Amrel DK886EX User Manual

12.1” tablet computer
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
American Reliance, Inc.
12.1" TABLET COMPUTER
DK886EX
USER'S GUIDE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DK886EX and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Amrel DK886EX

Summary of Contents for Amrel DK886EX

  • Page 1 American Reliance, Inc. 12.1” TABLET COMPUTER DK886EX USER’S GUIDE...
  • Page 2 Copyright © 2008 American Reliance, Inc. (AMREL) All rights reserved. No part of this publication may be processed; such as reproduced, transmitted, transcribed, stored in a retrieval system, translated into any computer language in any form, or by any means of electronic, mechanical, magnetic, optical, chemical, or others without the prior written permission of the manufacturer.

  • Page 3: Federal Communications Commission Statement

    EMC and Safety Notice Federal Communications Commission Statement This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

  • Page 4: Important Note

    Important Note FCC RF Radiation Exposure Statement: This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This device and its antenna must not be co-located or operated with any other antenna or transmitter. Products with the CE Marking comply with both the EMC Directive (89/336/EEC) and the Low Voltage Directive (73/23/EEC) issued by the Commission of the European Community.
  • Page 5 and the Amendment Directive (93/68/EEC), the procedures given in European Council Directive 99/5/EC and 89/3360EEC. The equipment was passed. The test was performed according to the following European standards. EN 300 328 V.1.4.1 (2003-04) EN 301 489-1 V.1.4.1 (2002-04)/EN 301 489-17 V.1.2.1 (2002-04) EN 50371:2002 EN 60950:2000 UL, TÜV...
  • Page 6 The crossed bin symbol indicates proper disposal is required. For more information on collection, reuse and recycling, please consult local or regional waste administration. You can also contact the dealer for more information on the environmental details of the equipment.

  • Page 7: Table Of Contents

    CONTENTS GETTING STARTED .................... 1 ........................... 1 NPACKING ..........................2 UICK HECK ......................3 ONTROLS AND NDICATORS COMPONENTS AND OPERATIONS ..............7 ............................. 7 OCATION ..........................7 UGGEDNESS ........................7 PERATING YSTEMS AC A ..........................8 DAPTER ............................8 ATTERY POST ........................
  • Page 8 ........................20 RIVE ........................... 20 OUCH CREEN I/O P ........................... 21 ORTS ) ................21 IMENSIONS AND EIGHT WITH UMPER AC A ..........................21 DAPTER ............................ 21 ATTERY ........................22 EYPAD EYBOARD ) ....................22 EHICLE DAPTER OPTIONAL DL-8I/DL-8M ( ) ..................

  • Page 9: Getting Started

    Getting Started GETTING STARTED Unpacking The following components come with your computer. If anything is missing or damaged, please notify the dealer immediately. Computer unit AC Adapter AC Power Cord Utility CD User's Guide Carrying Bag...

  • Page 10: Quick Check

    Getting Started Quick Check Insert the battery into compartment; fix the screw till battery is in position. Attach the AC adapter and charge battery for at least 10 minutes. Turn ON the computer by pressing the power button momentarily. Notice: When ambient temperature is under 0℃, the system may not boot up immediately.

  • Page 11: Controls And Indicators

    Getting Started Controls and Indicators Note: Some of the functions are optional. Front RF device indicator Battery charge/heater activity indicator Charging OFF: Battery full (when no battery installed it’s off, too) Flash: Heater active (heater is an optional device) HDD (Hard Disk Drive) activity indicator Power indicator F1~F6: Function keys, blue font are alternative functions enabled by pressing...
  • Page 12 Getting Started Power button (refer “Timeout/Standby/Wake up”) To enable alternative function keys Sleep button (refer “Timeout/Standby/Wake up”) Display brightness decrease Display brightness increase Function backlight Track point Left button of mouse Rear Secondary battery connector...
  • Page 13 1. Primary battery 2. LAN 3. USB (Universal Serial Bus) 4. USB (Universal Serial Bus) 5. PCMCIA slots or Express Card Right 1. DC jack (2 pin for DK886EX-I, 3 pin for DK886EX-M) 2. Serial port (COM1) 3. RF Device Switch (optional)
  • Page 14 Getting Started 1. ANT Cover 2. Stylus holder 3. ANT Cover Bottom 1. Docking connector 2. External antenna jack (optional)

  • Page 15: Components And Operations

    Components and Operations COMPONENTS AND OPERATIONS Location A clean and moisture-free environment is preferred. Make room for air circulation. Avoid areas with: Sudden or extreme changes in temperature. Extreme heat. Strong electromagnetic fields (near television set, motor rotation area, etc.). Dust or high humidity.

