  • Page 1 User Manual H4D-200 MS H4D-60 H4D-50 MS H4D-50 H4D-40 H4D-31...

  • Page 2: Table Of Contents

    The images in this manual were not taken with a Hasselblad H4D. They are used for illustrative purposes only and are not intended to represent the image quality produced by a Hasselblad H4D. Unless otherwise stated, all images: ©...
  • Page 3 SU – getting started Inter val Set tings check Set tings White Balance / Grey balance Custom Options Media Image Info Tex t set ting Browsing images Date & Time Basic image browsing System status Zooming in and out Drive Zooming in for more detail Flash /strobe Thumbnail views...

  • Page 4: Introduction

    Hasselblad cameras, famed for quality and reliability, were chosen to record the lunar missions – there could hardly be better praise than that. Hasselblad con tinues the tradition of building on well proven technologies, refining and im proving to raise standards, always to produce a better product. By using Hasselblad equipment you share the decision made by of some of the world’s...
  • Page 5 5 HC/HCD lenses ranging from 28mm to 100mm. The CF adapter (optional accessory) allows use of the classic CF-lenses from the Hasselblad V System, with full use of their central shutters, allowing flash to be employed at shutter speeds up to 1/500s. The central shutter also improves image quality by reducing camera vibration.

  • Page 6: Instant Approval Architecture

    field or back at the studio. IAA is a Hasselblad trademark and Hasselblad has a patent pending on the invention. Extra large 3”...
  • Page 7 A smooth, reliable and competent digital workflow is crucial in a working environment. The best medium format digital captures in the world should be handled in a qualified and proficient manner to provide the last links in the chain. Phocus by Hasselblad does just that. • Hasselblad’s Natural Color Solution (HNCS) enables you to produce outstanding and reliable out-of-the-box colors, with skin tones, specific product colors and other difficult tones reproduced easily and effectively.

  • Page 8: System Requirements

    Please ensure that all the items noted on the accompany- ing packing information have been supplied and are correct.  Contact your Hasselblad dealer or distributor immediately if anything is missing or seems faulty in any way, quoting the serial numbers and purchase details where appropriate.

  • Page 9: H4D Models

    However, virtually all the information in this manual applies to all models. When differences do occur, they are marked as such. Photo: Dirk Rees / Hasselblad Masters...
  • Page 10 ISO 50, 100, 200, 400 and 800 The H4D-50 produces 65 MB raw files that meet most demands to produce the tremendous quality that Shutter Speed 32 sec. – 1/800 Hasselblad is world renowned for. Color depth 16 bit Color management Hasselblad Natural Color Solution...
  • Page 11 Shutter Speed 256 sec. – 1/800 Color depth 16 bit Color management Hasselblad Natural Color Solution CF storage capacity 4 GB CF card holds 75 images on average Capture rate 1.1 sec. per capture. 50 captures per min. Color display...
  • Page 12 Based on the 50 Mpix sensor, the H4D-200 MS offers1-, 4- TECHNICAL SPECIFICATIONS and 6-shot capability. 6-shot will produce 8 bit TIFF files at Sensor size 50 Mpixels (6132 x 8176 pixels) 600MB each resulting in the most accurate color rendering...

  • Page 13: General Overview - Controls And Displays

    General overview – controls and displays This section provides an introduction to the control buttons' functions as well as the information provided on the display screens. Photo: Claudio Napolitan / Hasselblad Masters...

  • Page 14: But Ton Func Tions

    Button functions − overview Below is an overview of the primary functions of the control wheels and buttons. Some controls have dual or triple functions according to the state of the menu or setting. A full description can be found further on in this manual. Shutter release button MENU button Releases shutter.

  • Page 15: Display Information

    This overview illustrates the Display information VIEWFINDER INFORMATION functions and features most commonly needed when shoot- − overview ing, and how they are distri- • Metering method buted on the three displays. • Aperture setting • Shutter speed For example, aperture and shut- •...

  • Page 16: Grip Display

    Grip display − overview Typical camera grip display. Flash condition indication Focus setting Drive condition (No exposure compensation, (Autofocus setting, (Single setting) normal flash synchronisation) single shot mode) Aperture setting Shutter speed setting (f/5.6) (1/400s) Exposure Value display  ISO setting (EV 13.8) (100 ISO) Low battery symbol Exposure mode indication Metering method...

  • Page 17: View F Inder Display

    Viewfinder display − overview Typical viewfinder display. Note the LEDs will only be visible when activated (by the camera or a setting). Exposure method indication Aperture setting Exposure compensation Metering method setting setting reminder symbol (‘aperture priority’ mode) (f/5.6) (Centre weighted) Focus Assist LED Flash LED True Focus (all models)

  • Page 18: Sensor Unit Display

    Sensor unit display overview When shooting, the sensor unit can display the information most often required for a quick settings check. The unit's buttons are used to navigate the main menu and change settings. ISO setting White Storage ISO setting, white balance etc information is balance medium retained when navigating the menu.

  • Page 19: Spirit Level

    Spirit level The integrated electronic spirit level provides a rapid and accurate Normal (at default setting) way of ensuring the camera is either horizontally neutral in align- ment (level) and/or vertically neutral in alignment (plumb). It uses two methods that are fully visible on the sensor unit display and partly visible in the viewfinder.

