Pilot Communications 68 Service Sheet

Spare parts for Type - 68 Spray Gun
24
21
1 2 2A
22
5 6 7
23
3 4
16
9 10 3 11 12
17
18
19
20
25 26
28
Type 68 Spray Gun - List of spare parts
Sr. No. Description Code No. Sr. No. Description
Spray Gun Type - 68 with S.S. Top Feed Cup
68000S 17
Spray Gun Type - 68 with Plastic Top Feed Cup 68000N
18
1 Air Cap 68001 19
2 Nozzle 68002 20
2A S.S Nozzle # 68003 21
3 Teflon Packing 68005
22
4 Needle Packing Nut 68006
23
5 S.S. Needle 68007
24
6 Needle Spring Box 68008
7 S.S Spring for Needle 68009
25
8 Needle Adjusting Screw 68010
26
9 Air Valve Pin 68011
27
10 S.S. Spring for Air Valve 68012
28
11 Air Valve Packing Box 68013
29
12 Air Valve Packing Box Washer 68014
30
13 Link 68015
#
Accessories
14 Air Valve Washer 68016
* This set contains an air cap, nozzle, needle, air valve
15 Air Valve Locking Nut 68017
pin and packing.
16 S.S. Spring for Air Control 68018
@
Please mention nozzle size while ordering spare part.
S E R V I C E C H E C K S

Troubleshooting

Fault
Not spraying
8
Uneven spray
29
13 14 15
Intermittent
spray
27
Fluid leakage
Code No.
from packing nut
Air Control Valve 68019
Fulcrum Screw 68020
Trigger & Link Screw 68021
Dripping from
Trigger 68022
the nozzle
S.S. Top Feed Cup 0.14 Litre
Complete 68023
Cup Bottom Part 68023A
Washer For Cup 68023B
Plastic Top Feed Cup 0.14 Litre
Manufactured by :
Complete 68024
Air Intake Tube 68026
Manik Machinery Manufacturers Pvt. Ltd.
Air Intake Connector 68027
21/23, Sona Udyog, P. P. Road, Andheri (East), Mumbai 400 069. MH. INDIA
Hose Coupling 68028
Adaptor for side Cup Complete # 68029
Tel.: +91 22 660 47 000 Fax: +91 22 660 47 010
Spanner # 68030
E-mail: info@pilotindia.com
Repair kit # * 68031
www.pilotindia.com
C a u s e
R e m e d y
1. No pressure at the gun 1. Check air supply
2. Needle adjustment Screw not
2. Adjust
properly adjusted.
1. Material build up on air cap/nozzle 1. Clean air cap / nozzle
2. Coating material flow or viscosity 2. Adjust needle
adjustment screw,
incorrect
or Reduce viscosity
1. Insufficient material in cup 1. Fill cup
2. Gun material passage blocked 2. Clean
3. Loose or damaged nozzle 3. Tighten or replace
4. Needle sealing damage. 4. Replace
1. Needle packing damage 1. Replace packing.
1. Damaged nozzle or needle 1. Replace
2. Foreign substances between
2. Clean needle and
fluid tip and needle nozzle in thinner
prevent sealing or Replace.
Conformity to
European Standards
P I L O T S P R A Y G U N
Service Sheet & List of Spare Parts
Type
68