  • Page 16: Ac Adapter

    Components and Operations AC Adapter The AC adapter performs two functions: It powers the computer from an external AC source. It charges the computer battery. The adapter automatically detects the AC line voltage (110V or 220V) and adjusts accordingly. The following are recommended when using the AC adapter: Use a properly grounded AC outlet.
  • Page 17 Components and Operations Turn the computer into standby (by Sleep or Power button) when it is temporarily not in use. Shut down the computer when it will not be in use for long time. Battery Low When the battery is nearly exhausted, the computer gives the following “Battery Low”...

  • Page 18: Boot Up And Post

    Components and Operations memory effect on Lithium Ion battery cells. However, discharge the battery to nearly empty every month will help calibrating the internal gauge Charging the Battery Plug in the AC adapter or vehicle adapter to start the battery charging. If the battery is already full, the sense circuitry will stop high current charge within several minutes.

  • Page 19: Shutdown

    Components and Operations Note: Timeout/Standby works under both AC adapter and battery mode. Some functions may not work under Windows NT or other non-Windows operating systems. Shutdown The following procedure is recommended in shutting down the computer: 1. Save any work you want to keep. 2.

  • Page 20: Replacing Modules

    Components and Operations Plug the Kensington lock into the slot near primary battery and turn lock it. Both the computer and battery are secured. Kensington lock is a widely available 3 party product. Replacing Modules Caution! Turn OFF the power before replacing any module. To remove the modules: 1.

  • Page 21: Hard Disk Drive

    Components and Operations Hard Disk Drive The Hard Disk Drive (HDD) is a 2.5” type standard serial ATA interface data storage device. HDD is user removable. This provides convenience and security. It can ONLY be removed while power is OFF. Note: NEVER drops your HDD module or exposes it to high temperature, high humidity, or any hazardous environment.

  • Page 22: External Backlight Keyboard (Optional)

    Components and Operations External Backlight Keyboard (optional) The external backlight keyboard is equivalent to a full size desktop keyboard plus extra functions. The interface is via USB port. Track point The track point is functionally equivalent to a mouse. Pushing the track point may move the cursor on the screen.
  • Page 23 Components and Operations Mount Docklight 1. Open the rubber cap on the docking connector. 2. Align the docking connector. 3. Attach Docklight. 4. Fix the screws. Docklight ports Top: 1. Docking connector Bottom and Left: 1. Audio jacks (Microphone/Speaker) 2. RGB port 3.

  • Page 24: Stand Unit (Optional)

    Components and Operations 7. USB port 3, 4 (proprietary sealed type) 8. Serial port (COM2) 9. DC jack Stand Unit (optional) Stand unit can hold the system unit and Docklight with adjustable view angle. It can be used in office or in vehicle. There are 2 configuration options: - Stand unit only to accept system unit.
  • Page 25 Components and Operations Please refer the illustration as below:...

  • Page 26: Optional Devices

    Optional Devices OPTIONAL DEVICES Memory Card The memory card will expand main memory to facilitate better system performance. The cards are available as following: 1GB, 2GB Battery battery may mount on the rear. The computer’s A Lithium Ion rechargeable 2 internal charger can detect 2 battery and perform charging accordingly.

  • Page 27: Stand Unit

    Optional Devices Stand Unit This acts as computer holder for office or vehicle operation and can work with or without Docklight. RF Device The RF device are available as following: - GPS - Bluetooth - HSDPA - Wi-Fi...

