Hide SSID
SSID
Subnet
Isolate Member
VLAN ID
Channel
Extension Channel
Channel Width
After finishing this web page configuration, please click OK to save the settings.
3 . 1 0 . 2 S e c u r i
3 . 1 0 . 2 S e c u r i
This page allows you to set security with different modes for SSID 1, 2, 3 and 4 respectively.
After configuring the correct settings, please click OK to save and invoke it.
VigorAP 900 User's Guide
make you feeling that you have two independent AP/subnet
functions in one VigorAP 900.
If you disable this function, LAN-A and LAN-B ports are in
the same domain. You could only connect one router (no
matter connecting to LAN-A or LAN-B) in this environment.
Check it to prevent from wireless sniffing and make it harder
for unauthorized clients or STAs to join your wireless LAN.
Depending on the wireless utility, the user may only see the
information except SSID or just cannot see any thing about
VigorAP 900 while site surveying. The system allows you to
set four sets of SSID for different usage.
Set a name for VigorAP 900 to be identified. Default settings
are DrayTek5G-LAN-A and DrayTek5G-LAN-B. When
Enable 2 Subnet is enabled, you can specify subnet interface
(LAN-A or LAN-B) for each SSID by using the drop down
menu.
Choose LAN-A or LAN-B for each SSID. If you choose
LAN-A, the wireless clients connecting to this SSID could
only communicate with LAN-A.
Check this box to make the wireless clients (stations) with the
same SSID not accessing for each other.
Type the value for such SSID. Packets transferred from such
SSID to LAN will be tagged with the number.
If your network uses VLANs, you can assign the SSID to a
VLAN on your network. Client devices that associate using the
SSID are grouped into this VLAN. The VLAN ID range is
from 3 to 4095. The VLAN ID is 0 by default, it means
disabling the VLAN function for the SSID.
Means the channel of frequency of the wireless LAN. You may
switch channel if the selected channel is under serious
interference. If you have no idea of choosing the frequency,
please select AutoSelect to let system determine for you.
With 802.11n, there is one option to double the bandwidth per
channel. The available extension channel options will be varied
according to the Channel selected above. Configure the
extension channel you want.
20 MHZ- the AP will use 20Mhz for data transmission and
receiving between the AP and the stations.
Auto 20/40 MHZ– the AP will use 20Mhz or 40Mhz for data
transmission and receiving according to the station capability.
Such channel can increase the performance for data
transmission.
t y
t y
138
