Bittel HWD9888TSD-S User Manual

Table of Contents
1. Introduction to Bittel 38 Series Cordless Phone
1.1 Unique Features
1.2 Main Features
2. Installation
3. Operation
3.1 Off-Hook
3.2 On-Hook
3.3 Answer New Call
3.4 Adjust the Call Volume
3.5 Using the Hold Key
3.6 SPKR, handset and Wireless Base, Handset
calling changeable
3.7 Three-way conference （Two-line model only）
3.8 To redial the last number dialed
3.9 Mute
3.10 Adjust ringer volume
3.11 Memory keys (Only work when outside
power is available)
1. Introduction to the Bittel 38 Series

Cordless Phone.

This series product is professionally designed and
produced for hotels which compile with the standard of
indoor digital cordless phone technology requirements.
According to different frequency standard of each countries
can be adjusted to 2.4GHz, 1.8/1.9GHz DECT6.0..
1.1 Unique Feature
►
Auto-Registration of the handset to the base
Registers the cordless handset to the phone base
automatically for any handsets put to the base for power
charging.
►
Both the phone base and cordless handset have speaker
functions.
►
Better sound quality and longer work distance. Working
distance up to 200 meters in open area.
►
Dual Channel Conversation function. Both of the two line
cordless phone can be used simultaneously
1.2 Main Features
►
There are one or two line models. The Base and
Handset can make/answer any calls freely. One
Base can work with 1—4 Handsets.
►
Support 2.4GHz,1.8/1.9GHz, DECT6.0 standards
Adopt HF numerical coding technical between Base and
Handsets.
3.12 MWL
1
3.13 Register and delete the Handset
1
4. Maintenance and troubleshooting
2
4.1 No ringing or no continually ringing
4.2 Handset doesn't work
4.3 Handset not work momentary
2
4.4 About Battery
3
3
5. Approval
3
5.1 FCC Approval
3
5.2 CE Approval
3
5.3 Jacks
3
6.Service
3
5.1 Warranty
3
5.2 FCC Warranty
3
5.3 Customer Service Center
3
►
Base can answer or dialing calls freely even without
outside power( For two line phone, Line 1 can work
normally) if th PBX's current is higher than 35mA
►
Ringer volume is adjustable
►Data port --for connecting modem and fax machine
►Both the base unit and handset ringer, volume five-
steps
adjustable.
►
10 memory keys stored phone numbers can provide
good
services for the guests
►
Data port ,Hold,Mute
►
Both phone base and handset volume four-level
adjustable.
►
Default 600ms hook switch flash, adjustable and store
►
Redials the last number dialed and dialed number
disappear within 5 minutes (Special configurations
optional
to store the phone numbers)
►
Message waiting light compatible with main PBX, MWL
indicator and withdraw feature
---- Page 1----
USER MANUAL
Cover Models
HWD9888(38)TSD-S (1 line)
HWD9888(38)TSD-T ( 2 line)
4
4
4
4
4
4
4
4
4
4
5
5