  • Page 28: Specifications

    Specifications SPECIFICATIONS Intel Core2 Duo (Merom) CPU runs at multiple speeds dependent on CPU type and operating system: The CPU speed switches automatically by detecting AC adapter/battery operation and busy state. Memory System memory Standard: 1GB Expandable 2GB Cache memory Internal level-II 2MB Video memory 224MB (shared RAM)

  • Page 29: I/O Ports

    Specifications I/O Ports Serial port (DB9) LAN jack 1 type-II PCMCIA slots + 1 Express slot or 2 type II PCMCIA slots Docking port USB port DC jack Dimensions and Weight (with Bumper) Width: 310 mm (12.20”) Depth: 255 mm (10.04”) Height: 54 mm (2.13”) Weight:...

  • Page 30: Keypad/Keyboard

    Specifications Dimension: 150 mm (W) x 90 mm (D) x 20 mm (H) Weight: 500 g (1.1 1b.) Keypad/Keyboard Embedded Keypad: Function keys: F1~F6 Optional External USB Keyboard: Number of keys: Key travel: 1.5 mm Function: Emulates standard 101/102-key keyboard Trackpoint: Equivalent to PS/2 mouse Vehicle Adapter (optional)
  • Page 31 Specifications...

  • Page 32: Materials And Recycling

    Specifications Materials and Recycling Materials of the computer are as follows: Cabinet: Magnesium alloy AZ91D UL grade PC+ABS GE C2800 or TN-3813BW Bracket: Aluminum 5052 Steel with Nickel plating Stainless Steel S304 PCB: FR-4, UL 94V0 Battery: Rechargeable Lithium Ion cells Packing: Carton: Unbleached paper Cushion: Recyclable PE...

  • Page 33: Bios Setup

    BIOS Setup BIOS SETUP Press [F2] at boot up to enter BIOS setup. Use arrow keys to select options and [+/-] to modify them. When finished, move to” Exit” and press [Enter] then confirm save by pressing [Y]. Main Menu Phoenix TrustedCore (tm) Setup Utility Main Advanced...

  • Page 34: Ide Channel 0 Master Sub-Menu

    BIOS Setup IDE Channel 0 Master Sub-Menu Phoenix TrustedCore (tm) Setup Utility Main IDE Channel 0 Master [None] Item Specific Help Type: [Auto] User = you enter parameters of hard-disk drive installed Multi-Sector Transfers: [Disabled] at this connection. LBA Mode Control: [Disabled] Auto = autotypes hard-disk drive installed here.

  • Page 35: Ide Channel 0 Slave Sub-Menu

    BIOS Setup IDE Channel 0 Slave Sub-Menu Phoenix TrustedCore (tm) Setup Utility Main IDE Channel 0 Slave [None] Item Specific Help User = you enter parameters Type: [Auto] of hard-disk drive installed Multi-Sector Transfers: [Disabled] at this connection. LBA Mode Control: [Disabled] Auto = autotypes hard-disk 32 Bit I/O:...

  • Page 36: Ide Channel 1 Master Sub-Menu

    BIOS Setup IDE Channel 1 Master Sub-Menu Phoenix TrustedCore (tm) Setup Utility Main IDE Channel 1 Master [None] Item Specific Help Type: [Auto] User = you enter parameters of hard-disk drive installed Multi-Sector Transfers: [Disabled] at this connection. LBA Mode Control: [Disabled] Auto = autotypes hard-disk 32 Bit I/O:...

  • Page 37: Ide Channel 1 Slave Sub-Menu

    BIOS Setup IDE Channel 1 Slave Sub-Menu Phoenix TrustedCore (tm) Setup Utility Main IDE Channel 1 Slave [None] Item Specific Help Type: [Auto] User = you enter parameters of hard-disk drive installed Multi-Sector Transfers: [Disabled] at this connection. LBA Mode Control: [Disabled] Auto = autotypes hard-disk 32 Bit I/O:...
  • Page 38 BIOS Setup General Help Window Pressing <F1> or <Alt-H> on any menu brings up the General Help window that describes in detail the keys and functions for setup. The scroll bar on the right of any window indicates that there is more than one page of information in the window.