  • Page 20: But Tons And Controls - Details

    Buttons and controls − details Shutter release button This button has half-press and full-press positions. By pressing half-way (or softly) the camera, auto focus function and exposure meter can be activated. By pressing all the way down (or more firmly) the shutter will be released (or the chosen exposure proce- dure for example, the self timer is activated with this button).
  • Page 21 Can be reassigned in Custom Options to another function. Remote release cord port For attaching a remote release cord (electrical). The Hasselblad accessory jack plug socket is protected by a captive rubber plug. STOP DOWN button Press this button to make a visual check of the depth-of-field on the viewfinder screen at the chosen aperture.

  • Page 22: Audio Feedback

    There are also two control buttons on the viewfinder, as well as the eyesight correction adjustment wheel: Eyesight correction adjustment wheel The personal eyesight adjustment facility has a diopter range of -5 to +3.5, to suit most users. EV correction adjustment button Press this button to access the EV compensation screen.
  • Page 23 Saving settings changes on the grip The basic principle behind making changes is that the appropriate button is first pressed to access the menu and then settings altered by way of the control wheels. The appropriate control wheel is designated by arrowheads alongside the setting description.

  • Page 24: Camera Body

    The integral ergonomic grip houses the main control interface and also contains the battery holder. The camera body also contains the viewfinder screen, which can be easily removed Photo: Nina Berman / Hasselblad Masters or exchanged without the use of special tools or adjustment procedures.

  • Page 25: Carrying Strap

    Carrying strap 1, 2 The carrying strap is attached by firstly withdrawing the safety collar. The hook is then freed and attached to the strap lug (fig. 1). Slide back the safety collar (fig. 2) to ensure the hook remains in the locked position between the small protruding lugs.

  • Page 26: Charging The Battery

    Charging the battery With the battery removed from the camera, insert the jack plug from the battery charger into the socket on the battery grip. Insert the battery charger into a standard (100–240V~ /50–60 Hz) domestic socket. During the charging procedure, the lamp on the charger signifies the following: continuous yellow ...

  • Page 27: Rechargeable Battery Grip - Precautions

    Rechargeable battery grip – precautions: The following precautions should be followed: • Connect the battery grip to the camera correctly. • Keep the protective cover in place when not in use. (Short-circuiting across keys in a pocket, for example, could cause a fire risk). • Do not use the battery grip for anything other than H1/H1D/H2/H2D/H3D/H4D cameras. • Do not immerse the battery grip in liquids. • Do not incinerate the battery grip. Please recycle or discard in an environmentally approved manner. • Do not use any other charger than the Hasselblad battery charger BC-H Li-ion 7.2 VDC (3053568). Battery charger BC-H Li-ion 7.2 VDC – precautions: • Read the instructions before using the charger. • Use indoors only (protect against moisture). • Do not use charger for anything else than charging of Battery grip rechargeable 7.2 V (3043348). • Do not short-circuit the jack plug. • Do not alter the charger in any way other than changing the plug attachment. Battery life...

  • Page 28: Battery Status

    Battery status An immediate full-screen information and battery status check appears on the grip display by holding down the illumination/battery status button. This screen displays: • the firmware version • the number of captures taken since the last battery recharge / change. • a rechargeable-battery status icon that provides a quick visual check as well as a figure estimate in percent. The information regarding the number of captures taken is intended to help you make an estimate of the number of possible remaining captures according to your way of work- ing.

  • Page 29: Viewfinder Screen

    fluid. If the screen becomes damp, do not use hot air to dry it. Use a soft cloth on the upper surface only. Seek advice from an Authorized Hasselblad Service Center if the screen becomes particularly soiled. Remember that particles or greasy marks on the screen might impair the viewfinder image but have...

  • Page 30: Viewfinder

    This display also duplicates much Photo: Joao Carlos / Hasselblad Masters information visible on the grip display for immediate check- ing. In addition to the display, there are four LEDs providing general warnings, flash and focus information.

  • Page 31: Par Ts & Components

    User functions are the same for both wish to wear eyeglasses. models. The eye cups can be rapidly changed by a Hasselblad Authorized Service Center. Integral flash unit See under Flash for full details.

  • Page 32: Lenses

    All HC lenses have been specially formulated for the H system to produce the extremely high performance expected from Hasselblad. In addition to exceptional sharpness, the design also incorporates a very pleasing boké. All lenses feature an electronically controlled central shutter designed to extreme- ly fine tolerances for supreme accuracy.

  • Page 33: Par Ts & Components

    Parts and components A. Lens shade index B. Manual focus ring C. Focusing distance scales D. Depth-of-field scales E. Lens index Attaching a lens 2, 3 Remove the front protective cover on the camera body by depressing the lens release button and keeping it depressed while turning the cover counter-clockwise.

  • Page 34: Depth-Of-F Ield / Visual Preview

    Lens focus setting too far For specialists, please contact your Hasselblad dealer for information about sensor units beyond the distance of the subject framed by the central adapted solely for infrared photography.

  • Page 35: Manual Focus

    (AF-T can also be To expand your range of lenses, consider using a CF adapter used). to allow you to use most of the lenses from the Hasselblad V- system.

  • Page 36: Autofocus

    Manual focus There is both a Manual focus mode setting and a manual override capability. Manual focus is a specific setting that you actively make, whereas manual override is always available as a temporary override of an autofocus setting. In Manual focus mode, focusing is carried out by rotating the focusing ring in the conventional manner.

