English - NEC MultiSync EA193Mi User Manual

Mount Flexible Arm
This LCD monitor is designed for use with a fl exible arm.
1. Follow the instructions on how Remove Monitor Stand for Mounting to remove the stand.
2. Use the 4 screws removed from the stand to attach the arm to the monitor (Figure F.1).
Caution: Use ONLY the screws (4 pcs) that were removed from the stand to avoid damage to the monitor or stand. To meet
the safety requirements, the monitor must be mounted to an arm which guaranties the necessary stability under
consideration of the weight of the monitor. The LCD monitor should only be used with an approved arm
(e.g. GS mark).
100 mm
Thickness of Bracket (Arm)
100 mm
Figure F.1
2.0~3.2 mm
4 Screws (M4)
(Max Depth: 14 mm)

English-10

Weight of LCD assembly: 4.0 kg MAX
