Amrel rocky DK10 User Manual

Fully rugged
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the rocky DK10 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Amrel rocky DK10

Summary of Contents for Amrel rocky DK10

  • Page 2 No part of this publication may be reproduced and modified without the written permission of AMREL. AMREL reserves the right to make changes in the products or the product specifications without any prior notice. Customers are advised to contact AMREL for updated product information.
  • Page 3 FCC (Federal Communications Commission) Statement This equipment has been tested and found to comply with the limits for a Class-B digital device pursuant part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and radiates radio frequency energy.
  • Page 4 Products with the CE Marking comply with both the EMC Directive (2004/108/EC) and the Low Voltage Directive (2006/95/EC) issued by the Commission of the European Community. Compliance with these directives implies conformity to the following European Norms: EN55022 CISPR 22 Radio Frequency Interference EN55024 EN61000-4-2, EN61000-4-3, EN61000-4-4, EN61000-4-5, EN61000-4-6, EN61000-4-8, EN61000-4-11, EN61000-3-2, EN61000-3-3, Generic Immunity...
  • Page 5 CE Declaration of Conformity It is confirmed to comply with the requirements set out in the Council Directive on the approximation of the laws of the member states relating to Electromagnetic Compatibility Directive (2004/108/EC), Low-voltage Directive (2006/95/EC) and the procedures given in R&TTE Directive (99/5/EC).
  • Page 6 Power Conservation This tablet computer consumes less power compared to conventional consumer computers. The power consumption may be further reduced by properly configuring the Power Management Setup. It is recommended that the power saving features be enabled even when not running on battery power.
  • Page 7 Battery Precautions  Only use batteries designed for this tablet computer. Using incompatible battery types may cause explosion, leakage or damage to the computer.  Do not remove the battery from the computer while the computer is powered on.  Do not continuously use a battery that has been dropped, or that appears damaged (e.g.
  • Page 8 Environmental Information, Material Safety & Recycling All materials used in the manufacturing of this equipment are recyclable or environmentally friendly. Please recycle the packing materials in accordance with local regulations at the end of the product's service life. Notice:  The equipment may contain insignificant amount of hazardous substances for health and environment below control level.

  • Page 9: Table Of Contents

    TABLE OF CONTENTS CHAPTER 1 - GETTING STARTED ............... 1 ........................1 NPACKING ......................... 2 ORKPLACE ..................... 2 NVIRONMENTAL ATINGS ....................... 3 UGGEDNESS ....................4 PPEARANCE VERVIEW ......................10 EADY FOR CHAPTER2 - OPERATING INFORMATION ..........12 ............... 12 TART SING ABLET OMPUTER...
  • Page 10 .................... 47 ELECTIONS ......................48 ECURITY & E ..................... 49 CHAPTER 5 – DRIVERS AND APPLICATIONS ......... 50 ........................50 HIPSET VGA .......................... 51 ........................51 UDIO ME ........................52 NTEL ................52 NTEL APID TORAGE ECHNOLOGY ..................53 IRELESS OWER ANAGER ......................
  • Page 11 USB K ..................67 XTERNAL EYBOARD KBD ....................68 EYBOARD ........................ 69 TAND CHAPTER 8 – MAINTENANCE AND SERVICE .......... 70 ........................70 LEANING ..................... 70 ROUBLESHOOTING RMA S ......................71 ERVICE...

  • Page 12: Chapter 1 - Getting Started

    Getting Started Chapter 1 - Getting Started Unpacking The following components come with your computer. If anything is missing or damaged, please notify the dealer immediately.  Computer unit  AC Adapter  AC Power Cord  Utility DVD  Quick Guide ...

  • Page 13: Workplace

    Getting Started Workplace A clean and moisture-free environment is preferred. Make room for air circulation. Remember to avoid areas from:  Sudden or extreme changes in temperature.  Extreme heat.  Strong electromagnetic fields (Near television set, motor rotation area, etc.). ...