  • Page 37: Continuous

    Note though that in this mode the lens will focus at a distance and will remain focused at that distance while pressure remains on the shutter release button. In this way, you can focus on a nearby object for example, temporarily positioned within the focusing zone on the viewing screen and then without releasing pressure on the shutter release button, recompose knowing that the focus remains on the object chosen even though it is now outside the focusing zone.
  • Page 38 True Focus can be used with longer lenses, smaller apertures etc but the further you come from situations similar to the 'ideal' as described above, the less the effect will be until it has no visible effect at all. Please remember that although True Focus can noticeably improve a demanding shoot it will only work effectively in the specific circumstances it was designed for.
  • Page 39 True Focus and Absolute Position Lock The obvious situation that would most benefit from using True Focus would be a fashion shoot with a fairly wide angle lens at a large aperture setting and where the central area of the image is clothing while retaining focus on the model's face.
  • Page 40 True Focus True Focus can be used in combination with other autofocus settings to achieve various functions. Activated by shutter release button – True Focus retained In this mode the autofocus function is effectively converted into the True Focus func- tion. That is, focus is set by half-pressing the shutter release button. Remember, MENU though, that the True Focus function is retained until turned off in Custom Options. 1. In Custom Options, select # 31 (True Focus in AF-S) with the front control wheel. Select 'ON' with the rear front control wheel.

  • Page 41: Light Metering & Exposure Control

    A great deal of control is available ranging from 100% manual through to sophisticated fully automatic by way of the various exposure methods: Manual, Aperture priority, Shutter prior- Photo: Lyle Owerko / Hasselblad Masters ity, Program and Program variable.

  • Page 42: Iso & White Balance Button

    Light metering and exposure control Two primary factors have to be considered when making exposure control choice, namely, metering method and exposure method: ISO/WB Metering method determines in which manner the light measurement is made and how much of the image is taken into account (Centre Weighted, CentreSpot and Spot). Exposure method involves the parameters and deciding factors about how the light measurement is translated into aperture and shutter speeds.

  • Page 43: Metering Method

    Metering modes Centre Weighted There are three metering modes available. All three are reflective methods (measuring (23 x 20 mm) the light reflected off various selected parts of the subject according to method) and ≈ 32% (H4D-40) ≈ 25% (H4D-50) are through the lens (TTL).

  • Page 44: Manual Exposure Mode 4

    Manual Exposure – M Manual mode will provide total user control of the shutter and aperture settings. To set the Manual mode, proceed as follows with the camera in active mode: 1) Press the EXP button on the viewfinder. 2) Turn the front control wheel in either direction until you reach M (Manual).

  • Page 45: Ae-L But Ton

    Programmed variable: Pv - This mode is very similar to Pro- grammed, except with the additional parameters of lens focal length being automatically taken into account. For example, long shutter speeds will automatically be avoided with a long fo- cal length lens. To set one of the modes, proceed as follows with the camera in active mode: 1) Press the EXP button on the viewfinder.
  • Page 46 b) The AE-L button also allows the spot metering function to make zone placements. When the AE-L button is pressed, the metered area is saved as a mid-grey (Zone 5). When the spot area is then placed over another part of the scene, the new area is then compared to the saved area and the difference can be read off...

  • Page 47: Exposure Compensation/Quick Adjust

    Exposure compensation/Quick Adjust The exposure compensation function, for both manual and Custom Options #3, #17 and automatic modes can be set from -5 to +5 EV, in 1/3, 1 or 1/2 EV #23 used to deactivate and increments (Custom Option #3) and is visible above the scale in alter the settings for the rear the viewfinder and as a ±...

  • Page 48: Profiles

    Profiles Profiles not only allow for rapid setup in changing working environments but also ensure an element of security. Photo: Mark Holthusen / Hasselblad Masters...

  • Page 49: Making A Profile

    Profiles The profiles feature allows rapid access to pre-determined combinations of settings that increase the speed and security of workflow. One example might be in a social situa- tion where there might be a need for formal outdoor portraiture followed by informal indoor handheld flash-assisted wide-angle shots, both situations requiring very different settings in a stressful environment.

  • Page 50: Using Profiles

    3) Use the scroll bar to go through the list of profiles. Choose a Spare profile or a named profile (except Default). You can either save the new profile under the original name or you can change it 4) Press Save (ISO/WB button). The Profile name screen is then displayed where you can rename the profile to what suits you (see under Image Info 4.2 for procedure details).

  • Page 51: Su - Introduction

    Sensor unit – introduction Photo: Dirk Rees / Hasselblad Masters...
  • Page 52 In keeping with Hasselblad’s modular design philosophy, the sensor unit is an independ- ent component of the H4D. In this way it can be used with view/large format cameras to optimize its use (see under Sensor unit –...

  • Page 53: Par Ts And Components

    M N O H4D-31 / 40 / 50 (also applies to 200 MS) H4D-60 Parts, components & control panel buttons The buttons are used for browsing images and navigating the menu system to make settings. Two of the buttons, located at the bottom-right and -left of the screen, are given an on-screen label that changes according to the current context.
  • Page 54 Never attempt to remove the glass filter from the front of the CCD–you will probably ruin the CCD if you do so. If dust manages to get between the IR filter and CCD, it can only be removed at the Hasselblad factory. Contact your Hasselblad dealer for assistance.

  • Page 55: Over View Of Menu System And Navigation

    Introductory overview of menu access, navigation and settings choice. The menu is structured in a manner similar to mobile/cell phones and similar small electronic devices. Various branches within the tree system are accessed by pressing the navigation button until you reach the point where a choice has to be made. The OK (Approve) button or SELECTION (ZOOM IN / ZOOM OUT) buttons are then used to confirm choice.

