Page 1: User Guide
USER GUIDE Flexpedient AT80 Rugged Android Tablet ®... - Page 2 Date Version Changes July 13, 2015 1.00 Initial release...
- Page 3 Copyright COPYRIGHT NOTICE In no event will the manufacturer be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or inability to use the product or documentation, even if advised of the possibility of such damages. This document contains proprietary information protected by copyright.
-
Page 4: Table Of Contents
Table of Contents INTRODUCTION ....................1 1.1 O ..................... 1 VERVIEW 1.2 F ..................... 2 EATURES 1.3 F ....................2 RONT ANEL 1.4 R ....................3 ANEL 1.5 L ....................3 ANEL 1.6 R ....................4 IGHT ANEL 1.7 T .................... - Page 5 4.10.5 Storage ..................... 28 4.9.6 Battery ....................29 4.10.7 Apps ....................30 4.10.8 Location services ................31 4.10.9 Security ..................... 32 4.10.10 Language & Input................33 4.10.11 Backup & Reset ................35 4.10.12 Add an Account ................36 4.10.13 Date & Time ..................37 4.10.14 Accessibility ..................
- Page 6 List of Figures ® Figure 1-1 Flexpedient AT80 Rugged Tablet ................1 Figure 1-2: Front Panel ........................2 Figure 1-3: Rear Panel ........................3 Figure 1-4: Left Panel ........................3 Figure 1-5: Right Panel ........................4 Figure 1-6: Top Panel ........................4 Figure 1-7: Dimensions in millimeters..................
- Page 7 Figure 4-10: Settings Menu ......................22 Figure 4-11: WIRELESS & NETWORKS Settings ..............23 Figure 4-12: Ethernet configuration ....................24 Figure 4-13: More Settings Menu ....................25 Figure 4-14: Audio Profiles ......................26 Figure 4-15: Display Menu ......................27 Figure 4-16: Storage Menu ......................28 Figure 4-17: Battery Menu ......................29 Figure 4-18: Apps Menu .......................30 Figure 4-19: Location Services ....................31 Figure 4-20: Security Menu ......................32...
-
Page 8: Introduction
Chapter Introduction Overview ® Figure 1-1 Flexpedient AT80 Rugged Tablet ® AT80 Rugged Tablet is an Android-based rugged tablet with an 8” touch The Flexpedient optically bonded LCD screen. At the heart of the system is the Texas Instrument OMAP 4470 Dual-core 1.5GHz CPU. -
Page 9: Features
1.2 Features ® Some of the Flexpedient AT80 Rugged Tablet features include: Multiple colors Android 4.3 8-inch LCD (1024×768), Optically bonded 10-point Capacitive Touchscreen Texas Instrument OMAP 4470 Dual-core 1.5GHz 1GB LPDDR RAM 8 GB Built-in storage ... -
Page 10: Rear Panel
1.4 Rear Panel The rear panel is the location of a 5-megapixel camera. It is also the location for personalized logos. Rear camera Figure 1-3: Rear Panel 1.5 Left Panel The left side panel contains a 1 watt IP67 speaker. Figure 1-4: Left Panel... -
Page 11: Right Panel
1.6 Right Panel The left side panel contains a power jack, USB OTG port, Micro SD card reader, head phone jack, sliding door, and a speaker. The closed sliding door protects Micro SD card reader and head phone jack. Figure 1-5: Right Panel 1.7 Top Panel The top panel contains power button, volume controls, and a light sensor. -
Page 12: Technical Specifications
1.8 Technical Specifications The AT80 technical specifications are listed in the table below. Display LCD Size 8” Brightness (cd/m Max. Resolution 1024 x768 Viewing Angle 85° (H) x 85° (V) Touchscreen 10-point capacitive System Texas Instrument OMAP 4470 Dual-core 1.5GHz Operating System Android 4.3 Memory... - Page 13 I/O Interface Speakers 1 watt x 2 Audio 3.5mm headphone jack x 1 Standard: Micro SD card x 1 Power jack x 1 USB2.0 OTG x 1 PCIe /USB x 1 (internal) SIM holder x 1 (internal) USB2.0 x 3 (Internal). Power Power Adapter 12Vdc 2.4A...
-
Page 14: Dimensions
1.9 Dimensions Figure 1-7: Dimensions (millimeters) -
Page 15: Unpacking
Chapter Unpacking... - Page 16 ® To unpack the Flexpedient AT80 Tablet follow the steps below: WARNING! Remove the protective plastic cover stuck to the front screen after receiving. The plastic layer protects the display surface during shipping. Step 1: Carefully cut the tape sealing the box. Only cut deep enough to break the tape. Step 2: Open the box.