  • Page 39: Advanced Menu

    BIOS Setup Advanced Menu Phoenix TrustedCore (tm) Setup Utility Main Advanced Security TPM State Boot Exit Item Specific Help Legacy USB Support: [Enabled] Summary screen: [Disabled] Enable support for Legacy QuickBoot Mode: [Enabled] Universal Serial Bus Extended Memory Testing [None] IGD - Boot Type: [VBIOS Default] PS/2 Mouse...
  • Page 40 BIOS Setup Feature Options Description CRT+LFP LFP-SDVO TV-SDVO CRT+LFP-SDVO CRT+EFP ’Disabled’ prevents any installed PS/2 mouse PS/2 Mouse Disabled from functioning, but frees up IRQ 12. Enabled ’Enabled’ forces the PS/2 mouse port to be Auto Detect enabled regardless if a mouse is present. ’Auto Detect’...
  • Page 41 BIOS Setup Feature Options Description SIO SMC227 These items control the configuration of CONFGURATION various National 393 SIO devices.

  • Page 42: Sio Smc227 Configuration Sub-Menu

    BIOS Setup For most frequently altered setup “SIO SMC227 CONFIDURATION” please refers following: Warning: Incorrect settings in RS485/RS422 of COMx mode may cause SIO component Damage. Must be cautious before Setup. SIO SMC227 Configuration Sub-Menu Phoenix TrustedCore (tm) Setup Utility Advanced SIO SMC227 CONFIGURATION Item Specific Help...
  • Page 43 BIOS Setup Feature Options Description [Disabled] No configuration [2F8-IRQ 3] Set the base I/O address for COM2 COM2 mode RS232 Configure UART mode options: TTL2 [RS232]：External Device [TTL2]：Internal Device COM3 port Disabled Configure COM3 using device options: 3E8-IRQ 10 [Disabled] No configuration [3E8-IRQ 10] Set the base I/O address for COM3...

  • Page 44: Security Menu

    BIOS Setup Security Menu Warning: If you forget user/supervisor password, the computer has to send back to manufacturer and replace EEPROM to make it work again. Phoenix TrustedCore (tm) Setup Utility Main Advanced Security TPM State Boot Exit Item Specific Help Processor Serial Number [Disabled] Set Supervisor Password...
  • Page 45 BIOS Setup Feature Options Description Password on boot Disabled Enables password entry on boot Enabled USB Interface Disabled Control the listed USB Functions by setting the item to the desired value. Enabled AC97 Audio Disabled Control Detection of the AC97 Audio Interface Device.

  • Page 46: Rf Security Control Sub-Menu

    BIOS Setup For most frequently altered setup “RF Security Control” please refers following: RF Security Control Sub-Menu Phoenix TrustedCore (tm) Setup Utility Security RF Security Control: Item Specific Help Wireless Lan: [Disabled] Wireless Lan Control WWAN: [Disabled] GPS: [Disabled] Blue Tooth: [Disabled] –/+ ↑↓...

  • Page 47: Tpm State Menu

    BIOS Setup TPM State Menu Phoenix TrustedCore (tm) Setup Utility Main Advanced Security TPM State Boot Exit Item Specific Help Current TPM State: Enabled and Deactivated Change TPM State: [No Change] Change TPM State –/+ Help ↑↓ Select Item Change Values Setup Defaults ↔...

  • Page 48: Boot Menu

    BIOS Setup Boot Menu Phoenix TrustedCore (tm) Setup Utility Main Advanced Security TPM State Boot Exit Item Specific Help Boot priority order: 1: USB KEY: 2: USB FDC: Keys used to view or 3: USB HDD: configure devices: 4: IDE CD: Up and Down arrows select 5: IDE HDD: a device.

  • Page 49: Exit Menu

    BIOS Setup Exit Menu Phoenix TrustedCore (tm) Setup Utility Main Advance Security TPM State Boot Exit Item Specific Help Exit Saving Changes Exit Discarding Changes Load Setup Defaults Exit System Setup and save Discard Changes your changes to CMOS. Save Changes –/+ Help ↑↓...