  • Page 56: Over View Of Menu Struc Ture

    Schematic view of sensor unit menu Here you can see where all the screens are situated with regard to each other. Navigating to them is just a matter of tracing along the paths using the Navigation button. You can revert by either pressing the Navigation button in the opposite direction or the Menu/Exit button.

  • Page 57: Description Of Menu Items

    By using the buttons on the control panel and the control wheels on the Simple description grip you can navigate down through the various levels in the menu. of menu items Below is an overview of the setting options available. MENU MENU MENU WHITE BALANCE Sets the light sensitivity of the sensor. Sets the color temperature of light used. BROWSE Sets the IAA approval status (rating) filter for easier and quicker image browsing.. STORAGE STORAGE STORAGE STORAGE STORAGE STORAGE DELETE DELETE DELETE FORMAT For single or multiple dele- For single or multiple dele- For single or multiple deletion of images. Used to format CF cards for optimum use. tion of images. tion of images.

  • Page 58: Su - Initial Settings

    General sensor unit overview – initial settings This section deals with getting started as well as a general overview of tethered and untethered shooting and capture storage modes. Photo: Mark Zibert / Hasselblad Masters...

  • Page 59: Setting The Menu Language

    Getting started The initial general setting is language choice. This choice is retained but can be changed at any time. You can choose between: ENGLISH GERMAN FRENCH ITALIAN SPANISH JAPANESE CHINESE Before each shoot an ISO and a white balance setting should be made (white balance is for your convenience regarding the appearance of the image on the display though;...

  • Page 60: Capture Storage

    Hasselblad Phocus software and store captures on a computer hard-disk. • The main advantages with this mode are the almost limitless storage capacity, remote camera-control and being able to see the images (with Hasselblad Phocus) on a large screen. • The main disadvantage with this mode is the lack of mobility to any great extent.

  • Page 61: Compac T Cards

    Using compact flash memory cards When using a compact-flash card, the H4D is completely self- contained. No additional wires or connectors need to be attached. The H4D is shipped with a 4GB (or larger) compact-flash card, which is capable of holding approximately 50 − 100 captures (according to model).

  • Page 62: Formatting

    Formatting The camera is only able to read and write to storage media that have been formatted. New cards or disks sometimes have no for-  matting, or you might want to convert media that are currently using a format that the camera cannot read. There are two ways to format cards.

  • Page 63: Tethered To A Computer

    16-bit 3F file in the currently selected folder on the computer hard disk. 3FR is a proprietary Hasselblad format for storing raw captures. It contains the complete raw image exactly as it was captured by the camera, plus technical details that enable Phocus to process and display the image correctly, amongst other things.

  • Page 64: Su - Getting Started

    Sensor unit – getting started This section covers basic initial settings: ISO, white balance and selection of media. Photo: Claudio Napolitan / Hasselblad Masters...

  • Page 65: Settings Check

    Settings check ISO, White Balance and Browse settings should be checked be- fore each session. They are therefore placed at the top level of the ISO/WB menu for quick and easy access. They are also shown on-screen in most preview modes, so you can easily keep an eye on them as your work.
  • Page 66 To set the white balance on the grip The ISO/WB button provides immediate access to white bal- ance settings. The rear control wheel is used to make the de- ISO/WB sired changes. The settings are automatically and simultane- ously transferred from the camera to the sensor unit. Please note that the changes are only displayed on the sensor unit when the settings have been saved.

  • Page 67: Media

    3b. Alternatively, you can position the central spot in the view- finder over an area that you consider should be rendered as neutral in color in the image (a ‘grey card’ or even a sheet of white paper is ideal) and make a test capture (ensure the exposure is approximately correct otherwise you will get a warning message).

  • Page 68: Browsing Images

    Browsing images This section is an overview of the various ways of browsing, zooming, sorting and viewing images. Photo: Mark Holthusen / Hasselblad Masters...

  • Page 69: Basic Image Browsing

    Basic image browsing The large, full-color display enables you to inspect your shots while you are still on-location. It offers full-screen previews, high- magnification zoom, two levels of thumbnails and analysis tools including a full histogram and camera settings. When you first turn on the camera, the display opens in standard browse mode, showing the last capture taken (if any) for the current batch.

  • Page 70: Thumbnail Views

    You work your way deeper into the menu each time you press the – button to view media, batch, thumbnail view etc. The selected item is framed framed in blue. Conversely, you work your way back out of the menu each time you press the button.

  • Page 71: Preview Modes

    Preview Modes The preview can be set to various modes to show or hide technical information. It can be changed in seconds. Photo: Bang Peng / Hasselblad Masters...

  • Page 72: Preview Modes

    Preview Modes Standard preview mode You can cycle through all the available preview modes by View-Mode pressing the button. Histogram Full-screen mode preview mode Battery saver mode Histogram and full details mode View Modes Choosing the viewing mode Use the View Mode button to cycle through the available preview modes which are: • Standard preview: Shows a preview image surrounded by a display of a few important settings.

  • Page 73: Histogram Mode

    The Standard Preview display is the one shown Standard Preview ISO setting setting when you first turn on the camera and is White balance White probably the view you will use most often. Current storage medium Current It shows a preview of your most recent capture and basic information about the settings.

  • Page 74: Full-Details Mode

    Full Details Mode In full-details mode, you can read a complete list of camera settings, plus see the histogram and, in the background, a darkened preview of the image. The camera-setting details are stored with the image, so you can refer to them using Phocus even after you have loaded the image to your computer and stored it in your archive.

