Simpson QUIK DRIVE QDBDT75 Operating Instructions

OPERATING INSTRUCTIONS
QUIK DRIVE
READ BEFORE
OPERATING

GENERAL SAFETY RULES

• Always read and understand the tool's operator's manual, tool
marking and the instruction package before starting any work.
• Stay alert, watch what you are doing and use common sense when
using this tool.
• Keep your work area clean and well lit.
• Keep bystanders, children and visitors away when using this tool.
• Do not use tool when you are tired or under the influence of drugs,
alcohol or medication.
• Always wear eye protection when operating or servicing the tool.
• When servicing the tool, use only identical replacement parts.
• Follow instructions regarding maintenance in the tool operator
manual.
• Maintain labels and nameplates. If unreadable or missing, contact
the manufacturer for a replacement.
QUICK START INSTRUCTIONS
1.

DRIVING SCREWS

Be sure screwdriver motor is
in FORWARD.
Start screwdriver motor
before applying pressure.
Apply pressure to keep bit
engaged until screw is fully
driven and clutch releases.
Keep screwdriver motor
running between screws.
QDBDT75
®
Complete instructions inside
2.
3.
4.
www.strongtie.com/products/quikdrive_au

SPECIFIC SAFETY RULES

• While assembling system components, screwdriver motor should
be unplugged from power source.
• Keep hands, feet and head away from the tip (screw outlet) of the
tool.
• Tool can eject screw without being connected to motor or power
source.
• Do not cycle attachment while pointed at any body part.
• If a screw should become jammed in the auto-feed attachment,
immediately disengage the power source and point the tool in a safe
direction.
Flying Objects.
Wear approved
eye protection
when operating
this equipment
Screwdriver motor sold separately
© C2009 SIMPSON STRONG-TIE COMPANY, INC.
SAVE THESE
INSTRUCTIONS
Sharp Objects. Rotating parts.
Sharp objects can Loose clothes, jewelry
puncture hand or long hair can be
and fingers caught in moving
parts
Use with or without
the "Stand-up"
Extension
T-QDBDT75INAU09
