İçindekiler Genel Kullanım kılavuzu Hakkında ..........3 Sorumluluk................3 Kullanım Kılavuzundaki İşaretler ..........3 Güvenlik CE Deklerasyonu..............4 Kullanım Amacı ve Ömrü............4 Yetkisiz Kullanım..............4 Elektriksel Güvenlik ..............5 Yangın Tehlikesi ..............5 Sevk..................6 Tehlike Durumunda...............6 Genel Bakış Ürün Tanımı ................7 Teknik Veriler ................8 Teslimat Kapsamı ..............8 Ürün Özellikleri ..............8 Montaj Paketten Çıkarma ..............9...
Genel Size uzun yıllar güvenle hizmet verecek olan Fakir TH 2000 Kule tipi Seramik Isıtıcısını satın almış olduğunuz için kutlarız. Bu kullanma kılavuzu almış olduğunuz üründen en iyi per- Kullanım kılavuzu formansı almanız için hazırlanmıştır. Ürünü çalıştırmadan hakkında: önce lütfen kullanma kılavuzunu dikkatle okuyunuz. Bu kıla- vuzu ilerideki kullanımlar için güvenli bir yerde saklayınız.
Güvenlik CE deklarasyonu Cihaz, ürün ve ürün güvenliği yasasına( GPSG) uygundur ve Avrupa Birliği standartlarına (2004/108/EC) ” Elektromanye- tik Uyumluluk ”ve “Düşük Voltaj Direktifi”(2006/95/EC)’ne uy- gun bir şekilde üretilmiştir. Cihazın etiketinde CE işaretini gö- rebilirsiniz. Kullanım amacı ve ömrü Bu cihaz sadece ev kullanımı için tasarlanmıştır. Endüstriyel ve ticari kullanım için uygun değildir.
Aşırı sıcak ortamda çalıştırmayınız. ● Cihazın kablosunda herhangi bir arıza ya da hasar var ise, ci- hazı kullanmayınız ve Fakir Yetkili Servisi’ne başvurunuz. ● Cihazın gücüne uygun uzatma kablosu kullanınız. ● Cihaz kullanımda değilken, cihazın yerini değiştirirken, ciha- zın parçalarını...
Tehlike veya kaza durumunda, derhal fişi çekin. Tehlike durumunda UYARI! Arızalı bir cihazı çalıştırmayınız. Elektrik çarpma ve yangın tehlikesi vardır. Fakir Yetkili Servisi’ne başvurmadan önce, sorun giderme bölümünde belirtilen direktifler doğrultusunda sorunun gide- rilmediğinden emin olunuz. NOT! Eğer sorunu kendiniz çözemiyorsanız, lütfen Fakir Yetkili...
Genel Bakış Teknik Veriler Model TH 2000 Referans Kodu 62 07 006 Voltaj / Frekans 220-240V/50Hz Toplam Güç 2000W Güç seviyesi 600/1000/1200/2000 W Hava hızı ≥1.3 m/s Salınım ca. 75° Zamanlayıcı 1-12 saat Ses Seviyesi ≤50dB (A) Devrilme emniyet açısı...
Cihazın mobilya, perde veya diğer yanıcı nesnelere yakın mesafede olmadığından emin olun. Aşağıda cihazın çevre- deki nesneler, duvarlar ve tavanlar arasındaki mesafeyi gösteren krokiyi bulabilirsiniz. Bu mesafeler cihazın rahat hava sirkülasyonunu için belirlenmiştir. 30 cm 30 cm 30 cm TH 2000...
Montaj Ürün Kurulumu Taban Sabitleyici Ana Ünite (Şekil 1) Taban Sabitleyici Cam Taban Ana Ünite (Şekil 2) • Ana üniteyi alt tabanına ulaşabilecek şekilde bir tezgahın üzerine koyunuz. Taban sabit- leyiciyi ünitenin tabanından sökünüz. Şekil 1 • Cam tabanı, ana üniteye taban sabitleyici ile takınız ve iyice sıkınız. Şekil 2 •...
Kullanım UYARI! ● Cihazın düz ve kuru bir zeminde kullanıldığından emin olunuz. ● Prizinin doğru şekilde topraklanmış olduğundan emin olun. ● Prizi 16 A otomatik sigorta ile korunmalıdır. ● Cihazı gücüne uygun uzatma kabloları kullanınız. LCD Gösterge Üst Isıtıcı (PTC) Alt Isıtıcı...
