Summary of Contents for PureAir Motion
- Page 1 Automobile Air Purification Owner’s Manual...
- Page 2 WELCOME Thank you for your purchase of the pureAir Motion. The technology in the unit is designed to clean your vehicle’s breathing space of smoke, bacteria, viruses, VOC’s (Volatile Organic Compounds), dust and other particulates. With minimal cleaning and maintenance, you can keep Motion in its optimal working condition.
-
Page 3: Table Of Contents
TABLE OF CONTENTS Uses & Features ............4 Warnings . -
Page 4: Uses & Features
USES & FEATURES NOTE: Motion is not a medical device and should not be used to alleviate any respiratory issues you may have. Please consult your doctor before using the Motion if you are worried that the machine could cause adverse effects. -
Page 5: Warnings
WARNINGS NOTE: For your safety, please read through these warnings before using Motion. Do not change settings on the unit while driving. Do not place in a location that will obstruct your view while driving. Do not block either air vent. - Page 6 PRODUCT INTRODUCTION / Control Panel & Unit Top Air Vent Out Mode/Fan Speed Fan Speed Indicator Ion Generator Replacement Light Ion Generator Lifetime Reset Clean Filter Light...
-
Page 7: Product Introduction / Unit Rear
PRODUCT INTRODUCTION / Unit Rear Ion Generator DC Power Plug In Filter Rear Cover Release DC Power Adapter Copyright © 2015 GreenTech Environmental, LLC. | All Rights Reserved... -
Page 8: Setup
SETUP Push on the Rear Unit Cover Release Button and slide the plate down and off the unit. Place the DC Plug in the DC Power Plug In and situate the cord in one of its two cable ports along the side of the unit. Replace the Rear Unit Cover. -
Page 9: Setup
SETUP Secure the Power Plug into the Vehicle’s 12V Outlet. Place the unit in a cup holder or another secure location that will not distract the driver. Copyright © 2015 GreenTech Environmental, LLC. | All Rights Reserved... - Page 10 OPERATION NOTE: To improve the Ion Output, use the unit in conjunction with your vehicle’s Air Conditioning. WARNING: Do not change settings on Motion while driving your vehicle. Push the Mode Button once. The unit will now run in Low Output Mode.
-
Page 11: Operation
OPERATION Pushing the Mode Button a third time will turn the unit OFF. NOTE: The unit will save the last mode used when you turn your car OFF and back ON. Copyright © 2015 GreenTech Environmental, LLC. | All Rights Reserved... - Page 12 MAINTENANCE Your Motion will need maintenance from time to time in order to keep it functioning at its best ability. WARNING: Remove the Power Plug from the Vehicle’s 12V Outlet before performing any maintenance. Failure to do so could result in an electrical shock.
-
Page 13: Maintenance
MAINTENANCE Remove the screw holding the Ion Generator in place. Disconnect the Power Cable and Remove the Ion Generator. Replace the Ion Generator and the Screw that holds it in place. Copyright © 2015 GreenTech Environmental, LLC. | All Rights Reserved... - Page 14 Replace the Rear Cover and plug the unit back into the Vehicle’s 12V Outlet. Turn the Motion on and hold the Reset Button for 3+ Seconds. The Ion Generator Indicator Light will flash twice, turn off, and begin monitoring the new Ion Generator.
-
Page 15: Cleaning
CLEANING Your Motion will need cleaning from time to time in order to keep it functioning to its best ability. WARNING: Remove the Power Plug from the Vehicle’s 12V Outlet before performing any cleaning. Failure to do so could result in an electrical shock. - Page 16 CLEANING (continued from page 15) Dry and replace the Rear Cover. Turn the Motion on and hold the Reset Button for 3+ Seconds. The Clean Filter Indicator Light will turn off.
-
Page 17: Product Specifications
PRODUCT SPECIFICATIONS Model Number PA-MOTION-US Voltage 12V DC | .14 A Effective Area 3.6 m Dimensions 6.4” H 2.8” W 2.2” D (162 mm) (72 mm) (55 mm) Weight 8.64 oz. (245g) Modes HIGH MODE LOW MODE Electrical Usage 2.3 W 1.8 W... -
Page 18: Warranty Information
LIMITED WARRANTY INFORMATION Your pureAir Motion (Product) is warranted to be free from all defects in material and workmanship in normal household use for a period of 1 Year from date of purchase. The warranty is granted only to the original purchaser. The warranty is subject to the following provisions: Any damages or malfunctions caused by negligence, abuse, or use not in accordance with the Product Owner’s Manual are not covered by this warranty. - Page 19 NOTES ______________________________________________________________________________________________ ______________________________________________________________________________________________ ______________________________________________________________________________________________ ______________________________________________________________________________________________ ______________________________________________________________________________________________ ______________________________________________________________________________________________ ______________________________________________________________________________________________ ______________________________________________________________________________________________ ______________________________________________________________________________________________ ______________________________________________________________________________________________ ______________________________________________________________________________________________ ______________________________________________________________________________________________ ______________________________________________________________________________________________ ______________________________________________________________________________________________ ______________________________________________________________________________________________ ______________________________________________________________________________________________ ______________________________________________________________________________________________ ______________________________________________________________________________________________ Copyright © 2015 GreenTech Environmental, LLC. | All Rights Reserved...