  • Page 14: Ruggedness

    Getting Started Ruggedness The computer is designed with rugged features such as vibration, shock, dust, and rain/water protection. However, it is still necessary to provide appropriate protection while operating in harsh environments. NEVER immerse the computer in water. Doing so may cause permanent damages. Drop may cause parts break or permanent damages.

  • Page 15: Appearance Overview

    Getting Started Appearance Overview Note:  The following illustrations show the tablet mounted on optional devices, which may not appear on your devices. Front ○ ○ ○ 1. Touch Screen 2. LED Indicators 3. Buttons (Left to Right) Button Layer 1: Button Layer 2: Function Key F1 Esc Key...
  • Page 16 Getting Started Tab Key Up Arrow Key Minus (-) Sign Delete Key Power Button Fn Key Plus (+) Sign Enter Key Left Arrow Key Decrease Brightness Right Arrow Key Increase Brightness Track Pointer Function Backlight Left Mouse Button For more information on Buttons and Indicators, please refer to Using Indicators and Buttons section.
  • Page 17 Getting Started Rear ○ ○ ○ 1. HDD or optional SSD 2. Secondary battery connector 3. Stylus holder Chapter One - 6...
  • Page 18 Getting Started Left ○ ○ ○ ○ 1. Battery 2. GLAN RJ45 3. USB 3.0 x 1 (Left) USB 2.0 with Fast Charger x 1 (Right) 4. Multi Bay: ExpressCard (Top) SIM Card + SD Card (Bottom) Chapter One - 7...
  • Page 19 Getting Started Right ○ ○ 1. DC jack (2 pin for DK10I, 3 pin for DK10M) 2. Serial port DB9 (COM1, Default: RS232) Note:  The External COM1 port default is RS232, and it can be selected by BIOS (RS232/RS422/RS485).Please refer to IT 8783F Super IO Configuration Sub-Menu section for more information.
  • Page 20 Getting Started ○ ○ 1. Optional WWAN/Wi-Fi Antenna 2. Optional Wi-Fi/BT/GPS Antenna Bottom ○ 1. Docking connector Chapter One - 9...

  • Page 21: Ready For Use

    Getting Started Ready for Use After taking a quick look at your tablet computer, the following illustrations will get you ready for using it. 1. Mounting the Battery Mount the battery into the battery bay. Close the cover, turn clockwise and lock firmly with a flat-head screwdriver or a coin.
  • Page 22 Getting Started 3. Turning ON the Power Make sure the battery is securely mounted. Connect all power cords properly. Turn on the power of your tablet computer by pressing the “Power Button“. Press to turn on the power of your tablet computer. Note: ...

  • Page 23: Chapter2 - Operating Information

    Operating Information Chapter2 - Operating Information Start Using Your Tablet Computer Always turn on your tablet computer by using the power button. This is the standard operating procedure to start using your tablet computer. After turning on the power of your tablet computer, it will start with the Operating System (OS) installed.

  • Page 24: Stop Using Your Tablet Computer

    Operating Information Stop Using Your Tablet Computer Each time when you finish working with your tablet computer, there are several ways to stop your tablet computer from operating. Shut down Directly tap “Shut down” from your OS to turn OFF the power of your computer. Before shutting down, please do remember to save any unfinished works and close your applications to prevent your HDD/SSD from suffering possible data loss or damage.

  • Page 25: Working With Power Button (Heater Kit)

    Operating Information Working with Power Button (Heater Kit) Your tablet computer is equipped with a heater kit to enable work under low temperature. The heater will heat up the HDD to the temperature set by the user before booting the system.

  • Page 26: Installing Operating System

    Operating Information Installing Operating System Your computer is designed to operate with Microsoft Windows ® 7 or 8 32 / 64-bit Operating System. Please connect your computer with an external USB-interface drive, such as an ODD or a USB thumb drive, and start the OS installation. Note: ...
  • Page 27 Operating Information Some of the functions of the first layer buttons include: Button Layer 1 Description Function Key F1/ BIOS General Help Function Key F2 / BIOS Previous Values Function Key F3 / BIOS Optimized Defaults Function Key F4 / BIOS Save & Exit Tabulation BIOS change option Minus (-) Sign...

