANTIE HUOLTO JA TAKUU SERVICE OG GARANTI USER GUIDE 保... -
Page 8: Product Dimensions - 600Mm Minimal & Contemporary Models
PRODUCT DIMENSIONS - 600MM MINIMAL & CONTEMPORARY MODELS WB60SDE PRODUCT DIMENSIONS A Overall height B Overall width C Overall depth* D Height of chassis E Width of chassis F Depth of chassis** ISOMETRIC G Height of drawer front panel H Depth of drawer front panel and attachment flange PLAN I Depth of open drawer... -
Page 9: Product Dimensions - 600Mm Minimal (Tall) Model
PRODUCT DIMENSIONS - 600MM MINIMAL (TALL) MODEL WB60SDT PRODUCT DIMENSIONS A Overall height B Overall width C Overall depth* D Height of chassis E Width of chassis F Depth of chassis** G Height of drawer front panel ISOMETRIC H Depth of drawer front panel and attachment flange I Depth of open drawer PLAN... -
Page 10: Cabinetry Dimensions - 600Mm Minimal & Contemporary Models
CABINETRY DIMENSIONS - 600MM MINIMAL & CONTEMPORARY MODELS FLUSH INSTALL 13/16 (20mm) PROFILE PLAN WB60SDE CABINETRY DIMENSIONS PROUD INSTALL A Minimum inside height of cavity B Minimum inside width of cavity C Minimum inside depth of cavity D Overall width of cabinetry E Minimum clearance between top of front panel and upper cabinetry panel F Minimum clearance between bottom of front panel and lower cabinetry panel 13/16 (20mm) -
Page 11: Cabinetry Dimensions - 600Mm Minimal (Tall) Model
CABINETRY DIMENSIONS - 600MM MINIMAL (TALL) MODEL FLUSH INSTALL 13/16 (20mm) PLAN PROFILE WB60SDT CABINETRY DIMENSIONS PROUD INSTALL A Minimum inside height of cavity B Minimum inside width of cavity C Minimum inside depth of cavity D Overall width of cabinetry E Minimum clearance between top of front panel and upper cabinetry panel F Minimum clearance between bottom of front panel and lower cabinetry panel 13/16 (20mm) -
Page 12: Installation Options
INSTALLATION OPTIONS STANDALONE INSTALLATION COMBINED WITH SINGLE OVEN This installation is suitable for Minimal, Contemporary or Professional 600mm Warming drawer. This combination is suitable for Minimal, Contemporary or Professional Warming Drawer that A fixed shelf must be installed above the warming drawer. can fully support a 600mm Fisher &... - Page 13 INSTALLATION OPTIONS COMBINED WITH COMPANION PRODUCT COMBINED WITH DOUBLE OVEN This combination is suitable for Minimal, Contemporary or Professional Warming drawer that This combination is suitable for Minimal 600mm Tall Warming drawer that can fully support a can fully support a 600mm Fisher & Paykel companion product. 600mm Fisher &...
-
Page 14: Installing The Drawer
INSTALLATION OPTIONS INSTALLING THE DRAWER COMBINED WITH SINGLE OVEN & COMPANION PRODUCT This combination is suitable for Minimal 600mm Tall Warming drawer that can fully support 600mm Fisher & Paykel single oven and companion product. A shelf is required above the oven to support the companion product. -
Page 15: Adjusting The Depth
ADJUSTING THE DEPTH ADJUSTING THE HEIGHT The depth of the front panel of the warming drawer can be adjusted to align with the The front panel of the warming drawer can be adjusted vertically to align with the surrounding surrounding cabinetry. cabinetry. -
Page 16: Installer Checklist
INSTALLER CHECKLIST PRODUCT OFF USER PRESSES ON/OFF BUTTON FP WARMER DRAWER INTERFACE LOGIC_V1 IMPORTANT! Read all installation instructions in this manual to see if the unit has been correctly installed. ALL OT Ensure that installation has been completed correctly before use. TEMPER MEDIUM Ensure that:... - Page 20 FISHERPAYKEL.COM © Fisher & Paykel Appliances 2020. All rights reserved. The models shown in this guide may not be available in all markets and are subject to change at any time. The product specifications in this guide apply to the specific products and models described at the date of issue.
