Item #987829
Model #DF-5512-WH-D
USE AND CARE GUIDE
MOTION SECURITY LIGHT
Questions, problems, missing parts? Before returning to the store,
call Defiant Customer Service
8 a.m. - 6 p.m., EST, Monday - Friday
1-866-308-3976
HOMEDEPOT.COM
THANK YOU
We appreciate the trust and confidence you have placed in Defiant through the purchase of this motion security light.
We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of
products available for your home improvement needs. Thank you for choosing Defiant!

Advertisement

Chapters

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DF-5512-WH-D and is the answer not in the manual?

Questions and answers

Summary of Contents for Defiant DF-5512-WH-D

  • Page 1 THANK YOU We appreciate the trust and confidence you have placed in Defiant through the purchase of this motion security light. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of...
  • Page 2: Table Of Contents

    Table of Contents Tools Required ........3 Table of Contents ........2 Hardware Included .........4 Safety Information ........2 Package Contents ........5 Precautions ..........2 Mounting Locations .......5 Warranty ...........2 Installation ..........6 2-Year Warranty ........2 Operation...........9 Specifications ...........3 Care and Cleaning ........12 Pre-Installation .........3 Troubleshooting ........12 Planning Installation ......3 Safety Information...
  • Page 3: Specifications

    Specifications Up to 100 ft. (30 m) - Varies with surrounding temperature Range Up to 270° Sensing angle Up to 300 watt maximum (Up to 150 watt maximum per bulb holder) Electrical load - incandescent 120 VAC, 60 Hz Power requirements Test, Auto, Manual Operating modes Security, BulbSaver, AlertFlash...
  • Page 4: Hardware Included

    Pre-Installation (continued) HARDWARE INCLUDED NOTE: Hardware shown to actual size. FRONT Part Description Quantity Wire connector Rubber plug Mounting bolt Mounting bracket screw Mounting bracket screw Mounting bracket screw Gasket (not to scale) Mounting bracket (not to scale) Plastic hanger (not to scale) T3 halogen bulb (not to scale) Light shield (not to scale)
  • Page 5: Package Contents

    Pre-Installation (continued) PACKAGE CONTENTS Part Description Quantity Bulb holder Canopy Motion sensor MOUNTING LOCATIONS Determine the mounting location – a wall or under an eave. Position bulb holders (A) in the general direction of the desired light coverage and tighten the lock nuts (1) and the thumb screws (2).
  • Page 6: Installation

    Installation Installing the Mounting Hanging the Light Fixture Bracket Temporarily Insert the small end of the plastic hanger (II) WARNING: Turn the power off at the circuit breaker or through the center hole of the canopy (B) and fuse. Place tape over the circuit breaker switch and verify power is off at the light fixture.
  • Page 7 Installation (continued) Caulking Around the Light Fixture Caulk around the canopy (B) and mounting surface with silicone sealant (not included). Installing the Light Shield If the light fixture does not come on at dusk or turns off unexpectedly, then another light source may be activating the daylight turn-off (photocell) feature.
  • Page 8 Installation (continued) Replacing a Bulb CAUTION: Burn hazard. Allow the light fixture and the bulb to cool before touching. Use a clean glove or cloth when handling the new bulb. Use isopropyl (rubbing) alchohol to clean the bulb if it is touched with bare hands. Using a phillips screwdriver (not included), loosen the glass cover locking screw (1) on the bulb holder (A) and lower the glass cover (2).
  • Page 9: Operation

    Operation Rotating Sensor Controls Adjusting the Bulb Holders Downward CAUTION: To avoid water damage and risk of electrical WARNING: Risk of fire. Do not aim the bulb at a shock, the motion sensor controls must be facing the combustible surface within 3 ft. (1 m). ground when installation is complete.
  • Page 10 Operation (continued) Adjusting the Motion Sensor Setting the Sensor for Testing Detection Zone When the “ON-TIME” switch is set to the “TEST” Turn on the circuit breaker or fuse and the light position, the light fixture will operate during the day switch.
  • Page 11 Operation (continued) Adjusting the DUALBRITE Adjusting the LAMP MODE Switch Switch The “DUALBRITE” switch determines the amount of The “LAMP MODE” switch determines the way the time the lights stay on at a reduced light level after lights will turn on when motion is detected. sundown.
  • Page 12: Care And Cleaning

    Care and Cleaning To prolong the original appearance, clean with clear water and a soft, damp cloth only. Do not use paints, solvents, or other chemicals on this light fixture. They could cause a premature deterioration of the finish. This is not a defect in the finish and will not be covered by the warranty. Do not spray with a hose or power washer.
  • Page 13 Troubleshooting (continued) Problem Possible Cause Solution The lights stay on continuously. A bulb is positioned too close to the Reposition the bulb away motion sensor or pointed at nearby from the motion sensor or objects that cause heat to trigger the nearby objects.
  • Page 14 Questions, problems, missing parts? Before returning to the store, call Defiant Customer Service 8 a.m.-6 p.m., EST, Monday-Friday 1-866-308-3976 HOMEDEPOT.COM Retain this manual for future use. 205293-05A...
  • Page 15 HOMEDEPOT.COM GRACIAS Agradecemos la fe y la confianza que usted ha depositado en Defiant al comprar esta luz de seguridad por movimiento. Procuramos crear continuamente productos de calidad diseñados para mejorar su hogar. Visítenos en internet para ver nuestra línea completa de productos disponibles que necesita para el mejoramiento de su hogar.
  • Page 16: Contenido