  • Page 28: Using Hard Disk Drive (Hdd) / Optional Solid State Drive (Ssd)

    Operating Information Using Hard Disk Drive (HDD) / Optional Solid State Drive (SSD) Your tablet is equipped with 2.5” SATA II Hard Disk Drive (HDD), or optional Solid State Drive (SSD) for data storage. HDD/SSD is user removable, providing convenience and security.

  • Page 29: Using Expresscards

    Operating Information Using ExpressCards The computer supports 2.1 in or 1.3 in (54 mm or 34 mm) wide ExpressCard. You can install an ExpressCard while the computer is running. The computer automatically detects the card. To install an ExpressCard: - Hold the card with the top side of the card. - Slide the card into the slot until the card is completely seated in its connector.

  • Page 30: Intel ® Rapid Start Technology

    Operating Information ® Intel Rapid Start Technology ® Your tablet computer can operate Intel Rapid Start Technology when SSD is installed. This technology enables your system resume time not only to be as fast as wake-up time from S3 (Sleep) mode, but also to be more energy saving. Before using Intel Rapid Storage Technology, please check the following system requirements: System Requirement:...

  • Page 31: Using The Touch Screen

    Operating Information Using the Touch Screen Your tablet computer is equipped with a highly sensitive touch screen, allowing you to navigate on the touch screen easily without using other external devices. Before using the touch screen, please follow the instructions below to calibrate your stylus pen for a more precise positioning: 1.
  • Page 32 Operating Information A stylus pen is provided for operating the touch screen. A list of operating tips is provided below to help you operate the touch screen more effectively with your stylus pen. Desired Operation Stylus Action Single Click Tap the touch screen once with your stylus pen. Double Click Quickly tap the touch screen twice with your stylus pen.

  • Page 33: Operating Wireless Devices

    Operating Information Operating Wireless Devices For your ease of operations, you can turn on/off your wireless devices through the proprietary software application - “Device Power Manager”. Note:  Depending on the configuration of your tablet computer, your Device Power Manager menu may be displayed differently from the screenshots provided in the following section.
  • Page 34 Operating Information Launch the Device Power Manager After launching the utility, please tap “Bluetooth” to enable the Bluetooth function (tap again to disable). Once the Bluetooth function starts up, the wireless LED indicator (color blue) will turn on and the Bluetooth icon will show up in the operating system accordingly.
  • Page 35 Operating Information Wireless LAN (Option) Wireless LAN is an optional wireless communication module for your tablet computer. The Wireless LAN supports Wi-Fi 802.11 a/b/g/n. An embedded antenna will be pre-installed in your tablet computer to access the internet wirelessly. To activate your Wireless LAN function, please follow the illustrations below: Driver &...
  • Page 36 Operating Information Wireless Wide Area Network (Option) Wireless Wide Area Network (WWAN) is an optional module for your tablet computer. With pre-installed embedded antenna and the optional 3.5G WWAN module, your tablet computer will be able to engage in WWAN functions. Driver &...
  • Page 37 Operating Information Tap “WWAN” to enable the WWAN function (tap again to disable). Enter into OS Tap “Network” icon on the taskbar. Tap Mobile broadband for the telecom. Chapter Two - 26...
  • Page 38 Operating Information Tap “Connect” for connection. Tap “Disconnect” to end the connection Chapter Two - 27...
  • Page 39 Operating Information GPS (Option) GPS is an optional module for your tablet computer. This GPS module supports both GPS and Galileo systems. An embedded antenna is pre-installed in your tablet computer to support the functions of your GPS. Driver & Application Installation Install the Device Power Manager application: Read from the Utility DVD and find the directory listed in the readme file to finish installation.
  • Page 40 Operating Information Note:  Wireless devices can be turned ON/OFF through BIOS. Once a device is turned off through BIOS, its button on the Device Power Manager will be colored in yellow background and with a prohibition marker. The following illustration shows that WWAN and GPS devices are disabled through BIOS.