Kullanım Cihazı Açma ● Cihazın arkasında bulunan ana şalter (açma/kapama) düğmesine basın. (BEKLEME MODU) ● Cihazı etkinleştirmek için bekleme modundayken cihazın üst kısmında yer alan açma/kapama düğmesine basın. ● Cihaz kullanıma hazırdır. Aşağıdaki işaretlerin parlak olması cihazın açık olduğunu, sönükse kapalı olduğunu gösterir. ●...
Kullanım Güç Kontrolü ISITICI 1 (HEATER 1) düğmesine basarak Üst Isıtıcı (PTC) da istenilen gücü ayarlayın. Heater 1 Üst Isıtıcı (PTC) Isıtıcı 1 Bir kere basıldığında Düşük Isı 600 Watt İki kere basıldığında Yüksek Isı 1000 Watt Üç kere basıldığında Üst ısıtıcı kapanacak Heater 2 Isıtıcı...
Kullanım Zaman Ayarı:Paneldeki göstergeye 1 kere bastığımızda zaman- TEMP. lama göstergesi yanıp sönecektir. TIMER işaretleriyle istediğiniz zamanı ayarlayabilirsiniz. (0-12 saat) Cihaz ayarlanan sıcaklığa ulaştıktan sonra, otomatik ola- rak kapanır. Salınım Cihaz çalışırken salınımı açmak için SWING düğmesine basınız. Salınım çalışırken düğmeye bastığımızda fonksiyon kapanacaktır.
Temizlik ve Bakım Temizlik ve Bakım • Şekil 1 de görüldüğü gibi hava filtresini çıkartın. • Filtre temizliği: Filtreyi temiz bir suya daldırın ve bekleyin. Daha sonra kurumaya bırakın. Temiz kuru filtreyi Şekil 2 deki arka ızgaranın içine yerleştirin. • Takma işleminin doğru olduğundan emin olun. DİKKAT! Cihaz kullanımda değilken, cihazın yerini değiştirirken, ci- hazın parçalarını...
Ürünlerimiz sıkı kalite kontrollerine tabi tutulmaktadır. Ciha- zın düzgün çalışmaması ihtimali bile bizim için bir üzüntüdür. Eğer sorunu kendiniz çözebilirseniz, Fakir Yetkili Servis’ine başvurmadan önce kontrol ediniz. Sorunu kendiniz çözemiy- orsanız, lütfen Fakir Yetkili Servis’i ile irtibata geçiniz. UYARI! Arıza çözümü sırasında cihazın fişini prizden çıkarınız.
Kullanım Sonrası Cihazın geri dönüşüm Cihazın kullanım ömrünün bitmesi halinde, elektrik kablosu- noktalarına bırakılması nu keserek kullanılamayacak hale getiriniz. Ülkenizde mevcut bulunan yasalara göre, bu tür cihazlar için özel olarak belirlenmiş çöp kutularına cihazı bırakınız. Elektriksel atıklar, normal çöplerle birlikte atılmamalıdır. Cihazı...
Page 18
Table of contents General Information about the operating instructions ......19 Liability................19 Notices in the operating instructions ........19 Safety CE Declaration of Conformity ..........20 Intended use ..............20 Unauthorized use..............20 Children ................20 Electric current..............23 In case of danger..............24 Dispatch................24 In case of defects ...............25 Overview Product description ............26 Technical data..............27...
General Thank you for choosing a Fakir TH 2000 Ceramic Tower Heater. The tower heater was developed and manufactured to gua- Information about the operating instructions rantee a trouble free operation for many years. These operating instructions are intended to enable the safe and proper handling and operation of the appliance.
Compatibility” 2006/95/EC “Low-Voltage Directive.” The appliance bears the CE mark on the rating plate. Fakir reserves the right to change design and equipment. This appliance may only be used for private and commercial purposes in residences and adjoining rooms. Intended use...
Page 21
Safety ● The appliance must not be built into and used in vehicles as it requires special components (e.g. protected heating elements, stronger motors, reinforced anchorage of the components for shock protection, etc.) which must not be used in vehicles. Using the appliance in vehicles of any kind (e.g.