  • Page 75: Ia A - Instant Approval

    – Instant Approval Architecture IAA should be considered as a necessary part of your methods. It can help you browse efficiently and help in sorting before you download to a workstation. Photo: Nina Berman / Hasselblad Masters...

  • Page 76: Using Iaa

    Using Instant Approval Architecture The Instant Approval Architecture system helps you to evaluate your images as quickly as you take them. It works by supplying immediate audio feedback, which tells you instantly whether each new capture is exposed correctly or likely to be rated as over- or underexposed.
  • Page 77 3. If no problem is detected, then the image is saved with the chosen default approval status. N o t e 4. When you are browsing through your shots, keep an eye on the approval status of each and consider whether you should promote or demote each shot based on its When the current storage medium appearance on the preview screen.

  • Page 78: Default Approval Status

    Default approval status By default, the system assigns an initial approval status for each new shot based on an analysis of the distribution of exposure  levels. In the factory configuration, the status of each new shot is assigned as follows: • Green (approved): The new shot seems to have been exposed correctly.

  • Page 79: Browsing By Approval Status

    Browsing by approval status You can set the camera to browse by approval status, which Show all means, for example, that you will see only green-status images as (brackets on all) you browse a batch (or both green and yellow, or only red, etc.). The current filter setting is indicated on-screen, as illustrated.

  • Page 80: Deleting By Approval Status

    Deleting by approval status There are several ways to delete images, including approval status. You can choose to delete: • All red-status images from the selected batch or medium • All red- and yellow-status images from the selected batch or medium • All images from the selected batch or medium roceed as follows: 1. Starting at the single-image preview display, Select MAIN MENU > STORAGE > Delete. 2.

  • Page 81: File Storage

    File storage – working with batches This section covers navigation of the menu regarding storage media, the storage of captures in batches, viewing batches as well as rating and browsing captures of using the IAA system. Photo: Joao Carlos / Hasselblad Masters...
  • Page 82 Introductory overview Navigating to batches and media. – – – – – Zoomed Normal view 4-Thumbnail view 9-Thumbnail view Batch list Media Creating new batches The BATCH screen. Batch name Batch Date the batch was created Date The blue frame around a folder tells you that it is the Current Batch.

  • Page 83: Organizing Work With Batches

    Organizing work with batches Collections of captures are stored in named and dated folders called batches. They help you to organize your shots as you work  and function exactly as folders on a computer. Batches have the following properties: • When you create a new batch, you assign a name to it. • When you copy images from a compact-flash card, each batch is saved as a sub-folder on the destination disk.

  • Page 84: Navigating Batches

    Navigating batches The camera always works with a current batch. This is the location at which the camera will save all new shots. To view batches using the browse controls: 1. If you start with a single-image preview view, press the Example: nine-thumbnail view zoom-out ( ) button to pass through the following...

  • Page 85: Deleting Images

    Deleting images Photo: Stephan Zirwes / Hasselblad Masters...
  • Page 86 Menus for deleting single or several images from the current batch. Menus for deleting several images from a batch. Menus for deleting several images from all batches from a card.

  • Page 87: Delete

    Delete The storage settings allow you to format media and create new batches. You can also set the initial approval status (green or yellow) assigned to new pictures. The first item on the storage list is file deletion. The great advantage of digital capture is of course the ability to judge images on the spot, delete them immediately if necessary and thereby make room for more valuable captures.

  • Page 88: Deleting Several Images From A Batch

    Deleting several images from a batch To delete several images from a selected batch: 1. Starting at the single-image preview display, Select MAIN MENU > STORAGE > Delete. 2. Use  to enter the Delete submenu or use shortcut. – 3.

  • Page 89: Transferring Images

    3. Press  to open the Delete Image dialog. 4. You must now select the approval status that you wish to   delete. All images on the CF card that are also of the status that you select here will be deleted by the operation. Use ...

  • Page 90: Settings

    Settings This section covers various diverse settings such as sound, date & time, display brightness, etc. Photo: Bang Peng / Hasselblad Masters...

  • Page 91: User Interface

    Navigating the USER INTERFACE settings User Interface By altering the User Interface settings, you can control the way the sensor unit interacts to suit you and your preferred way of working. It also includes date and time settings. User interface menu items The user interface menu includes both items and sub-menus as follows: • ...
  • Page 92 •  Sound: The H4D uses audio feedback to help let you know if each new image is exposed correctly. This is described in Standard Instant Approval Workflow. This menu item has Volume (choose between High, Low and Off), Key Click (choose between On and Off) and Exposure Warning (choose between On and Off).

  • Page 93: Camera

      (which can be downloaded from the Hasselblad website). The serial number is also displayed in case Hasselblad Support need to know it for any eventual problem solving. The About box also shows the focus calibration ID (which must match the information on the grip display under System Status to obtain the optimum performance).

  • Page 94: Custom Options

    Custom Options Selecting an option  Proceed as follows: 1. Press MENU and navigate down to select SETTINGS. 2. Press the  button and navigate down to Custom Options. 3. Press the  button to select the option. Choices are selected –...

