Batteries Suggestion

mCore's power supply: 3.7V DC — 6V DC
Option 1: Option 2:
4 × AA batteries(Not included)
3.7V lithium battery(Not included) with a
standard 2-pin JST-PH connector.
Support on-board charge via USB cable.
8

Remote Control

Mode 1: Remote
Notice:
manual control
CR2025 button cell battery for remote
control is not included .
Mode 2: Wall
avoidance robot
A B C
Forward
D E
Left
F
0
1 2 3
4 5 6
7 8 9
Suggestion: Play mBots on the flat surface
Line follower robot
Mode 1: Remote manual control
Users can use buttons to control the
direction and speed of mBot.
Mode 2: Wall avoidance robot
A robot that can avoid walls and obstacles
Right
while moving.
Backward
Mode 3: Line follower robot
Line follower is a robot that can follow a
Set the speed
path. The path can be visible like a black
of the robot.
line on a white surface (or vice-versa)
9