-
Page 17: Installation
Chapter Installation ® 3.1 Charging Flexpedient AT80 Tablet Battery ® Every Flexpedient AT80 Tablet is shipped with a fully charged battery. See instructions in Section 4.1 for powering the tablet and charging the battery. ® Figure 3-1: Connecting the Flexpedient AT80 Rugged Tablet to the Power Adapter... -
Page 18: Powering On/Off
Figure 3-2: Battery Icons 4) The battery is designed to be replaced only by a certified AMREL employee. The ® Flexpedient AT80 Tablet must be sent to AMREL in order for a battery to be replaced. -
Page 19: Figure 3-4: Power Off Screen
Powering Off: Press power button until box appears. Select power off. Select OK. Figure 3-4: Power Off screen... - Page 20 NOTE: ® When the Flexpedient AT80 Tablet is powered on, press the power ® button once to suspend the Flexpedient AT80 Tablet. To resume operation from the suspend mode, press the power button once.
-
Page 21: Using The Flexpedient At80 Rugged Tablet
Chapter ® Using the Flexpedient AT80 Rugged Tablet... -
Page 22: Using The Usb Otg Client Cable
4.1 Using the USB OTG Client Cable Figure 4-1: USB OTG Client Connection 1) The USB OTG Client Cable can be used to establish a host/client relationship with another computer. 2) Insert the USB OTG end of the cable into the appropriate connector on the tablet. Make sure both red dots line up to ensure the connector pins are aligned. -
Page 23: Using The Micro Sd Slot
4.2 Using the Micro SD slot Slide the I/O door open to insert SD Micro card. Note: Door can be closed with SD card inserted Figure 4-2 Micro SD slot 4.3 Using the Headphone Jack Slide the I/O door open to plug in 3.5mm Headphone jack. Note: The internal speakers will be disabled. -
Page 24: Volume Control
Figure 4-3: 3.5 mm Headphone Jack 4.4 Volume control Press + or – to raise or lower volume... -
Page 25: Figure 4-4: Volume Bar
Figure 4-4: Volume bar... -
Page 26: Home Screen
4.5 Home Screen Figure 4-5: Favorites Tray The Favorites tray at the right side of each home screen allows users to keep the most important or frequently used shortcuts and folders. Tap the All Apps button at the right side center of the home page to access the launcher/widget page. -
Page 27: Adding Shortcuts
4.6 Adding Shortcuts To add app or widget shortcuts on the home screen, follow the steps below. Step 1: Tap the All Apps button on the home screen to access the launcher/widget page. Step 2: Long press an app icon or a widget (click the WIDGETS tab to access the widgets page) and drag it to the home screen. -
Page 28: Navigation Buttons
Trash Figure 4-7: Move and Trash Item on Home Screen 4.8 Navigation Buttons The three navigation buttons shown in Figure 4-8 can always be found at the bottom of the screen. Figure 4-8: Navigation Buttons Buttons Description Back Tap to return to the previous screen. Home Tap to return to the home screen. -
Page 29: Status Bar
4.9 Status Bar The status bar on the top of the screen (Figure 4-9) displays the pending notifications and status, such as battery level or signal strength. Swipe down from the status bar to view notifications Figure 4-9: Status Bar 4.10 Settings The Settings menu allows configuration to the Flexpedient®... -
Page 30: Wireless & Networks
4.10.1 Wireless & Networks Figure 4-11: Wireless & Networks Settings In the WIRELESS & NETWORKS field, the user can turn on/off the Wi-Fi, Ethernet and Bluetooth functions, and view the data usage status. Ethernet: Allows the user to turn Ethernet function. Will need optional RJ-45 dongle or optional built in RJ-45 port to function ... -
Page 31: Figure 4-12: Ethernet Configuration
Bluetooth: Allows the user to turn on or off the Bluetooth function. When the Bluetooth function is turned on, tap this item to manage the Bluetooth connections. Data usage: Allows the user to view data usage status. Figure 4-12: Ethernet configuration... -
Page 32: More Settings
4.10.2 More Settings Figure 4-13: More Settings Menu After tapping More in the WIRELESS & NETWORKS field, the user can configure the following network settings. Airplane mode: Turns on or off the airplane mode. VPN: Sets up and manages Virtual Private Networks (VPNs). -
Page 33: Audio Profiles
4.10.3 Audio Profiles The Audio Profiles menu allows the user to configure the audio settings. Figure 4-14: Audio Profiles... -
Page 34: Display Profiles
4.10.4 Display Profiles Figure 4-15: Display Menu Use the Display menu to configure the following items. Brightness: Adjusts the screen brightness. Wallpaper Sets up the wallpaper. Sleep: Sets up the time of inactivity after which the screen turns to sleep mode. ... -
Page 35: Storage
4.10.5 Storage The Storage menu displays the status of the internal storage and any inserted micro SD card, and allows users to manage the data stored in them. Figure 4-16: Storage Menu... -
Page 36: Battery
4.9.6 Battery The Battery menu displays the battery status, battery percentage, device /apps power use, and battery history. Figure 4-17: Battery Menu... -
Page 37: Apps
4.10.7 Apps The Apps menu displays the applications installed on the device, and allows users to manage them. Figure 4-18: Apps Menu... -
Page 38: Location Services
4.10.8 Location services Figure 4-19: Location Services Use the Location service menu to configure the following items. Google location service: Enabling this item allows the apps to use Google’s location service to estimate the user’s location. GPS satellites: Enabling this item allows the internal GPS in the device to pinpoint location. -
Page 39: Security
4.10.9 Security Figure 4-20: Security Menu Use the Security menu to configure the following items: Screen lock: Set up the way to unlock the screen. Owner info: Enable this item to show the information of device owner on the lock screen. ... -
Page 40: Language & Input
Taps to install certificates from the micro SD card. Unknown sources: Enable this item to allow installation of applications from unknown sources. Verify apps: Enable this item to verify apps before installation. Trusted credentials: Tap to display the CA certificates. ... - Page 41 Language: ® Sets up the language for Flexpedient AT80 Tablet. Spell checker: Allows the user to enable the spell checking function and to configure its settings. Personal dictionary: Configures the user dictionary. Keyboard and input methods: Sets up the input methods.