  • Page 95: Su - View Cameras

    Sensor unit – use with view cameras This section covers using the sensor unit when attached to a view or large format camera. Photo: Claudio Napolitan / Hasselblad Masters...
  • Page 96 View cameras – Flash sync shutters View cameras – Electronic shutters Flash sync input cable Any view camera with Hasselblad H adapter Rollei Lens- Control S Any view camera with Hasselblad H adapter Expose cable Flash sync input cable Schneider...
  • Page 97 Setting CAMERA model and options These settings are only available when the sensor unit is not attached to an H4D body. Proceed as follows: 1. Press the menu (MENU) button to open the menu. 2. Use  and  to select the SETTINGS sub-menu. 3.
  • Page 98 Setting EXPOSURE TIME and CAPTURE SEQUENCE Proceed as follows: 1. Press the menu (MENU) button to open the menu. 2. Use  and  to select the SETTINGS sub-menu. 3. Press  to open the SETTINGS menu. 4. Use  and  to select CAMERA. 5.
  • Page 99 11. Press either the or button to make an INITIAL DELAY set- ting. This setting controls the amount of time that elapses before the first capture in the sequence. 12. Press  to select DELAY. – 13. Press either to make a DELAY setting. This setting controls the amount of time between each capture in the sequence.

  • Page 100: Custom Settings

    Each one can be changed to suit your preferences so that the whole camera becomes a reflection of the way you like to work. Photo: Alexandfelix / Hasselblad Masters...

  • Page 101: General Overview Of Grip Menu

    General overview of grip menu MENU Text setting Self timer options Bracketing options Interval Settings options options Custom Options System status Drive...
  • Page 102 Menu charts – general Throughout this manual you will find charts to explain the The H4D features the advantage of multiple customization steps and procedures required to alter the various settings. of settings. This means that your personal choice of settings, These charts are laid out to graphically illustrate in a simple and thereby appearance of various combinations of symbols manner how to navigate through the menus.

  • Page 103: Self Timer

    There are a number of more advanced features that while not necessarily used every day still remain immediately accessible through the menu system. They provide the integral finesses that make the H4D a powerful and sophisticated tool to satisfy a variety of professional demands.
  • Page 104 Self timer setting The Self timer function is set in the following manner: MENU 1) Press the MENU button on the grip. 2) Turn the front control wheel until Self Timer appears. 3) Press ENTER (ISO/WB button) on the grip. 4) Turn the front control wheel to access the options, that are: Delay Mirror sequence...

  • Page 105: Bracketing

    2 Bracketing 2 frames options available 3 frames 5 frames options available options available options available 1/3 EV   1/2 EV  1 EV 2 EV 3 EV   2  Bracketing T i p The bracketing function provides an automatic series of captures; one at the standard exposure setting (Manual or Auto) and the others with pre-determined deviations in EV A bracketing sequence can be from the standard exposure.

  • Page 106: Bracketing Setting

    Bracketing setting The Bracketing function is set in the following manner: 1) Press the MENU button. MENU 2) Turn the front control wheel until Bracketing appears 3) Press Enter (ISO/WB) button on the grip 4) Turn the front control wheel to access the options, that are: Number of Captures (the number of captures required in the sequence) Sequence (the sequential order of the over- or underexposures) ISO/WB...

  • Page 107: 3 Interval

    3 Interval options available 2 frames – 255 frames options available 1 second − 1 hour   3  Interval By using the interval setting, you can allow the camera to auto- matically take a series of captures over a set period. This is often MENU required for time and motion studies, security surveillance, nature study, etc.

  • Page 108: 4 Settings

    4 Settings / 4.1 Custom Options options available CUSTOM OPTIONS   4  Settings From the Settings screen you can access four main sub-settings: Custom options, Image info, Date & Time and System status MENU by turning the front control wheel. From each of these sub- settings you can access further items for setting changes.

  • Page 109: 4.1 Custom Options

    4.1 Custom options Stop down button function • Stop Down The following is a description of all thirty four Custom Options. but can be reassigned to: They are accessed by Menu > Settings > Custom Options. The words and figures in red signify the default setting for that option. • B mode • T mode • Flash Measure •...
  • Page 110 Generates message on grip Zone makes the camera behave in the same display if attempted. fashion as the Hasselblad 205FCC. That is, the central spot is placed over a particular No allows the lens shutter and auxiliary shut-...
  • Page 111 Rear wheel quick adjust Interval & Self Timer • Yes • No • Exit • Stay Allows rear control wheel to make a rapid Allows either the Interval or Self Timer EV adjustment (or EV compensation) in mode to remain active after a capture or auto-exposure mode. immediately return to standard setting.
  • Page 112 Aperture control in Manual True Focus in AF-S • Front wheel • Rear wheel • Off • on Selects which control wheel changes the Re-assigns half press of shutter release aperture setting when in Manual expo- button to activate True Focus function in- sure mode. stead of standard automatic focus (single) Front wheel selects the front control wheel to change the aperture setting.
  • Page 113 Customizable button True Focus button function options M.UP button These four buttons by default are as- signed according to name but can be AE-L button reassigned (in Custom Options #4, #5, #6 and #7) to various other functions listed here. STOP DOWN button ·...

  • Page 114: 4.2 Image Info

    4.2 Image Info 4.2 Image Info In Image info you can compose your own combination of letters, words, symbols, etc to be included in the metadata. The same MENU procedure is also used to change a Profile name. Text setting 1) Press the MENU button on the grip.

  • Page 115: 4.3 Date & Time

    Changing text - an example Here is an example of how to change existing text (in this case the word ‘Text’ to a copyright symbol plus a photographer’s name -’Jens Karlsson’). See previous section 4.2 Image info for proce- dure description. 1) Start by accessing the Image info screen.