  • Page 41: Using Docklight Dl10 (Option)

    Operating Information Using Docklight DL10 (Option) Docklight acts as docking unit or port enhancer. It contains more ports that are not available on system unit. Mount Docklight 1. Open the rubber cap on the docking connector. 2. Align the docking connector. 3.
  • Page 42 Operating Information Note:  The combination of DK10+DL8 or DK8+DL10.is not fully compatible. A few functions, including audio, modem, and surge protector, are incompatible in these combination. Chapter Two - 31...

  • Page 43: Chapter3- Managing Power

    Managing Power Chapter3- Managing Power AC Adapter The AC adapter performs two functions: It powers the computer from an external AC source. It charges the computer battery. The adapter automatically detects the AC line voltage (110V or 220V) and adjusts accordingly.

  • Page 44: Battery

    Managing Power Battery The computer will automatically switch to battery when the external power source (AC adapter or optional vehicle adapter) is disconnected. Battery Power Saving Tips The computer comes with an intelligent power-saving feature. You may extend the battery life by: Setup power saving functions in Operating System Power Management options (e.g.
  • Page 45 Managing Power Battery Gauge You may check battery status from battery gauge. Click the power/battery icon to reveal the battery gauge window. The following is the illustration of Battery Gauge in Windows OS. Note:  Battery characteristic varies depending on factors such as ambient temperature, charging method, load current, aging, etc.

  • Page 46: Acpi Support

    Managing Power ACPI Support Your computer supports ACPI (Advanced Configuration and Power Interface) for power management. With ACPI and an ACPI-compliant operating system (such as Microsoft Windows), this feature will allow you to reduce the power consumption and conserve energy. By supporting ACPI, the AC adapter LED and the Power indicator LED will show in different ways.

  • Page 47: Usb Fast Charging

    Managing Power USB Fast Charging Your tablet supports USB fast charging feature, enabling to quickly charge your fast-charging compatible devices. But note, fast charging is not supported in every power mode. The following table shows details for USB Charging information: Mode USB 2.0 Charging Features Fast charging supports...

  • Page 48: Chapter 4 - Bios Setup

    Optional Devices BIOS Setup Chapter 4 - BIOS Setup Press [F2] at boot up to enter BIOS setup. Use arrow keys to select options and [+/-] to modify them. When finished, move to “Exit” and press [Enter] then confirm save by pressing [Y].

  • Page 49: Advanced Menu

    Optional Devices BIOS Setup Advanced Menu Aptio Setup Utility Main Advanced Chipset Boot Security Save & Exit Trusted Computing Setting ► Trusted Computing ► SATA Configuration ► Intel (R) Rapid Start Technology ► USB Configuration ► IT8783F Super IO Configuration →←...
  • Page 50 Optional Devices BIOS Setup Advanced Menu Selections You can make the following selections on the Advanced Menu. Feature Options Description Trusted Computing Disabled TPM Support Enabled SATA Configuration SATA Mode Selection SATA Mode Selection: IDE, AHCI, RAID Serial Port Software Preserve Serial Port Software...

  • Page 51: Sata Configuration Sub-Menu

    Optional Devices BIOS Setup SATA Configuration Sub-Menu Aptio Setup Utility Advanced Determine how SATA SATA Mode Selection [AHCI] controller(s) operate. Serial ATA Port 0 INTEL SSDSC2CW (180.0 Software Preserve SUPPORTED Port 0 [Enabled] Hot Plug [Disabled] →← : Select Screen ↑↓: Select Item Enter: Select –/+: Change Opt.

  • Page 52: Usb Configuration Sub-Menu

    Optional Devices BIOS Setup USB Configuration Sub-Menu Aptio Setup Utility Advanced Enables Legacy USB support. USB Configuration AUTO option disables legacy support if no USB devices are USB Devices: connected. Disable option will 1 point keep USB devices available only for EFI applications Legacy USB Support [Enabled]...

  • Page 53: It8783F Super Io Configuration Sub-Menu

    Optional Devices BIOS Setup IT8783F Super IO Configuration Sub-Menu Aptio Setup Utility Advanced Set Parameters of Serial IT8783F Super IO configuration Port 0 (COMA) IT8783F Super IO Chip IT8783F ►Serial Port 0 Configuration →← : Select Screen ↑↓: Select Item Enter: Select –/+: Change Opt.