  • Page 50: Utilities And Drivers

    Utilities and Drivers UTILITIES AND DRIVERS Note: Most device drivers are available in Windows. Only when the default driver does not work properly you need to install the factory bundled drivers. The utility CD includes most drivers of the computer’s installed devices.

  • Page 51: Audio Driver

    Utilities and Drivers Resolution & Color LCD + RGB 1600x 1200x 16-bit color 1600x 1200x 24-bit color 1600x 1200x 32-bit color 2048x 1536x 16-bit color 2048x 1536x 24-bit color 2048x 1536x 32-bit color The table lists typical display modes only. The system also supports standard video modes with lower resolution and color.

  • Page 52: Pcmcia Driver

    Utilities and Drivers (\DK8EX\Driver\Touchscreen\DP9000\2kxpVista3264\PM...Universal…v1.0.0.8 ), and follow the prompt to complete installation and then restart. PCMCIA Driver Windows The driver is automatically installed under Windows. Mini PCI 1G AX92200 LAN Insert the Driver CD into the CD-ROM. Click Setup.exe in the directory of E:\AX92200\DRIVER\RTL8110S\windows (612) then follow the prompt to complete installation.

  • Page 53: Wireless Manager

    Utilities and Drivers Wireless Manager For flight safety and power saving reason, there is a utility provided easily to enable/disable RF devices of Wireless LAN/WWAN/GPS/Bluetooth in the run time Insert the Driver CD into the CD-ROM. Click setup.exe in the directory of Utilities\Wireless Manager then follow the prompt to complete installation.
  • Page 54 Utilities and Drivers In addition, if you activate “Launch Function key manager at startup”, will be on the task menu automatically after the system is launched. If you activate “Launch On-Screen keyboard at logon” and the log on password is set; On- Screen keyboard will pop-up automatically when system get into/recover from following modes, “Logon/Logoff”, “Standby/Resume”, “Boot/Reboot”, and “Hibernate/Resume”.
  • Page 55 Set the proper file type if necessary, batch file (*.bat) is the default. 2. Open a URL in default browser Input the address of the website, e.g. www.amrel.com 3. Replace with another Key The single key or combination key can be used. For example, press “Ctrl”...
  • Page 56 Utilities and Drivers Simulate mouse button click Used to define two button clicks of the mouse. “Left button click” and “Right button click” are alternatives. 6. Change display output Switch display output among LCD, CRT and DVI. Just only one single mode can exist.
  • Page 57 Utilities and Drivers Please make sure Intel Extreme Graphics 2 driver/Control Panel application is will be on the task menu. Activate the “Graphics installed and this icon Properties …” from “Graphics Options”. In the “Hot Keys”, activate “Enable Hot Keys”.
  • Page 58 Utilities and Drivers In the “Rotation”, activate “Enable Rotation” and set the “Rotation Views” to “Normal”. It is recommended that to set a Function Key to work as “Rotate Screen” with parameter of “Normal” when you have set other keys to act as “Rotate Screen” with parameter of “90”, “180”...
  • Page 59 Utilities and Drivers It results from “Hide modes that monitor cannot display” is enabled. So in such a situation, uncheck this box to enable all rotation views under Control Panel/Display/Display Properties/Setting/Advanced/Monitor.
  • Page 60 Utilities and Drivers If you rotate screen to “Normal”, the “System Properties” windows will pop- 8. Change desktop background color Used to change background color to make display more readable in the day or night. Select a color from the pop-up color palette. 9.

  • Page 61: Maintenance/Service

    Maintenance/Service MAINTENANCE/SERVICE Cleaning ALWAYS turn OFF the power, unplug the power cord and remove the battery before cleaning. The exterior of the system and display may be wiped with a clean, soft, and lint- free cloth. If there is difficulty removing dirt, apply non-ammonia, non-alcohol based glass cleaner to the cloth and wipe.
  • Page 62 Maintenance/Service - Address - Unit serial number - Place and date of purchase or the original invoice number - Date of failure - A DETAILED description of the problems you have encountered including: The operating system, the add-on device installed (if any), the application software, the failure phenomenon, etc.
  • Page 63 Recycled/Recycleable Printed in USA P/N: G630804000B...