-
Page 42: Backup & Reset
4.10.11 Backup & Reset Figure 4-22: Backup & Reset Menu Use the Back & Reset menu to configure the following items. Back up my data: Enables to back up the app data, Wi-Fi passwords and other settings to Google servers. ... -
Page 43: Add An Account
Factory data reset: ® Erases all data from the internal storage of the Flexpedient AT80 Tablet. 4.10.12 Add an Account Tap Add account to start setting up an e-mail or corporate account. Figure 4-23: Add Account Menu... -
Page 44: Date & Time
4.10.13 Date & Time Figure 4-24: Date & Time Menu Use the Date & Time menu to configure the following items: Automatic date & time: Enable this item to use the network-provided date & time. Set date: Sets up the system date. This item is available only when the Automatic date &... -
Page 45: Accessibility
Select time zone: Sets up the time zone. This item is available only when the Automatic time zone item is disabled. Use 24-hour format: Turns on to use the 24-hour format. Choose date format: Sets up the date format. 4.10.14 Accessibility Figure 4-25: Accessibility Menu Use the Accessibility menu to configure the following items. -
Page 46: Developer Options
Auto-rotate screen: Turns on or off the auto-rotate function of the screen. Speak passwords: Turns on or off the speak password function. Text-to-speech output: Configures the text-to-speech settings. Touch & hold delay: Configures the touch & hold delay settings. ... -
Page 47: About Device
4.10.16 About Device Figure 4-27: About Device Use the About device menu to check for new versions of software/system and display the following items. System updates: Tap to update the system. Status: Tap to display the status of batteries, network, signal, etc. ... - Page 48 Android version: Displays the Android OS version. Kernel version: Displays the kernel version.
-
Page 49: Camera
4.10.17 Camera ® The AP Flexpedient AT80 Rugged Tablet is equipped with two 5-megapixel cameras. Tap Camera on the application page to launch it. Camera icon Front/Rear camera select Flash status Capture Zoom Settings Figure 4-28: Camera Application Modes select still camera, motion, and panorama. -
Page 50: Safety Precautions
Appendix Safety Precautions... -
Page 51: Safety Recautions
AT80 Tablet is not designed to be opened by the end-user, and may not be safe to do so. Modification of the interior must be made by AMREL. 6) There are no end-user serviceable parts inside the tablet. Repairs, upgrades, and modifications must be performed by AMREL. -
Page 52: Product Disposal
AMREL. NOTE: A user cannot replace a motherboard or battery; If the unit fails it must be shipped back to AMREL to be replaced. Please contact the system vendor, reseller or an AMREL sales person directly. A.1.2 Product Disposal CAUTION: Risk of explosion if battery is replaced by an incorrect type. -
Page 53: Fcc (Federal Communications Commission) Statement
The mark on electrical and electronic products only applies to the current European Union Member States. Please follow the national guidelines for electrical and electronic product disposal. A.1.3 FCC (Federal Communications Commission) Statement This equipment has been tested and found to comply with the limits for a Class-B digital device pursuant part 15 of the FCC Rules. -
Page 54: R&Tte (Ce) Manual Regulatory Requirement
A.1.4 CE Products with the CE Marking comply with both the EMC Directive (2004/108/EC) and the Low Voltage Directive (2006/95/EC) issued by the Commission of the European Community. Compliance with these directives implies conformity to the following European Norms: EN55022 CISPR 22 Radio Frequency Interference EN55024 EN61000-4-2, EN61000-4-3, EN61000-4-4, EN61000-4-5, EN61000-4-6, EN61000-4-8, EN61000-4-11, EN61000-3-2, EN61000-3-3, Generic Immunity Standard LVD EN 60950-1: 2006+ A11: 2009+ A1: 2010+ A12: 2011... - Page 55 European standards dictate maximum radiated transmit power of 100mW EIRP and frequency range 2.400-2.4835 GHz. In France, the equipment must be restricted to the 2.4465-2.4835 GHz frequency range and must be restricted to indoor use...
-
Page 56: Repair, Rma, And Contact Information
Appendix Repair, RMA, and Contact Information... -
Page 57: Repair, Rma, & Contact Information
B.1 Repair, RMA, & Contact information ® All repairs of the Flexpedient AT80 Tablet - external & internal - must be made by AMREL. ® The casing of the Flexpedient AT80 Tablet is not designed to be opened by the end-user, and may not be safe to do so.