Page 22
Safety WARNING! Danger of overheating and fire ● WARNING of fire hazard! The appliance must not be in- stalled or operated in garages or rooms prone to fire such as stables, wooden sheds, etc. This also applies to rooms where highly flammable vapors or dust can easi- ly form.
Safety Electric current ATTENTION! ● Incorrect voltage can destroy the appliance. Operate the appliance only if the voltage specified on the rating pla- te corresponds to the voltage in your household. ● The socket must be protected with a 16 A automatic cir- cuit breaker.
Safety In case of danger In case of danger or accident, unplug the appliance imme- diately. Dispatch Send the appliance in the original package or a similar, well- padded package to prevent damage to the appliance.
> see Chapter “Troubleshooting”. Notice If you were not able to eliminate a problem yourself, please contact an authorized Fakir / nilco service center or a trained technician in your country. Before calling, have the article no. and appliance / model name at hand.
Overview Model TH 2000 Technical Data Referenc no. 62 07 006 Mains voltage 220-240 V / 50 Hz Power IEC 2000 W Heating stages 600/1000/1200/2000 W Wind speed ≥1.3 m/s Swing ca. 75° Timer 1-12 hours Noise level ≤50dB(A) Tip over protection 40 +/- 10°...
If the mains plug is plugged in, the appliance could accidentally be switched on, resulting in injuries. Minimum clearance distances ATTENTION! These clearance distances are necessary to provide for a free air circulation. 30 cm 30 cm 30 cm TH 2000...
Assembly Assembling Put the master device on a desktop, with the bottom reaching out, unscrew the cover fixer, as Picture Ⅰ showed. Connect the base with the cover fixer, tie the base,as Picture Ⅰ showed. Erect the device, put it an even and stable surface. Infrared remote controll Pull out the battery door at the back side of remote control (see Picture Ⅲ) Pay attention to the battery polarity, and insert the battery to the tray of the door...
Operating Installing the appliance ATTENTION! Make sure that the unit is places on an even, stable and dry surface. ● •Make sure that the outlet is properly grounded. ● •The socket must be protected with a 16 A automatic circuit Connection to the mains breaker.
Operating Switching on ● Press the power switch which is situated at the rear part of the appliance. The appliance is then in the standby mode. ● For switching the appliance on press the on/off key at the top of the appliance. ●...
Operating ● In working condition, press key to shift nether PTC: low HEATER2 heating power/high heating power /off. a) NETHER PTC low heating power: indicator on. b) NETHER PTC high heating power: indicator on. Timer / Temperature ● In working condition, press key to shift between room tem- perature setting and time setting.
Operating Switching off ● To turn off, press the On / Off button at the top of the unit. WARNING! After switching off the unit, the fan motor is still about 10 seconds after the cooling of the PTC heating elements. Dur- ing this cooling, the unit may not be unplugged, or turn off the main switch, otherwise could overheat the PTC heating elements.
WARNING! Repairs and maintenance may by performed only by trai- ned technicians (e.g. Fakir customer service). Only original Fakir replacement parts may be used. Improperly repaired or serviced appliances may pose a danger to the user.
Security systems Overheating protection The heater has a security system that in the cases described below will automatically shutdown. When the unit is overheating and automatically be switched back on. Tip-over safety protection The heater has a Kippsicherungs- switch that the device is already at an inclination angle of 40 + / - 10 °...
Our products are subjected to stringent quality controls. If this appliance should nevertheless fail to function properly, this is a matter of regret for us. Before contacting the au- thorized Fakir service center, check to see if you can elimi- nate the problem yourself. WARNING! Switch off and unplug the appliance before beginning trou- bleshooting.
Page 37
Troubleshooting Kapitel R Fault Possible cause Solution Plug is not plugged. Connector plug. Device does not heat. Switch on the unit with heating Device is not turned on. stages. The socket does not have Try a different outlet. electricity. Switch off the mains plug. Report Power cord is damaged.
Kapitel L Disposal Disposal When the appliance has reached the end of its service life, especially in the event of malfunctions, render the appliance unserviceable by cutting the power cord. Dispose of the appliance in accordance with the applicable environmental regulations for your country. Do not dispose of electrical equipment with the household re- fuse.