  • Page 116: 4.4 System Status

    4.4 System status 4.4 System status Check component usage and general servicing information as follows: MENU 1) Press the MENU button on the grip. 2) Turn the front control wheel until Settings appears. 3) Press the Enter (ISO/WB button) on the grip. ISO/WB 4) Turn the front control wheel to access System Status.

  • Page 117: Drive

    5 Drive Drive There are two drive modes: Single and Continuous. MENU Single and Continuous In Single mode, a capture is made when the shutter release button is pressed and the camera is made ready for the next capture. To make the next capture however, you must first release the shutter release button and then press again.

  • Page 118: Flash /Strobe

    Metz and other top names in the field for powerful and reliable solutions When in the studio, the H system is capable of providing flash metering for maximum control and security. Photo: Mark Zibert / Hasselblad Masters...

  • Page 119: General

    Separate flash units can be used in dedicated mode when connected to the hot shoe if the unit is compatible with the SCA3002 (Metz) system using a Hasselblad SCA3902 adapter. This provides a cable free link up for information transfer.

  • Page 120: Integral F Lash

    To access the controls: 1) Activate the camera and press the FLASH button once. FLASH 2) Turn the front control wheel to set the amount of compensa- tion required: • from +3EV through -3EV • press Clr (AF button) to clear the setting quickly if required. 3) Turn the rear control wheel to set: • normal sync (flash triggered just after the shutter opens) • rear sync (flash triggered just before the shutter closes)

  • Page 121: Flash Measure

    5) If the settings were incorrect to match the output of the flash unit, the viewfinder display shows a red triangle alongside a flashing green ‘flash’ symbol plus a warning message - ‘Low flash’. The grip display will also show a warning message - ‘Low flash’.

  • Page 122: Multi Shot

    Multi-Shot This section provides an overview of the H4D- 200MS and H4D-50MS models. Photo: Lyle Owerko / Hasselblad Masters...
  • Page 123 To make a multi-shot capture, you must work tethered to a computer and have Hasselblad Phocus running. From the cap- ture menu simply choose 'Multi-shot' and Phocus takes care of the operation automatically. The captures are then saved as 3F files directly into the capture destination folder as normal.

  • Page 124: Optional Accessories

      Camera strap H  Focusing screens  Release cord  Lens accessories Optional accessories provide the opportunity to extend the capabilities of your system or just to add extra convenience to suit your way of working. Photo: Mark Holthusen / Hasselblad Masters...
  • Page 125 An adjustable bellows lens shade that provides highly efficient protection For connecting flashes compatible with against stray light. Its compact, flat the SCA 3002 system to the Hasselblad folding design saves space in the equip- H4D. ment case. With adapters fits all HC lenses and virtually all V system lenses.
  • Page 126 Hasselblad H system. The optical design consists of 6 elements in 4 groups. Check www.hasselblad.com for further details about lens shades, endcaps, lens pouches etc or news of new accessories.
  • Page 127 HC lens range HCD 4/28mm HC 3.5/35mm HC 3.5/50­IImm HC 2.8/80mm HC 2.2/100mm HC Macro 4/120­IImm HC 3.2/150mm HC 4/210mm HC 4.5/300mm HC 3.5–4.5/50–110mm HCD 4.0–5.6/35–90mm V system C type lenses with optional  CF lens adapter...
  • Page 128 Sensor unit (included) Camera body View cameras – Flash sync shutters View cameras – Electronic shutters Flash sync input cable Any view camera with Hasselblad H adapter Rollei Lens- Control S Any view camera with Hasselblad H adapter Expose cable Flash sync...

  • Page 129: Appendix

    Appendix  P and Pv explanatory charts  Technical specifications  Problems, Equipment Care & Service This section provides an insight into the more technical aspects as well as some important reference information. Photo: Lyle Owerko / Hasselblad Masters...

  • Page 130: True Exposure

    At slow shutter speeds the effect is minimal but at faster speeds, e.g. 1/500s, the effect becomes clearly visible. As Hasselblad knows exactly how the shutters behave in HC lenses, automatic compensatory measures in speed setting adjustments are therefore employed.

  • Page 131: P & P V Modes

    Automatic exposure – P & Pv Mode P Mode Pv Mode 50-110 @ 50 50-110 @ 50 50-110 @ 110 50-110 @ 110 1. 4 1. 4 2. 0 2. 0 2. 8 2. 8 4. 0 4. 0 5. 6 5.

  • Page 132: Technical Specif Ications

    Technical specifications Camera Type Auto-focus, auto-exposure digital SLR camera with interchangeable viewfinders and lenses. Construction One piece stainless steel shell. Die-cast aluminium internal structure. Tripod sockets (1/4 and 3/8”) and quick coupling tripod plate for rapid mounting. Lenses Hasselblad HC/HCD lenses with built-in electronically controlled shutter and aperture. Automatic or manual focusing with instant manual focus override. All HC/HCD lenses meet the exacting requirements of digital photo- graphy. Lens shades can be mounted in reverse for transport. V- system lenses can be used with a CF adapter. Lens factor HC – 1.0 / HCD –1.0 (marginal crop). Viewfinder (HV 90x-II) A 90° reflex viewfinder, providing 100% field of view even when wearing eyeglasses, and built-in multi-mode light metering system. Image magnification 3.1x. Integrated fill-in flash with guide number 12. Hot-shoe for automatic flash (Metz SCA3002 system / adapter SCA3902). Dot matrix display with presentation of all relevant information. Built-in diopter adjustment from -5 to + 3.5D. Interchangeable. Focusing Automatic and manual focusing with electronic focus aid in manual mode. Instant manual focus override.Automatic focusing using passive central cross type phase detection sensor. AF metering range EV 1 to 19 (ISO 100). Shutter Electronically controlled lens shutter with speeds up to to 1/800. Flash sync at all speeds. Flash control TTL centre-weighted system. Can be used with the built-in flash or a wide variety of flashes compatible with the SCA3002 (Metz) system using adapter SCA3902. ISO range16 to 6400. Flash output can be adjusted (-3 to +3EV) for fill-in purposes independent of ambient light. Synch at all shutter speeds. Flash measurement The H4D has a built-in measurement system that measures flash light from non-TTL flashes, such as studio flashes. Exposure metering Multi-mode exposure metering using 90° reflex viewfinder. Metering options are: Spot (diameter 7.5 mm), Centre Weighted, and CentreSpot. Metering range at f/2.8 and ISO100: Spot: EV2 to 21, Centre-weighted: EV1 to 21, CentreSpot: EV1 to 21.

