MAINTENANCE AND STORAGE

Inspect and tighten all parts of the PROFORM
regularly. The 975s can be cleaned with a soft, damp
cloth. To prevent damage to the console, keep liquids
away and keep the console out of direct sunlight.
BATTERY REPLACEMENT
If the console does not function properly, the batteries
should be replaced. To replace the batteries, refer to
assembly step 11 on page 7.
CRANK ADJUSTMENT
If the arms of the
Crank (14)
become loose,
they should be
tightened in
order to prevent
excessive wear.
35
Loosen the
Crank Nut (35)
on the left arm of
the Crank. Place
the end of a
standard screw-
¨ 975s driver in one of the slots in the Slotted Bearing Nut.
Lightly tap the screwdriver with a hammer to turn the
Slotted Bearing Nut counterclockwise until the arms
are no longer loose. Do not overtighten the Slotted
Bearing Nut. When the Slotted Bearing Nut is proper-
ly tightened, tighten the Crank Nut.
HOW TO STORE THE PROFORM
When the PRO-
FORM
not in use, it can
be folded for
compact storage.
Refer to the
drawing at the
right. Loosen the
Lock Knob (68)
Slotted
on the right side
Bearing
of the Frame (1).
Nut
Slide the Seat
Frame (3) as far
into the Frame
14
as it will go. Tighten the Lock Knob. Store the PRO-
FORM
12
¨ 975s is
1
¨ 975s indoors, away from moisture and dust.
¨ 975S
68
3