  • Page 54: Rf Device Control Configuration Sub-Menu

    Optional Devices BIOS Setup RF Device Control Configuration Sub-Menu Aptio Setup Utility Advanced RF Device Control Setting RF Device Control GSM STATUS Present [Enabled] GPS STATUS Present →← : Select Screen [Enabled] ↑↓: Select Item BT STATUS Present Enter: Select BLUETOOTH [Enabled] –/+: Change Opt.

  • Page 55: Ec Thermal Control Sub-Menu

    Optional Devices BIOS Setup EC Thermal Control Sub-Menu Aptio Setup Utility Advanced EC Thermal Control EC Thermal Control Setting Thermal cooling trip point [87 C] →← : Select Screen ↑↓: Select Item Enter: Select –/+: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save &...

  • Page 56: Chipset Menu

    Optional Devices BIOS Setup Chipset Menu Aptio Setup Utility Main Advanced Chipset Boot Security Save & Exit System Agent (SA) ► System Agent (SA) Configuration Parameters ► PCH-IO Configuration →← : Select Screen ↑↓: Select Item Enter: Select –/+: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults...

  • Page 57: Pch-Io Configuration Sub -Menu

    Optional Devices BIOS Setup PCH-IO Configuration Sub-Menu Selections You can make the following selections on the PCH-IO Configuration sub-menu. Feature Options Description PCH LAN Controller Disabled Enable or disable onboard NIC. Enabled Wake on LAN Disabled Enable or disable integrated LAN to wake the system Enabled USB Configuration...

  • Page 58: Boot Menu

    Optional Devices BIOS Setup Boot Menu Aptio Setup Utility Main Advanced Chipset Boot Security Save & Exit Sets system boot Boot Option Priorities order Boot Option #1 [PO: INTEL SSDSC2CW...] Boot Option #2 [IBA GE Slot 00C8 v...] Network Device BBS Priorities →←...

  • Page 59: Security Menu

    Optional Devices BIOS Setup Security Menu Aptio Setup Utility Main Advanced Chipset Boot Security Save & Exit Administrator Password Description Password If ONLY the Administrator’s password is set, then this only limits access to Setup and is only asked for when entering Setup.

  • Page 60: Save & Exit Menu

    Optional Devices BIOS Setup Save & Exit Menu Aptio Setup Utility Main Advanced Chipset Boot Security Save & Exit Exit system setup after Save Changes and Exit saving the changes Discard Changes and Exit Save Changes and Reset Discard Changes and Reset →←...

  • Page 61: Chapter 5 - Drivers And Applications

    Optional Devices Drivers and Applications Chapter 5 – Drivers and Applications The Utility DVD includes all the drivers for the installed devices in your tablet computer. Please consult the dealer if there is any driver missing. Also, through Device Manager in Windows, you are able to perform “Driver Update”...

  • Page 62: Vga

    Optional Devices Drivers and Applications ® Windows 7/Ultimate 64-bit: Run "win64_15288.exe" in the directory of "\Drivers\Windows 7 (64-bit)\Intel_VGA", and then follow the instructions to install. ® Windows 7/Ultimate 32-bit: Run "win64_15288.exe" in the directory of "\Drivers\Windows 7 (32-bit)\Intel_VGA", and then follow the instructions to install. ®...

  • Page 63: Intel Me

    Optional Devices Drivers and Applications Intel ME ® Windows 7/Ultimate 64-bit: "Setup.exe" directory "\Drivers\Windows (64-bit)\Intel_ME\MEI_allOS_7.1.40.1161_PV", and then follow the instructions to install. ® Windows 7/Ultimate 32-bit: "Setup.exe" directory "\Drivers\Windows (32-bit)\Intel_ME\MEI_allOS_7.1.40.1161_PV", and then follow the instructions to install. ® Windows 8/Ultimate 64-bit: "Setup.exe"...

