IR Remote Control Function and Data List

W Studio Micro's remote control codes are discrete IR (Infrared) codes. Custom installers may want to have access to the standard
codes that enable the W Studio Micro's remote functions to be programmed into a universal controller. Below are the remote control
function and data lists for these functions:
IR Remote Control Function and Data list for the W Studio Micro Sound Bar
Standard Codes
NEC Transmission Format using Definitive Technology Custom Code (A): 0x0A56
BUTTON Screen Print
Power power symbol
Mute mute symbol
SRC1
SRC2
SRC3
CENTER + CENTER +
CENTER - - CENTER
VOLUME + VOLUME +
VOLUME - - VOLUME
BASS + BASS +
BASS - - BASS
MOVIE MOVIE
MUSIC MUSIC
IR Remote Control Function and Data list for the W Studio Micro Sound Bar
Discrete Codes
NEC Transmission Format using Definitive Technology Custom Code (B): 0x0A58
NAME FUNCTION: W Studio
Power ON DISCRETE_POWER_ON
Power OFF DISCRETE_POWER_OFF
Mute DISCRETE_MUTE
Unmute DISCRETE_UNMUTE
IR codes in Philips Pronto format are available through our customer support group.
Please contact them at info@DefinitiveTech.com or 800-228-7148.
Note: When programming a macro for your home automation system, the W Studio Micro can be
powered on with any of the source select remote commands (SRC1, SRC2, SRC3).
www.definitivetech.com
FUNCTION: W Studio
Power toggle: On / Off (standby)
Power toggle: On/Off (standby)
Select: Source 'Input 1'
Select: Source 'Input 2'
Select: Source 'Input 3'
Center Level: adjust Up (+)
Center Level: adjust Down (-)
Master Volume: adjust Up (+)
Master Volume: adjust Down (-)
Subwoofer Level: adjust Up (+)
Subwoofer Level: adjust Down (-)
Select: 'Movie' audio DSP
processing mode
Select: 'Music' audio DSP
processing mode
Custom Code
DECIMAL Ccode Ccode'
136 0x0A 0x56
138 0x0A 0x56
150 0x0A 0x56
151 0x0A 0x56
152 0x0A 0x56
192 0x0A 0x56
193 0x0A 0x56
212 0x0A 0x56
208 0x0A 0x56
214 0x0A 0x56
210 0x0A 0x56
140 0x0A 0x56
141 0x0A 0x56
Custom Code
DECIMAL Ccode Ccode'
87 0x0A 0x58
88 0x0A 0x58
92 0x0A 0x58
93 0x0A 0x58
owner's manual
Data Code
Dcode Dcode'
0x88 0x77
0x8A 0x75
0x96 0x69
0x97 0x68
0x98 0x67
0xC0 0x3F
0xC1 0x3E
0xD4 0x2B
0xD0 0x2F
0xD6 0x29
0xD2 0x2D
0x8C 0x73
0x8D 0x72
Data Code
Dcode Dcode'
0x57 0xA8
0x58 0xA7
0x5C 0x6D
0c5D 0xA2