  • Page 133: Sensor Unit

    ISO speed range ISO 50, 100, 200, 400 and 800. ISO 50, 100, 200, 400 and 800. ISO 50, 100, 200, 400 and 800. Longest exposure time 128s 128s Shooting mode Single shot/4-shot /6-shot. Single shot/4-shot . Single shot. Color definition 16 bit. Color management Hasselblad Natural Color Solution. Image storage CF card type U-DMA (e.g. SanDisk extreme IV), or tethered to a Mac or PC Color display Yes – TFT 3 inch, 24 bit color, 230,400 pixels. Histogram /Acoustic feedback Yes. IR filter Mounted on CCD sensor. File format Lossless compressed Hasselblad 3FR/3F. Software Phocus (supplied) for Mac and PC. Platform support Mac: OSX version 10.5, Windows: XP (32 and 64 bit), Vista (32 and 64 bit) Windows 7 (32 and 64 bit).
  • Page 134 ISO speed range ISO 50, 100, 200, 400 and 800. ISO 100, 200, 400, 800 and 1600. ISO 100, 200, 400, 800 and 1600. Longest exposure time 128s 256s Shooting mode Single shot. Color definition 16 bit. Color management Hasselblad Natural Color Solution. Image storage CF card type U-DMA (e.g. SanDisk extreme IV), or tethered to a Mac or PC Color display Yes – TFT 3 inch, 24 bit color, 230,400 pixels. Histogram /Acoustic feedback Yes. IR filter Mounted on CCD sensor. File format Lossless compressed Hasselblad 3FR/3F. Software Phocus (supplied) for Mac and PC. Platform support Mac: OSX version 10.5, Windows: XP (32 and 64 bit), Vista (32 and 64 bit) Windows 7...

  • Page 135: Default Set Tings

    Default Settings ('Default' profile) Exp.mode A (Aperture priority) LM mode Centre weighted Exp. adjust Focus mode AF-S Drive mode Flash sync Normal (beginning of exp.) Flash adjust Self timer delay 10 sec Sequence Mirror up / Delay Mirror mode Mirror goes down Bracketing Frames Sequence...

  • Page 136: Care, Sensor Unit

    filter from the front of the CCD – you will probably ruin the CCD if you do so. If dust manages to get between the IR filter and CCD, it can only be removed at the Hasselblad factory. Contact your Hasselblad dealer for assistance.
  • Page 137 Cleaning using the HAMA cleaning fluid and tissues Note! Hasselblad recommends HAMA Optic Cleaning Fluid 5902. 1. Carefully spray the fluid onto the IR filter at a distance of 10-15 cm (4-5 inches), so that the fluid is applied onto the filter as a thin, even haze. 1-2 sprays are enough. If you apply too little, the fluid will start to dry up before you start wiping the filter.

  • Page 138: Problems, Equipment Care And Ser Vice

    Hasselblad Authorized Service Centers. They have the that the databus connections are not damaged or soiled in any way. Also expert staff...

  • Page 139: Addendum

    ADDENDUM – All H4D models H4D Sensor Unit updates R500 (60 Mpix) and R365 (40/50/50MS/200MS) These two updates brought all H4D models into line to commonly share all the features listed here: •  Rear LCD updated to full resolution (except H4D-50 units upgraded from H3DII-50) •  One click 100% instant focus check •  Camera grip info on rear LCD •  Two directional electronic spirit level •  Live Video (requires Phocus 2.6.3 or later)  •  Support for Rollei & Schneider electronic shutter systems So, as confirmation for all models (except upgraded), these updates will provide the following features: Rear LCD resolution 100% zoom The rear LCD offers full resolution.

  • Page 140: Quick Index

    Q U I C K I N D E X About Eyepiece adjustment Saving set tings Accessories Exposure compensation/Quick Adjust 47 Sensor unit (intro) Accessor y connec tion Exposure method Self timer AE-L but ton Set tings (Custom Options on grip) Appendix File storage Shut ter and aper ture control...
  • Page 141 The images in this manual cannot be reprinted or reused without the express permission of the photographers who took them. All text in this manual : © Victor Hasselblad AB & Hasselblad A/S. All images in this manual not credited to the specific photogra- pher: ©...
  • Page 142 Hasselblad A/S Hejrevej 30, DK - 2400 Copenhagen, Denmark Victor Hasselblad AB Box 220, SE - 401 23 Göteborg, Sweden 07.2012 - UK v16...