  • Page 64: Wireless Power Manager

    Optional Devices Drivers and Applications Wireless Power Manager ® Windows 7/Ultimate 64-bit: Run "setup.exe" in the directory of "\Utilities\0107\", and then follow the instructions to install. ® Windows 7/Ultimate 32-bit: Run "setup.exe" in the directory of "\Utilities\0107\", and then follow the instructions to install.

  • Page 65: Usb3.0

    Optional Devices Drivers and Applications USB3.0 ® Windows 7/Ultimate 64-bit: Run "Texas Instruments xHCI Driver v1.12.25 ( Multilanguaje - WHQL ).exe" in the directory of "\Drivers\Windows 7 (64-bit)\USB3.0\Texas Instruments xHCI Driver v1.12.25 ( Multilanguaje - WHQL )", and then follow the instructions to install. ®...

  • Page 66: Turbo Boost Monitor

    Optional Devices Drivers and Applications Turbo Boost Monitor ® Windows 7/Ultimate 64-bit: Run "setup.exe" in the directory of "\Drivers\Windows 7 (64-bit)\IntelR Turbo Boost Technology Monitor", and then follow the instructions to install. ® Windows 7/Ultimate 32-bit: Run "setup.exe" in the directory of "\Drivers\Windows 7 (32-bit)\IntelR Turbo Boost Technology Monitor", and then follow the instructions to install.

  • Page 67: Nd Gigabit Lan (Option )

    Optional Devices Drivers and Applications 2nd Gigabit LAN (Option) ® Windows 7/Ultimate 64-bit: "setup.exe" directory "\Drivers\Windows (64-bit)\RTL8111E\Install_Win7_7046_07202011", and then follow the instructions to install. ® Windows 7/Ultimate 32-bit: "setup.exe" directory "\Drivers\Windows (32-bit)\RTL8111E\Install_Win7_7046_07202011", and then follow the instructions to install. ® Windows 8/Ultimate 64-bit: "setup.exe"...

  • Page 68: Wifi (Option)

    Optional Devices Drivers and Applications WiFi (Option) ® Windows 7/Ultimate 64-bit: "Wireless_15.3.1_Ds64.exe" directory "\Drivers\Windows (64-bit)\Intel_WiFi6235\WLAN\64bit", and then follow the instructions to install. *: Then into the“Wireless Power Manager”to turn on the WLAN device. ® Windows 7/Ultimate 32-bit: "Wireless_15.3.1_Ds32.exe" directory "\Drivers\Windows (32-bit)\Intel_WiFi6235\WLAN\32bit", and then follow the instructions to install.

  • Page 69: Gps (Option)

    Optional Devices Drivers and Applications GPS (Option) ® Windows 7/Ultimate 64-bit: *: First into the "Wireless Power Manager" to turn on the GPS device. "ublox_A4_U5_USB_drv3264_install_UI.exe" directory "\Drivers\Windows 7 (64-bit)\UBlox 6H Driver", and then follow the instructions to install. ® Windows 7/Ultimate 32-bit: *: First into the "Wireless Power Manager"...

  • Page 70: Wwan (Option)

    Optional Devices Drivers and Applications WWAN (Option) ® Windows 7/Ultimate 64-bit: *: First into the“Wireless Power Manager”to turn on the WWAN device. Install Driver: Run "SWIGobi3kSetup.exe" in the directory of "\Drivers\Windows 7 (64-bit)\AirPrime MC8305 HSPA module (Gobi)\GenericGobi3k", and then follow the instructions to install. Install MC8305 module AP: "Watcher_Generic_Q.msi"...

  • Page 71: Tpm (Option)

    Optional Devices Drivers and Applications TPM (Option) ® Windows 7/Ultimate 64-bit: *: First into the "BIOS" to turn on the TPM device. Run "setup.exe" in the directory of "\Drivers\Windows 7 (64-bit)\TPM", and then follow the instructions to install. ® Windows 7/Ultimate 32-bit: *: First into the "BIOS"...