    Contenido Herramientas Requeridas ....17 Contenido ..........16 Ferretería Incluida ........18 Información de seguridad ......16 Contenido del Paquete ......19 Precauciones ........16 Sitios Para el Montaje ......19 Garantía...........16 Instalación ..........20 2 Años de Garantía .......16 Operación ..........23 Especificaciones ........17 Cuidado y limpieza .........26 Antes de la instalación ......17 Análisis de averías .........26 Planificación de la Instalación .....17...
  • Page 17: Especificaciones

    Especificaciones Hasta 100 pies (30 m) – Varía con la temperatura circundante Alcance Hasta 270° Ángulo de detección Hasta 300 vatios máximo (Hasta 150 vatios máximo por cada Carga eléctrica-Incandescente porta-bombillas) 120 VCA, 60 Hz Requisitos de la energía eléctrica Prueba, automática, manual Fases de operación Seguridad, ahorrador de bombilla, destello de alerta...
  • Page 18: Ferretería Incluida

    Antes de la instalación (continuación) FERRETERÍA INCLUIDA NOTA: La ferretería se muestra en su tamaño real FRONT Pieza Descripción Cantidad Capuchón para cable Tapón de caucho Tornillo de montaje Tornillo del soporte de montaje Tornillo del soporte de montaje Tornillo del soporte de montaje Empaque (no está...
  • Page 19: Contenido Del Paquete

    Antes de la instalación (continuación) CONTENIDO DEL PAQUETE Pieza Descripción Cantidad Porta bombilla Escudete Detector de movimiento SITIOS PARA EL MONTAJE Determine el sitio para el montaje - una pared o debajo de un alero. Coloque los porta bombillas (A) en la dirección general para la cobertura deseada de la luz y apriete las contratuercas (1) y los tornillos de Montaje en...
  • Page 20: Instalación

    Instalación Instalación del soporte de Cuelgue temporalmente el montaje aparato de luz Inserte el extremo corto del colgador plástico ADVERTENCIA: Desconecte la energía eléctrica en el (II) pasándolo por el agujero central del disyuntor o en el fusible. Coloque cinta aislante sobre el interruptor disyuntor y compruebe que no haya energía escudete (B) y del empaque (GG).
  • Page 21 Instalación (continuación) Calafatee alrededor del aparato de luz Calafatee alrededor del escudete (B) y en la superficie de montaje con un sellador de silicona (no incluido). Instalación del protector de la Si el aparato de luz no se enciende al anochecer o se apaga inesperadamente, entonces otra fuente de luz puede que esté...
  • Page 22 Instalación (continuación) Cómo cambiar una bombilla PRECAUCIÓN: Peligro de quemaduras. Deje que el aparato de luz y la bombilla se enfríen antes de tocarlos. Use un guante o un paño limpio cuando manipule la nueva bombilla. Use alcohol isopropílico para limpiar la bombilla si la toca con las manos desprotegidas.
  • Page 23: Operación

    Operación Regulación de los porta Giro hacia abajo de los bombillas controles del detector ADVERTENCIA: Riesgo de incendio. No enfoque la PRECAUCIÓN: Para evitar daños por el agua y el bombilla a una superficie combustible que esté hasta a riesgo de una descarga eléctrica, los controles del detector 3 pies (1 m).
  • Page 24 Operación (continuación) Calibración del detector para Regulación de la zona de prueba detección del detector de movimiento Cuando el interruptor de “DURACIÓN” (“ON-TIME”) se fija en la posición “PRUEBA” (“TEST”) el aparato de luz Conecte el disyuntor o el fusible y el operará...
  • Page 25 Operación (continuación) Regulación del interruptor Regulación del interruptor DUALBRITE FASE LÁMPARA El interruptor DUALBRITE determina el lapso de tiempo El interruptor FASE LÁMPARA determina la manera que la luz permanece encendida con un nivel de luz en que las luces se encenderán cuando se detecta reducido luego de la puesta del sol.
  • Page 26: Cuidado Y Limpieza

    Cuidado y limpieza Para mantener la apariencia original, limpie solamente con agua limpia y un paño húmedo y suave. No use pinturas, solventes ni otros químicos en este aparato de luz. Podrían ser la causa de una prematura deterioración del acabado. Esto no es un defecto del acabado y no será cubierto por la garantía. No rocíe con manguera ni con una lavadora eléctrica.
  • Page 27 Análisis de averías (continuación) Problema Causa Probable Solución Las luces se apagan El aparato de luz puede estar instalado en Vuelva a ubicar el aparato de luz demasiado tarde en la un sitio relativamente oscuro. o utilice la calibración 3 horas o 6 calibración crepúsculo-al- horas.
  • Page 28 ¿Tiene preguntas, problemas o piezas faltantes? Antes de la devolución al almacén llame al Servicio al Cliente de Defiant de 8 a.m.-6 p.m., Hora del Este, de lunes a viernes. 1-866-308-3976 HOMEDEPOT.COM Guarde este manual para uso futuro. 205293-05A...