  • Page 72: Chapter 6 - Specifications

    Specifications Chapter 6 – Specifications Platform Intel® Huron River Platform Intel® Sandy Bridge i7-2610UE 4 MB Intel Smart Cache Memory Intel® Cougar Point QM67 Memory Max. 8GB System Memory Industrial grade DDR3 SO-DIMM x 1, 1333MHz Touch Screen Type: 12.1” XGA LCD with LED B/L Resolution: 1024 x 768 pixels Brightness (min.~ typ.): 280 nits ~ 350 nits...

  • Page 73: I/O Ports

    Specifications I/O Ports Serial port DB9 (Default RS232) GLAN RJ45 Multi Bay: • ExpressCard slot (ExpressCard/54) x 1(Top) • SIM Card slot x 1 + SD Card slot x 1(Bottom) Docking connector x 1 USB 3.0 port x 1 USB 2.0 with Fast Charger port x1 DC power jack Note: ...

  • Page 74: Power

    Specifications Power Primary Battery: Type: 9 x 18650 cells Lithium Ion Capacity: 11.1V/ 7200mAh Dimension: 6.42 in (W) x 3.04 in (D) x 0.81 in (H) / 163 mm (W) x 77 mm (D) x 20.5mm (H) Weight: 0.98 lb (445 g) Optional 2 Battery: Type:...

  • Page 75: Materials And Recycling

    Specifications Materials and Recycling Materials of the computer are as follows: Cabinet: Magnesium alloy AZ91D UL grade PC+ABS GE C2800 or TN-3813BW Bracket: Aluminum 5052 Steel with Nickel plating Stainless Steel S304 PCB: FR-4, UL 94V0 Battery: Rechargeable Lithium Ion cells Packing: Carton: Unbleached paper Cushion: Recyclable PE...

  • Page 76: Chapter 7 - Optional Devices

    Optional Devices Chapter 7 – Optional Devices Communication ®  WiFi/Bluetooth Intel® Centrino® Advanced-N 6235, Dual Band Board Form Factor: PCIe Half Mini Card Wi-Fi Certified: 802.11 a/b/g/n Bluetooth: Supports BT 2.1, 2.1+EDR, 3.0, 3.0+HS, 4.0 (BLE) Interface: PCIe (WiFi)/USB (BT) ...

  • Page 77: Docklight Dl10

    Optional Devices Docklight DL10 The Docklight can attach to computer or stand unit for mobile or stationary operation. Ports: Serial x 2, USB2.0 x 4, RGB, Audio (speaker out, microphone in), DC jack, Optional Giga LAN RJ45 x 1 Dimensions: 9.84 in (W) x 1.46 in (D) x 2.40 in (H) / 250mm (W) x 37mm (D) x 61mm (H) Weight:...

  • Page 78: E Xternal Usb K Eyboard

    Optional Devices External USB Keyboard An optional 89-key external USB keyboard with LED backlight and IP rating of IP54 is available for your tablet computer. The detailed specification is provided below:  89-key layout emulates 101/102-key KB  Life: >1 million times, water/dust protection up to IP54 ...

  • Page 79: Mini Keyboard Kbd

    Optional Devices Mini Keyboard KBD Mini Keyboard KBD is designed for all models. KBD also brings convenience of use through multi-language keyboard versions and USB interface. The detailed specification is provided below:  USB interface with 30 cm USB cable ...
  • Page 80 Optional Devices Stand Unit Stand unit can hold the system unit and Docklight with adjustable view angle. It can be used in office or in vehicle. There are 2 configuration options: - Stand unit only to accept system unit. - Stand unit with Docklight hooked to accept system unit. Mount Stand Unit 1.

  • Page 81: Chapter 8 – Maintenance And Service

    Chapter 8 – Maintenance and Service Cleaning ALWAYS turn OFF the power, unplug the power cord and remove the battery before cleaning. The exterior of the system and display may be wiped with a clean, soft, and lint-free cloth. If there is difficulty removing dirt, apply non-ammonia, non-alcohol based glass cleaner to the cloth and wipe.
  • Page 82 Unless prior arrangements have been made, the customer is responsible for all shipping costs. Unauthorized use of the company’s shipping accounts is not permitted. If you require support please contact AMREL Service department: Phone: 800.882.6735 E-mail: cdinfo@amrel.com Chapter Eight - 71...
